TOWER FAN
PFZ42R0APK
Warning Notice: Before using
this product, please read this
manual carefully and keep it for
future reference. For additional
support, please call customer
service at 1-866-646-4332.
The design and specifications are
subject to change without prior
notice for product improvement.
Consult with your dealer or
the manufacturer for details.
OWNER'S MANUAL
EN
PFZ42R0APK
pelonis.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PFZ42R0APK and is the answer not in the manual?

Questions and answers

Summary of Contents for Pelonis PFZ42R0APK

  • Page 1 OWNER’S MANUAL TOWER FAN PFZ42R0APK Warning Notice: Before using this product, please read this manual carefully and keep it for future reference. For additional support, please call customer service at 1-866-646-4332. The design and specifications are subject to change without prior notice for product improvement.
  • Page 2: Table Of Contents

    OWNER’S MANUAL SAFETY PRECAUTIONS ..................... 1 IMPORTANT INSTRUCTIONS ..................2 PART NAMES ........................ 5 SPECIFICATIONS ......................5 HOW TO ASSEMBLE ....................6 ..................8 OPERATING INSTRUCTIONS LED DISPLAY ....................... 10 AUTOMATIC SHUTDOWN FUNCTION ..............10 REMOTE CONTROL ..................... 11 CLEANING MAINTENANCE ..................12 TROUBLESHOOTING ....................
  • Page 3: Important Instructions

    IMPORTANT INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS CAUTION 1. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 4 IMPORTANT INSTRUCTIONS (cont.) WARNING 1. If the supply cord is damaged, it must be replaced by manufacturer or its service agent or a similarly qualified person in order to avoid a hazard. 2.To protect against the risk of electrical shock, do not immerse the unit, cord or plug in water or other liquid.
  • Page 5 IMPORTANT INSTRUCTIONS (cont.) WARNING a) “Do not operate any fan with a damaged cord or plug. Discard fan or return to an authorized service facility for examination and/or repair.” b) “Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar coverings. Do not route cord under furniture or appliances.
  • Page 6: Part Names

    All the pictures in this manual are for explanation purposes only. Any discrepancy between the real object and the illustration in the drawing shall be subject to the real model. SPECIFICATIONS MODEL Rated Voltage Frequency Power PFZ42R0APK 120V~ 60Hz Page 5...
  • Page 7: How To Assemble

    HOW TO ASSEMBLE NOTICE Please place the machine on the packing foam or other soft surfaces and invert it to avoid scracthing a mark when install the base. 1. Take out the two parts of the pole from packing box. Assemble two parts A and B of pole together as Fig 1.
  • Page 8 HOW TO ASSEMBLE 3.Take out the two parts of base from packing box. Insert the two poles of part C into two holes of part D, and insert the two poles of part D into two holes of part C to assemble the base as Fig 3. Fig 3 4.Position base to the smaller end of pole, turn the base counterclockwise until hearing a click voice and boundary of pole align with boundary of...
  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS Baby Mode Oscillation Mode Timer Speed Power Please place the fan on a stable, flat surface. Plug the cord set into a 120V~ electrical outlet, then listen for a “beep” sound to confirm that the fan has been successfully connected to the power supply. POWER Touch the “POWER”...
  • Page 10 OPERATING INSTRUCTIONS -NATURAL MODE The natural mode offers 6 wind speeds (1, 2, 3, 4, 5, 6). In natural mode, the fan will automatically cycle through different circulations based on the wind speed you select. -SLEEP MODE Sleep mode offers 6 wind speeds (1, 2, 3, 4, 5, 6). When in sleep mode, the fan will gradually decrease speed every 30 minutes until it reaches speed 1, providing a comfortable airflow during sleep.
  • Page 11: Led Display

    LED DISPLAY The display will automatically turn off after 30 seconds of no operation, the display will light up again once any key is touched. 1/2/3 Wind Speeds When the wind speed is set to 1/2/3, Sleep Mode this light will turn on. Baby Mode Timer Natural Mode...
  • Page 12: Remote Control

    REMOTE CONTROL • The buttons on the remote controller such as OSCILLATION, ON/OFF, BABY, DECREASE or INCREASE, TIMER, MODE, have identical functions to their corresponding keys on the unit. • The remote control operate effectivelywithin 16 feet in the front of the product and within an angle of 30°.
  • Page 13: Cleaning Maintenance

    CLEANING MAINTENANCE • Be sure to unplug from the electrical supply source before cleaning. • Please use a damp cloth or sponge for general cleaning. • To remove more persistent dirt with a cloth that dampened with warm soapy water, and thoroughly to remove soap film with a damp cloth. Do not use any solvents (such as thinners), as these may damage the plastic casing.
  • Page 14: User Servicing Instructions

    USER SERVICING INSTRUCTIONS a)Grasp plug and remove from the receptacle or other outlet device. Do not unplug by pulling on cord. b)Open fuse cover. Slide open fuse access cover on top of attachment plug towards blades.(Fig. c)Remove fuse carefully. Insert the tip of your tool into fuse slot(close with the terminal), then pry the fuse gradually and slowly, but do not overexert.
  • Page 15 SERVICE AND SUPPORT In the event of a warranty claim, questions, comments or if service is required for this product, please contact us at the following: Toll Free: 1-866-646-4332 Email us at: customerservice@supportuscenter.com Midea America Corp. Parsippany, NJ 07054 For your records, staple your sales receipt to this manual and record the following: DATE OF PURCHASE: PLACE OF PURCHASE: (STAPLE SALES RECEIPT HERE)
  • Page 16 ONE (1) YEAR LIMITED WARRANTY • Please read all instructions before attempting to use this product. Midea America Corporation warrants as limited herein to the original purchaser of retail thateach new Fan, shall be free of defects in material and workmanship for aperiod of one (1) year from the date of original purchase.
