LiFePO4 Lithium Iron Phosphate Battery, 48V 160Ah

OPERATOR'S MANUAL

Serial Number

Purchase Date

Note: Thank you for purchasing this product. Please read through the instructions carefully.

Installer is responsible for damage if instructions are not followed properly. The RHOX

BAT-48160-01 LiFePO4 is an economic, high quality, 51.2V 160Ah battery for a 48V

system.

Charger Requirements: Charging requires the use of RHOX CGR-722 Battery Charger

or optional CGR-715 Battery Charger ONLY. **DO NOT USE LEAD ACID GOLF CAR

CHARGERS**. Any other charger can damage the battery, void the warranty and/or cause

a safety issue. These chargers provides protection against overload, over-voltage, over-

heating, short circuit and reverse polarity connections. The RHOX battery pack's internal

battery management system (BMS) will turn the charger ON and OFF as required.

Approved Charger (Single 48V System):

● RHOX CGR-722, 58V 22A LiFePO4 Battery Charger

● RHOX CGR-715, 58V 15A LiFePO4 Battery Charger

Charger Plugs: The RHOX CGR-715 and CGR-722 Battery Chargers includes a short

cord with a SB50 gray quick disconnect (QD) connector. Vehicle gender specific cords for

E-Z-Go, Club Car and Yamaha are sold separately. Please ensure SB50 QD connectors

are tight before use. Observe polarity!

BAT-48160-01

Revision BATT-48160-LiFePo4_A-081723

Need help?

Do you have a question about the BAT-48160-01 and is the answer not in the manual?

Page 1 Note: Thank you for purchasing this product. Please read through the instructions carefully. Installer is responsible for damage if instructions are not followed properly. The RHOX BAT-48160-01 LiFePO4 is an economic, high quality, 51.2V 160Ah battery for a 48V system.
Page 2 Specifications DC OUTPUT / INPUT Rated DC Output Voltage 51.2VDC Battery Type Lithium LiFePO4 51.2V, 16 Cell With Battery Management 16S, 51.2V, 250A System (BMS) Rated Capacity 160AH Energy 8.2KWH Total Cycle Life >3,000 Times @ 0.5C 100% DOD Charge Voltage 58.4V +/-0.2V Max Continuous CHARGE 22A Charger (CGR-722) / Optional 15A Charger (CGR-715)
Page 3 Warning and Safety Precautions • Minimum Wire Gauge: The BAT-48160-01 LiFePO4 battery requires a MINIMUM of 2AWG cable. Correctly sized terminals with a good quality crimp are required for proper installation. • Use in High Temperatures (> 110°F (37.8°C)): To increase the life of the battery, it is recommended to not push the ratings of the battery capacity, current or low voltage when operating in hot environments greater than 110°F (37.8°C).
Page 4 DRIVE, CHARGE, DRIVE, REPEAT. RHOX Lithium Iron Phosphate Batteries are highly efficient, very compact, and most importantly, durable. PAGE 4...
