1.3

Parts List

The Smart Barrier Node is available as 3 main components:
1) Smart Barrer Node with integrated solar panel, internal rechargeable battery and magnet
2) Detachable strain band with cable and connector
3) Stainless steel cross piece for mounting
1.3.1

Smart Barrier Node

ITEM QTY DESCRIPTION
1 1 Smart Barrier
Node
2 1 Integrated
Solar panel
3
1 Cap for 7-pin
connector
4 Single
1
"STATUS" LED
5 1 Magnet
1.3.2

Detachable Strain Band

• Stainless steel band with strain gauge
installed on one side and holes for
adjustable length on the other
• UV resistant cable with 7-pin connector
Nut and bolt are 7mm hex, stainless
•
steel
• Stainless steel washer
USER MANUAL | Smart Barrier Node V2.0
Table 1 Parts List
