- Page 1 INSTALLATION, OPERATION, AND MAINTENANCE MANUAL ‘CMP COMBO’ METERED SERIES CC VALVE RESIDENTIAL WATER CONDITIONER COMPLETE FOR FUTURE REFERENCE: MODEL NO: Marlo Incorporated SERIAL NO: 2227 South Street P.O. Box 044170 DATE INSTALLED: Racine, WI 53404-7003 DEALER: www.Marlo-Inc.com 8-191 R4...
-
Page 3: Specifications
‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER SYSTEM INFORMATION SPECIFICATIONS CMP-25 COMBO CMP-30 COMBO CMP-45 COMBO CMP-60 COMBO 30.0 30.0 45.0 60.0 Exchange Capacity — Kilograins 37.0 49.0 29.0 39.0 15.0 15.0 22.5 30.0 Salt per Regeneration Lbs./Regen 15.5 20.0 10.0 Max. - Page 4 ‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER SYSTEM INFORMATION TYPICAL WATER SOFTENER INSTALLATION High Pressure Warning: If feedwater pressure is known to be above Cold hard water inlet 30 p.s.i. minimum pressure 100 p.s.i. it is strongly recommended that a 1/2”...
-
Page 5: Installation
‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER INSTALLATION GENERAL SYSTEM INFORMATION 1. DESCRIPTION This is a general class of water conditioning equipment which utilizes cation exchange resin to remove posi- tively charged mineral ions, or anion exchange resin to remove negatively charged mineral ions from a water supply. - Page 6 ‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER SYSTEM INFORMATION LUBRICANT IMPORTANT: USE PURE SILICONE LUBRICANT ONLY. The size increase shown in the picture to the right is due to the damaging effects of hydrocarbon-based lubricants such as Vaseline petroleum jelly. The O-ring has swollen and become soft, which caused a leak.
-
Page 7: Installation Fitting Assemblies
‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER INSTALLATION INSTALLATION FITTING ASSEMBLIES Installation fittings connect to the control valve or the bypass valve using nuts that only require hand tightening. Hand tight nut connections between control valve and installation fittings, control valve and bypass valve, and bypass valve and installation fittings allow for ease serviceability. -
Page 8: Planning Installation
‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER INSTALLATION INSTALLATION GENERAL Shut off all water at main supply valve. Shut off the fuel supply to water heater. Open faucets (hot and cold) nearest pump or water meter to relieve pressure and drain system. Move softener into the installation position. Loosely attach all fittings to measure for bypass valve assembly (if used), or manual bypass valve. -
Page 9: Manual Regeneration
‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER INSTALLATION INSTALLATION PRESSURE TEST THE INSTALLATION The plumbing system can now be checked for any possible leaks Put the unit into backwash. To do this, push and hold the REGEN button for 3-5 seconds. When the Valve stops cycling, unplug the unit. - Page 10 ‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER INSTALLATION PROCEDURE FOR CHLORINATION OF WELLS Problems of iron bacteria, organic growths, algae and their associated tastes and odors can often be eliminated by a complete chlorination of the well and distribution piping. (See exceptions under “NOTE” below.) Iron bacteria, while harmless, utilizes iron in water for their growth and in so doing, surround themselves with relatively large, slimy masses of iron.
-
Page 11: Control Valve Function And Cycles Of Operation
‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER OPERATION CONTROL VALVE FUNCTION AND CYCLES OF OPERATION This glass filled Noryl fully automatic control valve is designed as the primary control center to direct and regulate all cycles of a water softener or filter. When the control valve is set up as a softener, the control valve can be set to perform down flow or up flow regeneration with the proper piston. -
Page 12: Installer Displays & Settings
‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER OPERATION INSTALLER DISPLAYS & SETTINGS Step 1 STEP 1 - Press NEXT and simultaneously for 3 seconds. Installer Displays/Settings STEP 2 - Hardness: Set the amount of hardness in grains of hardness as NEXT REGEN STEP 1 - Press NEXT and... - Page 13 ‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER OPERATION INSTALLER DISPLAYS & SETTINGS Regeneration Mode 2 8 : 2 2 REGEN Typically a system is set to regenerate at a time of low water usage. An example of a time with low water usage is when a household is asleep. If there is a demand for water when the system is regenerating, untreated water will be used.
