AUTOMOTIVE ACCESSORY
MANUFACTURE & DISTRIBUTION
FITTING INSTRUCTIONS
PLEASE READ INSTRUCTIONS COMPLETELY BEFORE INSTALLATION
SPORTS BAR / ROLL BAR
NEXT GEN RANGER 2022+
:
NOTE
Fits genuine Tray Caps and genuine Under Rail Liner
1. Trim off excess plastic on tray liner.
(Both sides)
2. Remove centre mount covers from
top of tray caps. Carefully drill
12mm holes through the plastic
cover along the centre line at
spacings shown.
AIRPLEX INDUSTRIES LTD
21 Saleyards Road, Otahuhu, Auckland 1062, New Zealand
PO Box 11286, Ellerslie, Auckland 1542 New Zealand
PH +64 (9) 276-9826
info@airplex.co.nz
Fax +64 (9) 276-9836
www.airplex.co.nz
FIT1182
RB019
MADE IN NEW ZEALAND
