Page 1 User Guide Lenovo E4325...
Page 2 “Important safety information” on page iv • Appendix D “Notices” on page 51 The Safety, Warranty, and Setup Guide and the Regulatory Notice have been uploaded to the Web site. To refer to them, go to http://www.lenovo.com/UserManuals. First Edition (May 2013) © Copyright Lenovo 2013.
Page 4 User Guide...
Page 6: Important Safety Information
This information can help you safely use your notebook personal computer. Follow and retain all information included with your computer. The information in this document does not alter the terms of your purchase ® agreement or the Lenovo Limited Warranty. Customer safety is important. Our products are developed to be safe and effective. However, personal computers are electronic devices.
Page 7: Safety Guidelines
Note: If you notice these conditions with a product (such as an extension cord) that is not manufactured for or by Lenovo, stop using that product until you can contact the product manufacturer for further instructions, or until you get a suitable replacement.
Page 8 Power cords and power adapters DANGER Use only the power cords and power adapters supplied by the product manufacturer. The power cords shall be safety approved. For Germany, it shall be H05VV-F, 3G, 0.75 mm , or better. For other countries, the suitable types shall be used accordingly. Never wrap a power cord around a power adapter or other object.
Page 9 In addition, many mobile products, such as notebook computers, utilize a rechargeable battery pack to provide system power when in portable mode. Batteries supplied by Lenovo for use with your product have been tested for compatibility and should only be replaced with approved parts.
Page 10 A battery pack other than the one specified by Lenovo, or a disassembled or modified battery pack is not covered by the warranty. If the rechargeable battery pack is incorrectly replaced, there is danger of an explosion. The battery pack contains a small amount of harmful substances.
Page 11 • Do not restrict or block any ventilation openings. • Do not operate your computer inside furniture, as this might increase the risk of overheating. • Airflow temperatures into the computer should not exceed 35°C (95°F). © Copyright Lenovo 2013...
Page 12 Electrical current safety information DANGER Electric current from power, telephone, and communication cables is hazardous. To avoid a shock hazard: • Do not use your computer during a lightning storm. • Do not connect or disconnect any cables or perform installation, maintenance, or reconfiguration of this product during an electrical storm.
Page 13 50332-2 can be dangerous due to excessive sound pressure levels. If your Lenovo computer came with headphones or earphones in the package, as a set, the combination of the headphones or earphones and the computer already complies with the specifications of EN 50332-1.
Page 14 User Guide...
Page 15: Chapter 1. Product Overview
Note: Your computer might have slight variations from the following illustration. Figure 1. Front view Camera Touch pad Status indicators Battery status indicator Power button Speakers Right-click button Recovery button Left-click button Camera Use the camera to take pictures or hold a video conference. © Copyright Lenovo 2013...
Page 16: Left-Side View
Status indicators For more information, refer to “Status indicators” on page 6. Speakers To adjust the sound level of the built-in speakers, refer to “Function key combinations” on page 10. Right-click button Left-click button Touch pad Move your fingertip across the touch pad to move the pointer. The right-click button and left-click button provide functions similar to the right button and left button on a mouse.
Page 17 Figure 2. Left-side view Ethernet connector Security-lock slot Fan louvers HDMI connector VGA connector USB 3.0 connector Security keyhole To protect your computer from theft, you can purchase a security cable lock that fits the security keyhole to lock the computer to a stationary object. Fan louvers The fan louvers and internal fan enable air to circulate in the computer to ensure proper cooling, especially the cooling of the microprocessor.
Page 18: Right-Side View
DANGER To avoid the risk of electrical shock, do not connect the telephone cable to the Ethernet connector. You can only connect an Ethernet cable to this connector. For more information, refer to “Ethernet connection” on page 17. HDMI connector Use the high-definition multimedia interface (HDMI) connector to connect a compatible digital audio device or video monitor, such as a high-definition television (HDTV).
