LiFePO4 Lithium Iron Phosphate Battery, 12V 100Ah

OPERATOR'S MANUAL

Serial Number

Purchase Date

Note: Thank you for purchasing this product. Please read through the instructions carefully.

Installer is responsible for damage if instructions are not followed properly. The RHOX

BAT-12100-01 LiFePO4 is an economic, high quality, 12V 100Ah battery. Connect (4)

batteries in a series for a 48V system.

Charger Requirements: Charging requires the use of RHOX CGR-715, 58V 15A Battery

Charger ONLY. **DO NOT USE LEAD ACID GOLF CAR CHARGERS**. Any other charger

can damage the battery or battery pack, void the warranty and/or cause a safety issue.

This charger provides protection against overload, over-voltage, over-heating, short circuit

and reverse polarity connections. The RHOX battery pack's internal battery management

system (BMS) will turn the charger ON and OFF as required.

Approved Charger (Single 48V Pack / (4) 12V BAT-12100-01 Batteries in a Series):

● RHOX CGR-715, 58V 15A LiFePO4 Battery Charger

● Do NOT use a 22A charger on BAT-12100-01 Batteries

Charger Plugs: The RHOX CGR-715 Battery Charger includes a short cord with a SB50

gray quick disconnect (QD) connector. Vehicle gender specific cords for E-Z-Go, Club Car

and Yamaha are sold separately. Please ensure SB50 QD connectors are tight before use.

Observe polarity!

BAT-12100-01

Revision BATT-12100-LiFePo4_A-081723

Need help?

Do you have a question about the BAT-12100-01 and is the answer not in the manual?

Page 1 The RHOX battery pack’s internal battery management system (BMS) will turn the charger ON and OFF as required. Approved Charger (Single 48V Pack / (4) 12V BAT-12100-01 Batteries in a Series): ● RHOX CGR-715, 58V 15A LiFePO4 Battery Charger ●...
Page 2 Specifications DC OUTPUT / INPUT Rated DC Output Voltage 12.8VDC (51.2V Assumed for (4) 12V Batteries in Series) Battery Type Lithium LiFePO4 12.8V, 4 Cell With Battery Management 4S, 12V, 150A System (BMS) Rated Capacity 100AH Energy 1.280KWH (4x12V Batteries = 5.12KWH Total) Cycle Life >3,000 Times @ 0.5C 100% DOD Charge Voltage...
Page 3 Warning and Safety Precautions • Minimum Wire Gauge: The BAT-12100-01 LiFePO4 battery requires a MINIMUM of 2AWG cable. Correctly sized terminals with a good quality crimp are required for proper installation. • Use in High Temperatures (> 110°F (37.8°C)): To increase the life of the battery, it is recommended to not push the ratings of the battery capacity, current or low voltage when operating in hot environments greater than 110°F (37.8°C).
Page 4 DRIVE, CHARGE, DRIVE, REPEAT. RHOX Lithium Iron Phosphate Batteries are highly efficient, very compact, and most importantly, durable. PAGE 4...
