Part Numbers
Global Part Number
European Part Number

User Manual and Add-Ons

Find the documents via the
Part #
MAN1032
EXL6 & XL6 Prime User Manual
MAN1142
Rechargeable Battery Manual
HE-BAT019
Rechargeable 3.6V Lithium Battery
HE-XCK
Programming Cables
2 channel Analog Output I/O option kit,
HE-XDAC
selectable 0-10V, +/-10V, 4-20mA.
4 channel Analog Output I/O option kit,
HE-XDAC107
selectable 0-10V, +/-10V, 4-20mA.
HE-XKIT
Blank I/O Board
Adapter, RJ45 (8P8C) male to 8-pos-
HE200MJ2TRM
ition terminal strip.
Ferrite core for filtering out electrical
HE-FBD001
noise.

Battery Maintenance

The EXL6 has an advanced battery system that uses a
rechargeable lithium battery. The battery powers the real
time clock when power is removed, and it is needed for
register data retention. Manual MAN1032 via the
mentation Search
for more details on battery replacement.
EXL6 Datasheet - Model 2
12 DC In, 6 Relay Out, 4 - 12-bit Analog In
MAN1169-EN-21_EXL6_Mod2
HE-EXL1E2
HEXT371C112
Documentation
Search.
Description
Docu-

Table of Contents

Page 1
1
1
2
2
2
2
2
3
3
3
4
4
4
4
5
5
5
5
5
5
6
6
6
6
6
7
7
7
7
7
8
8
8
8
9
9
9
9
9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXL6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HORNER EXL6

  • Page 1: Table Of Contents

    Technical Support Battery Maintenance Precautions The EXL6 has an advanced battery system that uses a rechargeable lithium battery. The battery powers the real time clock when power is removed, and it is needed for register data retention. Manual MAN1032 via the...
  • Page 2: Technical Specifications

    TECHNICAL SPECIFICATIONS General Specifications User Interface Required Power Display Type 5.77” VGA TFT (450 nit typical) 420mA @ 12VDC 230mA @ 24VDC (Steady State) Resolution 640 x 480 Required Power 25A for < 1ms @ 24VDC, DC Color 16-bit (65,536) (Inrush) switched Screen Memory...
  • Page 3: Controller Overview

    CONTROLLER OVERVIEW Overview of OCS Power Wiring NOTE: The Primary Power Range is 10VDC to 30VDC. Primary Power Port Pins Signal Description Ground Frame Ground Input Power Supply Ground Input Power Supply Voltage DC Input / Frame Solid/Stranded Wire: 12-24 awg (2.5-0.2mm) Strip length: 0.28”...
  • Page 4: Model 2 Specifications

    Wiring: Model 2 MODEL 2 SPECIFICATIONS Digital DC Input Analog Inputs, Medium Resolution 12 including 4 configurable HSC Number of Channels Inputs per Module inputs Input Ranges 0-10VDC, 0-20mA, 4-20mA Commons per Module Safe Input Voltage -0.5V to 12V Input Voltage Range 12VDC / 24VDC Range Absolute Max.
  • Page 5: Wiring: Inputs And Outputs

    XL4/XL4 Prime: 3.0 - 4.0 in-lbs (0.34 - 0.45 N-m) tions, the state of the input is reflected in registers %I1 – EXL6/XL6 Prime: 3.0 - 4.0 in-lbs (0.34 - 0.45 N-m) %I12. EXLW/ XLW Prime: 3.0 - 3.5 in-lbs (0.34 - 0.40 N-m) XL7/XL7 Prime: 3.0 - 3.5 in-lbs (0.34 - 0.40 N-m)
  • Page 6: J1 Wiring - Digital In / Analog In

    Wiring: Model 2 J1 Wiring - Digital In / Analog In Wiring Details Solid/Stranded Wire: 12-24 awg (2.5-0.2mm2). Strip Length: 0.28” (7mm). Torque, Terminal Hold-Down Screws: 4.5 – 7 in-lbs (0.50 – 0.78 N-m). BUILT-IN I/O The I/O is mapped into OCS Register space, in three sep- arate areas –...
  • Page 7: Communications

    COMMUNICATIONS Serial Communication Dip Switches MJ1/2 Serial Ports MJ1/2 Independent Serial Ports MJ1: RS-232 w/Full Handshaking MJ2: RS-485 Half-Duplex MJ1 PINS MJ2 PINS SIGNAL DIRECTION SIGNAL DIRECTION DIP Switches NAME FUNCTION DEFAULT GROUND GROUND MJ3 RS-485 ON = +5V @ +5V @ Termination Terminated 60mA...
  • Page 8: Dimensions & Installation

    Ethernet port and CAN port as required. * +/- 0.1mm cutout tolerance Installation Information The EXL6/XL6 Prime utilizes a clip installation method to ensure a robust and watertight seal to the enclosure. Please follow the steps below for the proper installation and operation of the unit.
  • Page 9: Safety & Maintenance

    This device must accept any interference received, includ- ing interference that may cause undesired operation. Technical Support North America 1 (317) 916-4274 (877) 665-5666 www.hornerautomation.com techsppt@heapg.com Europe +353 (21) 4321-266 www.hornerautomation.eu technical.support@horner-apg.com Page 9...
