3 Wrap the strain band around the compressed wires, roughly halfway between posts on
either side. Use the nut and bolt to fix the strain band in place. The wires can now be
slowly released by the tool so that the strain band is the only thing holding them in place.
If attached to non-parallel wires: ensure the strain band is prevented from slipping by hose
clamps on the wire rope (see the 3.5 Anchor Block Wire Rope Installation (Not
Recommended) section for details).
4 Using stainless steel zip ties, attach the smart barrier node to the wire rope barrier
ensuring at least three points of contact. Using steel or plastic zip-ties, fasten the strain
band cable along the lower wire rope.
It is recommended the node is mounted onto the wire rope. However it can be attached to
posts instead if needed.
5 Activate the Smart Barrier node – see
USER MANUAL | Smart Barrier Node V2.0
Section 4 Operation
.
Page 9 of 14
