HORNER CANVAS 10D Quick Reference Manual

CANVAS 10D QUICK REFERENCE GUIDE
GENERAL SPECIFICATIONS
Primary Voltage Range
Typical Power Backlight 733mA @ 10VDC (10.17W); 336mA
at 100%
Typical Power Backlight
at 50%
Typical Power Backlight
at 0%
Inrush Current
Real Time Clock
Clock Accuracy
Relative Humidity
Operating Temperature
Storage Temperature
Weight
Pollution Degree
Altitude
Housing Material
Panel Seal
Type 1, 4X indoor use only, 12, 12K
Front Panel
Packaging
Included in Box
POWER WIRING
PIN SIGNAL
1 Ground
2 DC-
3 DC+
NOTE: Primary Power Range: 10-30VDC
Indianapolis, USA | Cork, Ireland | Calgary, Canada | Bangalore, India | Oakleigh, Australia | Tianjin, China | Esteio, Brazil
Please visit our website for a complete listing and to learn more about certified Horner Automation products.
This document is the property of Horner Automation Group, and is subject to change.
10 - 30VDC
@ 24VDC (10.56W)
180mA @ 24VDC (2.66W)
171mA @ 24VDC (2.52W)
140mA @ 24V
25A for < 1ms @ 24VDC, DC
switched
Battery Backed, Lithium Coin
20 ppm maximum at 25°C (
±
min/month)
5 to 95% Non-condensing
-10°C to +60°C
-20°C to +60°C
43.2oz (1225g)
2
Up to 2000m
Polycarbonate, UL rated
Silicone rubber
and 13
100% Recyclable
paper fiber materials
Controller,
3 x I/0 connectors,
4 x mounting clips,
1 x power connector,
1 x snap on feritte
Stud mounting hardware,
Quick Reference Guide
Primary Power Port Pins
DESCRIPTION
Frame Ground
Input Power Supply Ground
Input Power Supply Voltage
CONTROLLER OVERVIEW
1
±
1. Touch Screen
2. microSD: Data Storage
3. USB C Port
4. CAN 2 Port
5. MJ 1/2 Port
6. DIP Switches
7. MJ3 Port
8. CAN 1 Port
9. Power In
10. LAN2 Port
11. LAN1 Port
12. Audio Line Out/Mic In
13. USB A Port
14. OCS-I/O Port
NOTE: See Precaution #12 about USB and grounding.
page 1 of 5 technical specifications continued on next page...
MAN1394_00_EN_CV10D_QRG
