Summary of Contents for Dirt Devil CY06
- Page 1 USER MANUAL COMPACT BAGGED CYLINDER CY06 USER MANUAL DIRTDEVIL.CO.UK 0333 400 0653...
-
Page 2: Table Of Contents
If you have any questions, please email info@dirtdevil.co.uk to get in contact. CONTENTS Safety instructions ..................3 Getting to know your Dirt Devil vacuum cleaner ........7 Assembling your vacuum cleaner ............... 8 Using your vacuum cleaner ................. 9 Maintaining your vacuum cleaner .............. 10... -
Page 3: Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS FOR INDOOR USE ONLY WARNING When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY: USING THE VACUUM CLEANER •... - Page 4 • DO NOT pick up or pull the • Use genuine Dirt Devil filters vacuum cleaner by the cord. and attachments only. Using • Take care that the cord is non-genuine accessories may...
- Page 5 IMPORTANT SAFETY INSTRUCTIONS FOR INDOOR USE ONLY • Packing material must not be used for playing. There is a danger of suffocation. • Never leave the vacuum cleaner connected to the mains without supervision. • Keep the floor nozzle away from hair, face, fingers, uncovered feet or loose clothing when the vacuum...
- Page 6 WHAT TO EXPECT FROM YOUR USER MANUAL Your user manual contains lots of handy information about your Dirt Devil appliance. Please have a read and keep it somewhere safe for future reference. Here’s what you can expect from the different user manual sections.
-
Page 7: Getting To Know Your Dirt Devil Vacuum Cleaner
GETTING TO KNOW YOUR VACUUM CLEANER FEATURES Air Slide Hose Metal Telescopic Tube Cord Rewind Button Exhaust Cover + HEPA post-motor filter HEPA pre-motor Power Button filter Hose Socket Floor Tool 2-in-1 tool Cover Lock Front Wheel Synthetic Dust Bag SPARE PARTS HEPA post-motor filter Synthetic bag (x5) -
Page 8: Assembling Your Vacuum Cleaner
ASSEMBLING YOUR VACUUM CLEANER ASSEMBLING YOUR VACUUM CLEANER Before assembling or disassembling attachments, ensure the cylinder vacuum cleaner is not plugged into the mains supply and is switched off. 1. Attach the hose to the main body of the vacuum cleaner by sliding the hose connection into the hose socket until you hear a click. -
Page 9: Using Your Vacuum Cleaner
USING YOUR VACUUM CLEANER USING YOUR VACUUM CLEANER CAUTION Do not use the vacuum cleaner without placing the bag and filter in the correct position! Assemble the vacuum cleaner (see “Assembling your vacuum cleaner”). 1. Pull the cord to the desired length while holding the appliance body and plug it into the socket. CAUTION: The yellow mark on the power cord indicates it is extended almost all the way. -
Page 10: Maintaining Your Vacuum Cleaner
MAINTAINING YOUR VACUUM CLEANER CHANGING THE DUST BAG CAUTION Do not use the vacuum cleaner without placing the dust bag and filter in the correct position! Before replacing the dust bag, remove the power cord plug from the wall socket. Always use the vacuum cleaner with a dust bag fitted. -
Page 11: Cleaning The Hepa Pre-Motor Filter
Always use the vacuum cleaner with a filter in place. Failure to install the filter may result in motor damage. Make sure it is correctly inserted before using the vacuum cleaner again. It is recommended that you only use original Dirt Devil filters for your vacuum cleaner. USER MANUAL... -
Page 12: Cleaning The Hepa Post-Motor Filter
MAINTAINING YOUR VACUUM CLEANER CLEANING THE HEPA POST-MOTOR FILTER CAUTION Do not use the vacuum cleaner without the filter in the correct position! Before cleaning the filter, remove the power cord plug from the wall socket. 1. Open the air exhaust cover. 2. -
Page 13: Cleaning The Outer Body
MAINTAINING YOUR VACUUM CLEANER CLEANING THE OUTER BODY CAUTION Always turn off and unplug the vacuum cleaner for cleaning or maintenance. Do not use strong or abrasive products for cleaning the outer surface of the vacuum cleaner. 1. Clean the surface of the vacuum cleaner and its accessories with a fresh and soft cloth. 2. -
Page 14: Cleaning The Hose
MAINTAINING YOUR VACUUM CLEANER CLEANING THE HOSE The hose is two components. In order to clean it, separate the two elements by pressing the button. DIRTDEVIL.CO.UK... -
Page 15: Carriage And Storage
MAINTAINING YOUR VACUUM CLEANER CARRIAGE AND STORAGE 1. You can lift and carry the vacuum cleaner using the carry handle. Never pull or lift the vacuum cleaner using the cord. 2. Before storing the vacuum cleaner, turn it off. 3. Unplug the vacuum cleaner from the socket. 4. -
Page 16: Troubleshooting
TROUBLESHOOTING WARNING To reduce the risk of shock and unintended operation, turn off power and unplug from the mains before servicing. Problem Possible Issue Solution Change the dust bag. See “Changing the dust Loss of suction Dust bag full bag” section for more information. 1. -
Page 17: Specification
SPECIFICATION Model CY06 Power 800W Capacity Weight 4.5kg Hose length 1.5m Cord length Sound 78dB Dimensions (LxWxH) 38 x 23 x 27cm Filter type HEPA Input voltage 220-240V Current 50Hz WARNING: The above data has been supplied by the manufacturing plant and tested in laboratory conditions. - Page 18 NOTES DIRTDEVIL.CO.UK...
- Page 19 NOTES USER MANUAL...
-
Page 20: Parts List And Contact Details
Pictures are for illustration purposes only and may differ from the actual product. We are constantly striving to improve our products and the specifications contained herein are subject to change without notice. Made in China. DIRT DEVIL is a registered trademark of Techtronic Cordless GP and is used under licence by Connect Distribution Services Ltd.
