- Page 1 USER AND INSTALLATION MANUAL SDV6-EK C O M M E R C I A L A I R C O N D I T I O N E R S S D V 6...
- Page 3 Contents Safety Precautions ..............2 Product Description ..............4 Debugging and Solutions ............6 Installation Instructions .............8...
-
Page 4: Safety Precautions
Safety Precautions Safety Warning The Installation & Owner's Manual describes how to properly handle the product, prevent harm to others and prevent property losses, as well as how to use the product correctly and safely. Read the following carefully, make sure you understand the content (symbols and marks), and observe the precautions below. - Page 5 Warning ア This unit must be installed by professional technicians. Users are not allowed to install the unit themselves; otherwise, personal injury or damage to the controller may occur. ア Other electrical wiring work must be carried out by a professional technician according to the circuit diagram.
-
Page 6: Product Description
2-way X, Y and Eports shall be extended to meet the application scenario where "the VRF system requires two centralized control platforms at the same time". It is suitable for all SDV6 series units, that is, SDV6 ODUs and SDV6 IDUs. X Y E X1 Y1 E (CTR) - Page 7 Indicator Type Status Description Power supply for the gateway disconnected or abnormal Power supply Steady on Proper operation of power supply for the gateway Off/Steady Abnormal communication between the gateway and VRF X Y E units communication X Y E Normal communication between the gateway and VRF status Blinking...
-
Page 8: Debugging And Solutions
Debugging and Solutions Debugging Connect the X, Y and E ports on the ODU to those on the gateway. Power on the gateway. (*1) (*1) When the refrigerant system is powered on, system detection will take some time. During this period, the gateway may obtain incorrect information about the refrigerant system. - Page 9 Solutions If the gateway does not detect the refrigerant system (both the number of IDUs and the number of ODUs displayed are 0), do as follows to check the communication between the gateway and the refrigerant system: Check whether the refrigerant system is just powered on. After the refrigerant system stabilizes, check whether the gateway can detect the IDUs and ODUs.貅about 15 minutes after power-on觖depending on the actual refrigerant system貘...
-
Page 10: Installation Instructions
Installation Instructions Product Introduction X Y E X1 Y1 E (CTR) X2 Y2 E (CTR) Product Dimensions Unit: mm 51.5 74.5 Installation Components Please confirm that you have all the necessary parts. Description Quantity Remarks Self-tapping screw ST4*20 Plastic expansion pipe For installing the controller onto the wall 3-pin black terminal For communication... - Page 11 Installation Instructions Installation Method 1. Installing the Guide Rail Pull open the Snap fit the Close the handle buckle product on the handle buckle guide rail 2. Mounting the Device on the Wall Pull open the handle buckle Philips head screw ST4*20 Plastic expansion (This fixing screw is pipe...
- Page 12 United Kingdom www.sinclair-world.com This product was manufactured in China (Made in China). R E P R E S E N T A T I V E SINCLAIR Global Group s.r.o. Purkynova 45 612 00 Brno Czech Republic T E C H N I C A L S U P P O R T SINCLAIR Global Group s.r.o.
