User Manual
MS-1248-M1
Multispan Control Instruments Pvt Ltd
72/B, Phase 1, GIDC Estate, Vatva, Ahmedabad-382445, Gujarat, India.
export@multispanindia.com
www.multispanindia.com
+91-9978991483
Technical Specification
INPUT:
Input
J
Input Types
K
PT-100
PT.1
Resolution
J,K,PT-100,PT.1 = 1°C
Indication
±1% of FSD ± 1°C
Accuracy
(FSD:- full scale deflection)
DISPLAY, KEY & LED:
UPPER : 4 Digit 7 Seg 0.70", RED LED
Display
LOWER : 4 Digit 7 Seg 0.50", GREEN LED
Key
SET, INC, DEC, LEFT & RIGHT
Shift key, ENT
DIMENSION:
Size
Panel Cutout
OUTPUT SPECIFICATION:
Relay
Relay Type
Rating
Range
0 to 600°C
0 to 1200°C
-99 to 400°C
-99.0 to 400.0°C
100 (H) x 100 (W) x 70(D) mm
92 (H) x 92 (W) mm
Relay Output
4 Nos.
1 (NO-C-NC)
5A, 230V AC
RS-485 Modbus

Advertisement

loading
Need help?

Need help?

Do you have a question about the MS-1248-M1 and is the answer not in the manual?

Questions and answers

Related Manuals for MULTISPAN MS-1248-M1

Summary of Contents for MULTISPAN MS-1248-M1

  • Page 1 92 (H) x 92 (W) mm Panel Cutout OUTPUT SPECIFICATION: Relay Output Relay 4 Nos. Relay Type 1 (NO-C-NC) Multispan Control Instruments Pvt Ltd Rating 5A, 230V AC 72/B, Phase 1, GIDC Estate, Vatva, Ahmedabad-382445, Gujarat, India. RS-485 Modbus export@multispanindia.com +91-9978991483 www.multispanindia.com...

  • Page 2: Auxiliary Supply

    Key Operation AUXILIARY SUPPLY: Supply voltage 100 To 270V AC,50/60 Hz, * Press key to enter in set value menu. Power consumption Approx 4VA @ 230V AC MAX, * Press & key to change the parameter setting. (VA RATING) * Press key to enter in parameter menu ACCURACY: (Input Selection, skip-unkip selection)

  • Page 3: Input Selection

    Main Menu: Note :- Values can be changed To change set value & hystersis based on relay mode & grouping MENU-1 by pressing keys. For Example: Input Selection * Group No 1 If 1st channel, have a set point as a high alarm, 1 relay Press key.

  • Page 4: For Example

    For Example: Note: Set value can be changed by key. In Group No 1, If 1st channel, have a set point as a high alarm, 1 relay. Main Menu: To change set value & hystersis based on relay mode & grouping In Group No 2 If 2nd channel, have a set point as a low alarm, 1 relay.
  • Page 5 Note: Set value can be changed by key. MENU-4 MENU-5 Communication Parameter Offset selection Press & key to access Communication Parameter. Press key to change offset. (1- 127) Ofst Addr Device Address. Offset Press key. Press key. 9600 ( 4800 / 9600 /19200 ). Offset for channel 1.

  • Page 6: Front View

    Mechanical Dimensions & Installation Safety Precautions WARNING : Risk of electric shock. All safety related codifications, symbols and instructions that appear in this operating manual or on the equipment must be strictly followed to ensure the SCANNER MS 1248-M1 safety of the operating personnel as well as the instrument. ºC If all the equipment is not handled in a manner specified by the manufacturer, it might impair the protection provided by the equipment .

  • Page 7: Modbus Setting

    Modbus Setting 1) Device Address 1 to 127 2) Baud-rate 4800 , 9600 , 19200 (bps) 3) Parity None , Even , Odd 4) Data Type Sign Integer , Float, Long 5) Frame Delay 0 to 99 Data Type = Sign Integer Data Type = Long Read Function Read Function...