Page 19: Bottom View
Combo audio jack To listen to the sound from your computer, connect headphones or a headset that has a 3.5-mm (0.14-inch), 4-pole plug to the combo audio jack. USB connectors Used to connect a USB 1.1 or 2.0 device, such as a USB printer or a digital camera. Attention: When you attach a USB cable to this connector, make sure that the USB mark is facing upward.
Page 20: Status Indicators
Status indicators This topic describes the meaning of each status indicator. Note: Your computer might have slight variations from the following illustration. Figure 5. Status indicators Caps Lock status indicator When the indicator is on, Caps Lock mode is enabled. You can type all alphabetic characters (A-Z) in uppercase directly.
Page 21: Features
• Resolution: – LCD: 1366 by 768 pixels – External monitor: Maximum 2048 by 1536 pixels • Camera (on some models) Keyboard • 6-row Lenovo keyboard • Fn key • Recovery button Interface • Combo audio jack • HDMI connector •...
Page 22: Specifications
• 10/100/1000 Mbps Ethernet communication Specifications This topic lists the physical specifications for your computer. Heat output • 65 W (222 Btu/hr) or 90 W (307 Btu/hr) maximum (depending on the model) Power source (ac power adapter) • Sine-wave input at 50 to 60 Hz •...
Page 23: Chapter 2. Using Your Computer
For more information, see Chapter 5 “Recovery overview” on page 23. Where can I download the latest drivers? The latest drivers for your computer are available from the Lenovo Support Web site. To download the latest drivers for your computer, go to http://www.lenovo.com/drivers and follow the instructions on the screen.
Page 24: Registering Your Computer
When you register your computer, information is entered into a database, which enables Lenovo to contact you in case of a recall or other severe problem. After you register your computer with Lenovo, you will receive quicker services when you call Lenovo for help. In addition, some locations offer extended privileges and services to registered users.
Page 25 The following is a brief introduction to the function key combinations. Configuring camera and audio settings (Fn+Esc) Launches the camera and audio settings window. The camera preview is turned on. Then, you can change the camera and audio settings as desired. Power conservation (Fn+F1) Puts your computer into sleep mode.
Page 26: Numeric Keypad
Other functions • Fn+PrtSc: Has the same function as the SysRq key on a conventional keyboard. • Fn+Home: Has the same function as the Pause key on a conventional keyboard. • Fn+End: Has the same function as the Break key on a conventional keyboard. •...
Page 27: Power Management
Figure 8. Touch pad Right-click button: Functions the same as the right button on a conventional mouse. Left-click button: Functions the same as the left button on a conventional mouse. Touch pad: To move the cursor on the screen, slide your fingertip over the touch pad in the direction in which you want the cursor to move.
Page 28: Charging The Battery
• The power cord that plugs into the ac outlet and into the transformer pack. Attention: Using an improper power cord could cause severe damage to the computer. Connecting the ac power adapter To connect the ac power adapter, do the following: 1.
Page 29: Handling The Battery
To shut down the computer, click Start ➙ Shut down. Handling the battery This system does not support batteries that are not genuine Lenovo-made or authorized. The system will continue to boot, but might not charge unauthorized batteries. Attention: Lenovo has no responsibility for the performance or safety of unauthorized batteries, and provides no warranties for failures or damage arising out of their use.
Page 30: Connecting To The Network
The battery pack is a consumable supply. If your battery begins to discharge too quickly, replace the battery pack with a new one of the type recommended by Lenovo. For more information about replacing the battery pack, contact your Customer Support Center.
Page 31: Ethernet Connection
3. Double-click a network to connect to it. Provide required information if needed. To connect to different wireless networks in different locations, use the Access Connections program or the Lenovo Settings program to manage multiple network profiles so that the computer connects to an available network automatically when the location changes.
Page 32 User Guide...
Page 33: Chapter 3. You And Your Computer
The following topics provide information about arranging your work area, setting up your computer equipment, and establishing healthy work habits. Lenovo is committed to providing the latest information and technology to our customers with disabilities. Refer to our accessibility information which outlines our efforts in this area.
