Invicta Lithium Xero
SNLX - User Manual
SPB Sydney Office: 2/28 Prime Drive, Seven Hills New South Wales, 2147
SPB Melbourne Office: 3/35 Dunlop Road, Mulgrave, Melbourne, VIC, 3170
SPB National Head Office: 1 Ant Road, Yatala, Brisbane, QLD 4207
T
1300 001 772
E
info@spb.net.au
LITHIUM
BATTERIES
W
spb.net.au
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Invicta Lithium Xero SNLX
Summary of Contents for Invicta Lithium Xero SNLX
- Page 1 INVICTA LITHIUM BATTERIES Invicta Lithium Xero SNLX - User Manual SPB Sydney Office: 2/28 Prime Drive, Seven Hills New South Wales, 2147 SPB Melbourne Office: 3/35 Dunlop Road, Mulgrave, Melbourne, VIC, 3170 SPB National Head Office: 1 Ant Road, Yatala, Brisbane, QLD 4207 1300 001 772 info@spb.net.au...
- Page 2 INVICTA LITHIUM BATTERIES Contents Warnings For Operation Tips For Operation Battery Appearance Box Contents Battery Installation Charging Your Battery Setting Up A Parallel or Series System Wired System Connection BT System Connection Communication Device Connection Battery Recycling Transportation and Storage...
-
Page 3: Warnings For Operation
INVICTA LITHIUM BATTERIES Welcome to your new Invicta LIthium Xero LiFePO4 Battery. Please read the instructions and warning on this card carefully to ensure you get the most out of your battery. Warnings For Operation • Read this manual before use •... -
Page 4: Tips For Operation
• To activate communication device - Ensure that the reset button is press and held for 20seconds. Refer to Communication section • Download Invicta Legion App for Battery Monitoring, Wired Parallel/Series setup, and Communication Device setup. Refer to Invicta Legion Application Section •... - Page 5 INVICTA LITHIUM BATTERIES Battery Appearance Heat Sink Pole Terminal Display Panel Power Switch Label Handle Comms. Port Ventilation Valve Mounting Feet Heat sink: The heat sink is a cooling component that benefits the battery life. At the same time, the heat sink is a hot decoration that cannot be touched by hand during battery use to avoid burns.
- Page 6 INVICTA LITHIUM BATTERIES Battery Power Switch: The battery power switch is used to turn the battery on or off. When the battery is in the ON state, it indicates that the battery BMS is in a normal state and can Label: During use, matching the corresponding charger and loading according to the label parameters is essential to avoid battery failure.
-
Page 7: Box Contents
INVICTA LITHIUM BATTERIES Communication Port: There are two communication ports: one is Link in, and the other is Link out. Pay attention during use. Pressure relief valve: The waterproof grade is IP67 because the battery is heating during charging and discharging, which leads to thermal expansion. Adding a pressure relief valve can prevent the air pressure inside the battery box from rising, resulting in dangerous accidents. -
Page 8: Battery Installation
Wait upto 15 seconds for batteries to complete self check and turn on • turn on accessories • Open the Invicta Legion Application - ensure no protection are active • If you wish to change to name of your battery the password is 1234. Please record the serial number before doing this •... -
Page 9: Charging Your Battery
INVICTA LITHIUM BATTERIES Charging Your Battery • Always use a battery charger with a lithium profile that does not exceed the charging specifications of the battery • Charger must not contain Sulphation/Equalisation setting. If so then this needs to be turned off. - Page 10 = half the rated capacity of the battery * d). Before connecting the batteries in series and parallel, the batteries should be fully charged and balanced. You can check whether the batteries are balanced by using the Invicta Legion Application Important Information Before connecting in series or parallel, ensure the batteries are off.
- Page 11 Extension cables are available for purchase To set up a parallel or series connection you will need to download the Invicta legion Application Follow the steps in the following pages refering to the connection method you...
- Page 12 This is the preferred method when possible. To set up a Wired system please follow the steps below. Connect battery-to-battery Link cables. Only use approved Invicta Link Cables for battery-to-battery connection. Battery 1 - Link Out > Battery 2 - Link In Battery 2 - Link Out >...
- Page 13 INVICTA LITHIUM BATTERIES Open Invicta Legion Application and press Wired System connection Press the + sign and set the system name, voltage platform, series or parallel connection and quantity of batteries in the system. Max Configuration - S = Series / P = Parallel...
- Page 14 See Wired System Connection for this method To set up a BT system please follow the steps below. Open Invicta Legion Application and click BT System connection Click the + sign and set the system name, voltage platform, series or parallel connection and quantity of batteries in the system.
- Page 15 INVICTA LITHIUM BATTERIES Communication Device Connection Setup Use this connection method to set up a communication device such as a Victron Cerbo GX. Ensure you have the right cables to connect to the battery. You may need our battery to inverter cable which is CAN-to-RJ45.
-
Page 16: Battery Recycling
Warranty Invicta has a 7-year full replacement warranty when installed in an approved application and when instructions in this manual have been followed. Please refer to your warranty card or invictalithium. com.au and register your battery to ensure your battery is in an approved application. A copy of the warranty statement can be found at www.invictalithium.com.au/warranty-statement/.
