Please read this operation manual before using the air conditioner.
Keep this operation manual for future reference.
0010519692
SPLIT TYPE ROOM AIR CONDITIONER

OPERATION MANUAL

Contents
1
2-4
5
6.7
7

Advertisement

loading

  Related Manuals for Haier HSU-09LEK03/ (DB)

  Summary of Contents for Haier HSU-09LEK03/ (DB)

  • Page 1: Table Of Contents

    SPLIT TYPE ROOM AIR CONDITIONER OPERATION MANUAL HSU-09LEK03/ (DB) HSU-12LEK03/ (DB) Contents HSU-108CH09 HSU-138CH09 PARTS AND FUNCTIONS OPERATION MAINTENANCE CAUTIONS TROUBLE SHOOTING Please read this operation manual before using the air conditioner. Keep this operation manual for future reference. 0010519692...
  • Page 2: Parts And Functions

    Hint: CLOCK Remove the batteries in case unit won't be in usage for a long period. LIGHT If there are any display after taking-out, just need to press reset key SLEEP...
  • Page 3: Operation

    SWING 2.In FAN operation mode the unit will not operate MODE in COOL mode but only in FAN mode ,AUTO is not available in FAN mode.And temp.setting is disabled. Heat Operation Air Flow Direction Adjustm MODE MODE SWING...
  • Page 4: Timer Operation

    You can let unit start or stop automatically a following times: Emergency Operation: Before you wake up in the morning, or get back from outside Use this operation only when the remote controller or after you fall asleep at night.
  • Page 5: Operation Mode

    Power Failure Resume Function Note to the power failure resume: If the unit is started for the first time, the compressor will not press the sleep button ten times in five seconds and enter start running unless 3 minutes have elapsed. When the power function after hearing four sounds.And press the sleep button...
  • Page 6: Maintenance

    Clean the filter. for a long time, turn off the Use a vacuum cleaner to remove dust, or wash the filter with power supply main switch. water.After washing, dry the filter completely in the shade.
  • Page 7: Cautions

    Cautions WARNING Please call Sales/Service Shop for the Installation. Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. WARNING Check proper When abnormality such as burnt-small found, Use an exclusive...
  • Page 8: Trouble Shooting

    The type of connecting wire is H05RN-F or H07RN-F In DRY mode, when room 3. If the fuse on PC board is broken please change it with a fuse temperature becomeslower type T. 3.15A/250V. In dry mode, fan than temp.setting+2...

This manual is also suitable for:

Hsu-12lek03/ (db)Hsu-24hek03Hsu-108ch09Hsu-138ch09