Page 34 Questions about vision? The visual display screens of Lenovo notebook computers are designed to meet the highest standards and to provide you with clear, crisp images and large, bright displays that are easy to see, yet easy on the eyes.
Page 35: Chapter 4. Security
For more information about how to set the password, refer to the online help information system on the right screen of the BIOS program. Note: To enter the BIOS program, press F1 when the Lenovo logo is displayed on the screen while the computer is starting up.
Page 36 User Guide...
Page 37: Chapter 5. Recovery Overview
To launch the program, do one of the following: – When the computer is turned off, press the recovery button and then follow the on-screen instructions. – Start the computer. When the Lenovo logo is displayed, press the recovery button and then follow the on-screen instructions.
Page 38 • Press the recovery button and then follow the on-screen instructions to open the Product Recovery program. • Start the computer. When the Lenovo logo is displayed, press the recovery button and then follow the on-screen instructions to open the Product Recovery program.
Page 39: Chapter 6. Replacing Devices
Replacing the battery pack Before you start, print these instructions. Note: This system does not support batteries that are not genuine Lenovo-made or authorized. The system will continue to boot, but may not charge unauthorized batteries. Attention: Lenovo has no responsibility for the performance or safety of unauthorized batteries, and provides no warranties for failures or damage arising out of their use.
Page 40: Replacing The Backup Battery
If the rechargeable battery pack is incorrectly replaced, there is danger of an explosion. The battery pack contains a small amount of harmful substances. To avoid possible injury: • Replace only with a battery of the type recommended by Lenovo. • Keep the battery pack away from fire.
Page 41 If the backup battery is incorrectly replaced, there is danger of an explosion. The backup battery contains a small amount of harmful substances. To avoid possible injury: • Replace only with a battery of the type recommended by Lenovo. • Keep the battery pack away from fire.
Page 42: Replacing The Hard Disk Drive
6. Install a new backup battery. 7. Reinstall the bottom slot cover, and then reinstall the screws. 8. Reinstall the battery pack. See “Replacing the battery pack” on page 25. 9. Turn the computer over again. Connect the ac power adapter and all cables. Replacing the hard disk drive Before you start, print these instructions.
Page 43: Replacing The Memory Module
6. Remove the hard disk drive by lifting the tab 7. Slide a new hard disk drive firmly into place, and then reinstall the screws to secure the drive. 8. Reinstall the bottom slot cover, and then reinstall the screws to secure the cover. 9.
Page 44 5. If one memory module is already in the memory slot, press out on the latches on both edges of the socket at the same time , and then remove the memory module to make room for the new one Save the removed memory module for future use.
Page 45: Replacing The Optical Drive
Replacing the optical drive Before you start, print these instructions. To replace the optical drive, do the following: Note: Your computer might have slight variations from the following illustrations. 1. Turn off the computer and then disconnect the ac power adapter and all cables from the computer. Wait three to five minutes to let the computer cool.
Page 46: Replacing The Pci Express Mini Card For Wireless Lan/Wimax Connection
7. Insert a new optical drive, and then reinstall the screw to secure the drive. 8. Reinstall the bottom slot cover, and then reinstall the screws to secure the cover. 9. Reinstall the battery pack. See “Replacing the battery pack” on page 25. 10.
Page 47 4. Remove the screws , and then remove the bottom slot cover 5. If a tool for removing connectors is included in the package with the new card, use the tool to disconnect the cables from the card that is currently installed .
Page 48 9. Reinstall the bottom slot cover, and then reinstall the screws to secure the cover. 10. Reinstall the battery pack. See “Replacing the battery pack” on page 25. 11. Turn the computer over again. Connect the ac power adapter and all cables. User Guide...
Page 49: Chapter 7. Preventing Problems
8. Profile your machine at http://www.lenovo.com/support to keep up to date with current drivers and revisions. 9. Keep up to date for device drivers on other non-Lenovo hardware. You might want to read the device driver information release notes before updating for compatibility or known issues.
