  • Page 1 INVICTA LITHIUM BATTERIES Invicta Lithium Xero SNLX - User Manual SPB Sydney Office: 2/28 Prime Drive, Seven Hills New South Wales, 2147 SPB Melbourne Office: 3/35 Dunlop Road, Mulgrave, Melbourne, VIC, 3170 SPB National Head Office: 1 Ant Road, Yatala, Brisbane, QLD 4207 1300 001 772 info@spb.net.au...
  • Page 2 INVICTA LITHIUM BATTERIES SPB Sydney Office: 2/28 Prime Drive, Seven Hills New South Wales, 2147 SPB Melbourne Office: 3/35 Dunlop Road, Mulgrave, Melbourne, VIC, 3170 SPB National Head Office: 1 Ant Road, Yatala, Brisbane, QLD 4207 1300 001 772 info@spb.net.au...
  • Page 3 INVICTA LITHIUM BATTERIES SPB Sydney Office: 2/28 Prime Drive, Seven Hills New South Wales, 2147 SPB Melbourne Office: 3/35 Dunlop Road, Mulgrave, Melbourne, VIC, 3170 SPB National Head Office: 1 Ant Road, Yatala, Brisbane, QLD 4207 1300 001 772 info@spb.net.au...
  • Page 4 INVICTA LITHIUM BATTERIES Safety 1.1 Statement: Please read this manual carefully before installation, operation, and maintenance, and pay attention to various warning signs and statements on the equipment. After reading this manual, please keep it safe for future reference. 1.2 Specification: This manual’s contents using the following symbols should be paid special attention to during operation.
  • Page 5 INVICTA LITHIUM BATTERIES Battery operation: • Prohibit connecting batteries to different types of batteries. • Do not use faulty or mismatched chargers to charge the battery. • Follow the environmental conditions specified in the product specification. • If the battery is found to be deformed, abnormally hot, or emitting an odour, immediately cut off the power and stop using it.

  • Page 6: Installation

    Screw Introduction to Invicta Lithium XERO Batteries 3.1 Main Features: Invicta Xero is a LifePO4 chemistry which ensures exceptional safety and extended lifespan. It boasts high reliability, maintaining consistent performance across a broad temperature range. The battery’s enhanced heat dissipation allows for prolonged high-current charging and discharging.
  • Page 7 INVICTA LITHIUM BATTERIES 3.2 Product Appearance: Heat sink: The heat sink is a cooling component that benefits the battery life. At the same time, the heat sink is a hot decoration that cannot be touched by hand during battery use to avoid burns.
  • Page 8 INVICTA LITHIUM BATTERIES be charged, discharged, and connected to Bluetooth; when the battery is in the OFF state, it indicates that the battery is in a shutdown state, and cannot be charged or discharged, and cannot connect to the battery Bluetooth; The battery enters a sleep state. Placing the switch in the OFF state can reduce BMS power consumption when the battery is not used for a long time.
  • Page 9 INVICTA LITHIUM BATTERIES Usage method: • When using the battery for the first time, place the battery power switch in the ON position. • Short press the reset button for 1s to indicate battery SOC. The LED will be on for 10s.
  • Page 10 INVICTA LITHIUM BATTERIES Pressure relief valve: The waterproof grade is IP67 because the battery is heating during charging and discharging, which leads to thermal expansion. Adding a pressure relief valve can prevent the air pressure inside the battery box from rising, resulting in dangerous accidents.
  • Page 11 INVICTA LITHIUM BATTERIES Series and Parallel Connection of Batteries 4.1 Introduction: The Xero battery allows multiple batteries to be connected in series or parallel and simultaneously in series and parallel. This allows for the assembly of different voltage systems and the expansion of battery system capacity. For example, four 12.8V200Ah batteries can be connected in series and parallel to form a 25.6V400Ah battery system.
  • Page 12 INVICTA LITHIUM BATTERIES Communication Cable Positive Power Cable Negative Power Cable Parallel example: 2 x 12.8V100Ah System voltage: 12.8V System capacity:100Ah + 100Ah = 200Ah 4.3 Series Usage: A maximum of 4 batteries can be used in series. Before connecting the batteries in series, use a multimeter to test the voltage between the positive and negative terminals of the battery.
  • Page 13 CAN bus. This allows for communication between the battery and the load or charger, making it more efficient to use the battery. This is also beneficial for understanding battery faults. If you have more questions about the CAN bus, please get in touch with Invicta Lithium for technical support.
  • Page 14 INVICTA LITHIUM BATTERIES Communication line connection method: For normal battery operation, the CAN bus function is not mandatory. The battery can automatically operate and protect itself; it does not require any CAN bus communication or external devices (such as external controllers) or other CAN bus connected batteries to operate. Retain the two black covers installed on the two M12 connectors to protect them from environmental influences when not in use.
  • Page 15 INVICTA LITHIUM BATTERIES • Matching Address: After pressing the host battery1 reset button for 10 seconds, the indicator light will start running. After all the indicator lights are off, it means that the internal address allocation of the battery is completed; Attention: The...

  • Page 16: Charging Requirements

    5.2 Photovoltaic Charging: Check if the solar regulator you plan to use has a dedicated lithium charging setting meeting the above requirements. INVICTA LITHIUM Xero series batteries can be charged using a solar regulator without lithium charging settings, but it must be set to charge no more than 58.4V (4 batteries in series, with a maximum charging voltage of no more than 14.6V...

  • Page 17: Battery Recycling

    14.6V for a single battery), and then it must be turned off after the INVICTA LITHIUM XERO series battery is fully charged. After the battery is fully charged, please switch to the recommended floating voltage.
  • Page 18 INVICTA LITHIUM BATTERIES Warnings and Reminders Please carefully read the battery specifications or instructions before use. Improper use may cause the battery to heat up, catch fire, rupture, damage, or decrease capacity. Sealed Performance Batteries Pty Ltd. shall not be responsible for any accidents caused by not following our operating instructions.

  • Page 19: Warranty

    BATTERIES Warranty Invicta has a 7-year full replacement warranty when installed in an approved application and when instructions in this manual have been followed. Please refer to your warranty card or invictalithium. com.au and register your battery to ensure your battery is in an approved application. A copy of the warranty statement can be found at www.invictalithium.com.au/warranty-statement/.
  • Page 20 INVICTA LITHIUM BATTERIES SPB Sydney Office: 2/28 Prime Drive, Seven Hills New South Wales, 2147 SPB Melbourne Office: 3/35 Dunlop Road, Mulgrave, Melbourne, VIC, 3170 SPB National Head Office: 1 Ant Road, Yatala, Brisbane, QLD 4207 1300 001 772 info@spb.net.au...
