Disney Holiday Mickey Assembly And Operation Instructions

EASY ASSEMBLY AND OPERATION INSTRUCTIONS
23SV24033 Holiday Mickey
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
IF ANY PART IS MISSING OR BROKEN, DO NOT ATTEMPT TO ASSEMBLE THE PRODUCT AND CONTACT SVI CUSTOMER SERVICE FROM 8:30AM TO 5:30PM PST AT
1-855-428-3921, EMAIL CUSTOMERSERVICE@SVIUS.COM, OR CALL HOME DEPOT CUSTOMER SERVICE FROM MON-FRI 8:00AM TO 7:00PM AND SAT 9:00 AM TO
6:00 PM EST AT 1-877-527-0313.
IMPORTANT TIPS:
• Ensure that the item's adapter is plugged in at the function control box
and in the wall.
• Ensure that the switch on the function control box is on the desired
setting.
• If not functioning properly (Body doesn't turn, head doesn't move, right
arm doesn't lift up and down), ensure that cables are connected
correctly, according to the instruction sheet.
• Be sure nothing is blocking movement or caught in moving parts.
• Ensure that the floor or surface that the item sits on is flat and level.
PARTS LIST
A. Base x 1
B. Poles x 2
C. Shoes x 2
D. Foam Tubes x 2
E. Pants x 1
F. Body Frame x 1
G. Tail x 1
H. Shirt x 1
I. Left Arm x 1
J. Right Arm x 1
K. Head x 1
L. Neck x 1
M.Hat x 1
N. Left Ear x 1
O. Right Ear x 1
P. Adapter x 1
Input: 100-240V 50/60Hz
Output: 5.9V 2A
NOTE: Throughout the instructions,
Right and Left are relative to the
character.
Click
Means It's
Locking Pin
Locked
B
B
BACK
RIGHT
A
FRONT
©Disney
Video assembly
instructions
available online
A
F
L
C
B
B
C
LEFT
A
1 1
.
• Ensure that the volume is not all the way down.
• If the item still does not work, contact SVI Customer Service
from 8:30am to 5:30pm PST at 1-855-428-3921, email
customerservice@svius.com, or call Home Depot Customer
Service from Mon-Fri 8:00am to 7:00pm and Sat 9:00 am To 6:00
pm EST at 1-877-527-0313.
B C
G H
M
N O
B
D
1 2
.
USA 1009 529 437
D E
I J K
P
NOTE: Slide the (E) Pants onto
the assembly with the tag at the
back of the (E) Pants facing
towards the back.
D
B
2 1
.
FRONT
E
2 2
.
1/3
