SM-RBX-PRO-8-BLK Dual-Layer Enclosure
Assembly Instructions
Contents
1 × Enclosure
1 × Central Support Plate
1 × Cover Plate
1 × Dust Cover
1 × Trim Bezel
6 × Silicone Grommets
1 × Hardware Pack
Installation Needs
• #1 Phillips screwdriver
• Drywall saw
• Tape measure
• Level
• ¼" flathead screwdriver
• Electric drill and ¼" bit
Danger: This equipment must be installed and assembled by qualified service personnel in
accordance with local building codes. Contact a suitable contractor if necessary.
Caution: Before beginning, carefully plan locations, accounting for electrical, ductwork, plumbing
or other obstacles that may interfere with installation of the box, equipment, or wiring.
Note:
Use only standard-size cover plates on boxes and rings installed in the Strong VersaBox.
Mid- and jumbo-size plates will not fit.
Installation
Remove the cover
plate by pulling the
finger openings on
one side of the cover
to pop it loose.
Open any knockouts in
the VersaBox Pro that
will be used for wiring.
Optional Accessories and Hardware
• Drywall screws
• Electrical box and low voltage ring for
adding terminations to cutouts
• Compact WattBox (sold separately)
1