-
Page 14: Flow Diagrams
‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER OPERATION FLOW DIAGRAMS flow diagram...service flow diagram...backwash TO DRAIN PISTON ROD IS PISTON ROD IS BOTTOMED BELOW 2nd STEP DOWN OUT IN “HOME” POSITION SUPPLY SUPPLY WATER WATER OUTLET PORT FOR OUTLET PORT FOR SERVICE WATER SERVICE WATER SUPPLY WATER SUPPLY... -
Page 15: Normal Operation
‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER OPERATION BYPASS VALVE The bypass valve is typically used to isolate the control valve from the plumbing system’s water pressure in order to per- form control valve repairs or maintenance. The WS1 bypass valve is particularly unique in the water treatment industry due to its versatility and state of the art design features. -
Page 16: Maintenance
‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER MAINTENANCE CONTROL VALVE PARTS DIAGRAM... -
Page 17: Control Valve Parts List
‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER MAINTENANCE CONTROL VALVE PARTS LIST DRIVE CAP ASSEMBLY, DOWNFLOW, UPFLOW & REGENERANT PISTONS, SPACER STACK ASSEMBLY ITEM NUMBER PART NUMBER DESCRIPTION QUANTITY A2488034 *Spacer Stack Assembly w/o O-Rings A2080077 Drive Cap Assembly A2077180 O-Ring 228 (use Valve O-Ring) A2309040 Piston Downflow Assembly... - Page 18 ‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER MAINTENANCE Injector Cap, Injector Screen, Injector, Plug , O-Ring, Refi ll and Refi ll Port Plug, &Drain Line - 3/4” Part of Kit, O-ring (Item #51, pg. 20) 25a, 25b Proper fl ow washer orientation directs water fl...
- Page 19 ‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER MAINTENANCE INJECTOR CAP, INJECTOR SCREEN, INJECTOR, PLUG AND O-RING PARTS LIST Item No. Part No. Description Quantity A2080079 Injector Cap Use Item 51 O-Ring 135 (Use Valve O-ring Kit) A2142016 Injector Screen A2079059 Injector Assembly Z Plug See note A2079060...
- Page 20 ‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER MAINTENANCE “C” Series Valve (Metered Shown) Media Tank Brine Media Tank Jacket Valve w/ Cover Brine Tank Cover Assembly Media Turbulator Brine Line Hosing Brine Well Caps Brine Well Brine Brine Valve Safety Valve Safety Brine Tank...
- Page 21 ‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER MAINTENANCE Water Meter and Meter Plug Item No. Part No. Description Quantity A2095069 Nut 1” Quick Connect A2360039 Meter Assembly A2100027 Turbine Assembly A2077178 O-Ring 215 (Use Valve O-ring Kit) A2287077 Meter Plug Assembly (Time clock option) *Item #37 includes Items #38 &...
- Page 22 ‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER MAINTENANCE Item No. Part No. Description Quantity A2095069 Nut 1” Quick Connect A2453012 Split Ring A2077178 O-Ring 215 (Kit available - see Item #10) A2607004 Bypass 1” Rotor A2080090 Bypass Cap A2395009 Bypass Handle A2104036 Bypass Rotor Seal Retainer A2077182...
- Page 23 ‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER MAINTENANCE (Standard) (Optional) Order No: A2129080 Order No: A2099054 Description: Fitting 1” PVC Male NPT Elbow Assembly Description: Fitting 3/4” & 1” PVC Solvent 90 Drawing No. Order No. Description Quantity Drawing No. Order No. Description Quantity A2095069 Nut 1”...
- Page 24 ‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER MAINTENANCE Table 15 Troubleshooting Procedures Problem Possible Cause Solution a. Connect power a. Transformer unplugged 1. Timer does not display b. No electric power at outlet b. Repair outlet or use working outlet time of day c.
- Page 25 ‘CMP COMBO’ SERIES CC VALVE WATER CONDITIONER MAINTENANCE Troubleshooting Procedures (continued) Problem Possible Cause Solution a. Motor not operating a. Replace motor b. No electric power at outlet b. Repair outlet or use working outlet c. Defective transformer c. Replace transformer 6.
- Page 26 NOTES...
- Page 27 NOTES...
- Page 28 2227 South Street • P.O. Box 044170 • Racine, WI 53404-7003 www.Marlo-Inc.com 8-191 R4...
