SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030
www.SSVworks.com
|
Phone: 818-991-1778
WARRANTY INFORMATION:
ALL SWITCH Works Electronics are covered by a limited 1 year warranty against defects
in material or workmanship. Contact SSV Works for further warranty information.
|
Fax: 866-293-6751
230-FFT13-SWE12
2015-2020 Ford F150 (Gen 13)
Alpha12 Switcher Box
Please read and understand these
!
instructions completely before
installation to avoid possible injury, or
damage to the accessory or vehicle.
Mounting Kit
BY
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for SSV Works SWITCH WORKS 230-FFT13-SWE12
Summary of Contents for SSV Works SWITCH WORKS 230-FFT13-SWE12
- Page 1 230-FFT13-SWE12 2015-2020 Ford F150 (Gen 13) Alpha12 Switcher Box Mounting Kit SSV WORKS, 201 N. Rice Ave Unit A, Oxnard, CA 93030 www.SSVworks.com Phone: 818-991-1778 Fax: 866-293-6751 Please read and understand these WARRANTY INFORMATION: ALL SWITCH Works Electronics are covered by a limited 1 year warranty against defects instructions completely before in material or workmanship.
- Page 2 PARTS CONTENTS Ford F150 Overhead Fascia Ford F150 Overhead Mounting Ford F150 ALPHA12 [B-D3174] Bracket [B-D3173] Brain Mount Bracket [B-MB3192] Ford F150 ALPHA12 M5x10 Pan Head Screw (x4) M6-1x12mm Hex Head Screw (x2) Fender Bracket [B-MB3191] [B-S1158] [B-S2870] #7-19x.75” Phillips Screw (x4) 4-40x.375 Thread Cutting Screw (x4) #10x.63”...
-
Page 3: Tools Needed For Installation
All SSV Works Non-Electronic Parts are covered by a limited lifetime warranty against instructions completely before defects in material or workmanship. All SSV Works Electronics are covered by a limited installation to avoid possible injury, or 1 year warranty against defects in material or workmanship. All SSV Works Speakers are covered by a limited lifetime warranty against defects in material or workmanship. - Page 4 E. Remove the sunglass holder. Drill a 5/8” hole on towards the front F. Attach the ALPHA12 controller to the F150 overhead Fascia using of the sunglass holder cavity (front is the windshield side). the supplied thread cutting screws (B-S3262). G.
- Page 5 SWITCH Works Brain Module Installation TOOLS NEEDED FOR INSTALLATION - Phillips Screw Driver - 8, 10 & 13mm Wrench A. The SWITCH Works brain module is mounted in this area of the B. Mount the SWITCH Works brain module to the B-MB3192 bracket engine bay above the fusebox.
- Page 6 © 2024 SSV Works, Oxnard, CA 93030 FFT13-SWE12 Rev.B 6-11-24...