Page 50 • Keep your computer more than 13 cm or 5 inches away from magnets, activated cellular phones, electrical applicances, or speakers. • Avoid subjecting your computer to extreme temperatures (below 5°C/41°F or above 35°C/95°F). • Some appliances, such as certain portable desktop fans or air purifiers, produce negative ions. If a computer is close to such an appliance, and is exposed for an extended time to air containing negative ions, it might become electrostatically charged.
Page 51 • Store your external and removable hard disk drives or optical drives in the appropriate containers or packaging when not in use. • Before you install any of the following devices, touch a metal table or a grounded metal object. This action reduces any static electricity from your body.
Page 52 6. Be sure to dry the display before closing it. Keep the following in mind: • Only an authorized Lenovo repair technician should disassemble and repair your computer. • Do not modify or tape the latches to keep the display open or closed.
Page 53: Chapter 8. Troubleshooting Computer Problems
1. Turn off the computer, and then disconnect the ac power adapter and remove the main battery pack. 2. Reinstall the battery and reconnect the ac power adapter, then turn on the computer. Ensure that the ac power adapter is correctly and securely connected. 3. Turn on the computer. © Copyright Lenovo 2013...
Page 54: Computer Screen Problems
If the problem persists, contact your local Customer Support Center. A startup problem Print these instructions now and keep it with your computer for reference later. The Microsoft Windows operating system does not start. Use the recovery program provided on your computer to identify and troubleshoot the problem. For details, refer to Chapter 5 “Recovery overview”...
Page 55: Problems With Drives And Other Storage Devices
Incorrect characters are displayed on the screen. Ensure that the operating system and programs are correctly installed on your computer. If the problem persists, contact your local Service Provider. When I turn on the computer, nothing is displayed on the screen and the computer does not beep while starting up.
Page 56: Onekey Recovery Pro Program Problems
I forgot my password. Do any of the following: • If you forget your user password, you must take your computer to a Lenovo authorized servicer or a marketing representative to have the password changed. • If you forget your hard disk drive password, a Lenovo authorized servicer cannot reset your password or recover data from the hard disk drive.
Page 57 2. Select Startup ➙ Boot. Ensure that the device is included in the Boot Priority Order list. 3. Press F12. 4. When the Lenovo logo is displayed on the screen, select the device that you want the computer to start from.
Page 58 User Guide...
Page 59: Appendix A. Regulatory Information
• Phone Book Access Profile (PBAP) • Service Discovery Protocol (SDP) • Synchronization Profile (SYNC) • Video Distribution Profile (VDP) • Generic Attribute Profile (GATT) • Proximity Profile • Find Me Profile • Immediate Alert Profile © Copyright Lenovo 2013...
Page 60 Due to the fact that integrated wireless cards operate within the guidelines found in radio frequency safety standards and recommendations, Lenovo believes they are safe for use by consumers. These standards and recommendations reflect the consensus of the scientific community and result from deliberations of panels and committees of scientists who continually review and interpret the extensive research literature.
Page 61: Appendix B. Weee And Recycling Statements
Lenovo encourages owners of information technology equipment to responsibly recycle their equipment when it is no longer needed. Lenovo offers a variety of programs and services to assist equipment owners in recycling their IT products. Information on product recycling offerings can be found on Lenovo's Internet site at http://www.lenovo.com/recycling.
Page 62 User Guide...
Page 63: Appendix C. Restriction Of Hazardous Substances Directive (Rohs)
Appendix C. Restriction of Hazardous Substances Directive (RoHS) India RoHS RoHS compliant as per E-Waste (Management & Handling) Rules, 2011. © Copyright Lenovo 2013...
Page 64 User Guide...
Page 65: Appendix D. Notices
Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.
Page 66: Trademarks
Trademarks The following terms are trademarks of Lenovo in the United States, other countries, or both: Lenovo Lenovo logo OneKey Microsoft and Windows are trademarks of the Microsoft group of companies: Other company, products, or service names may be trademarks or service marks of others.
Page 68 User Guide...
Page 70 Part Number: Printed in China (1P) P/N: *1P*...
