SWIMMING POOL MONITORING SYSTEM
Installation Manual
Read carefully and keep for future reference. Please study the manual closely, before
1 - The content of this booklet may be modified without prior notice.
2 - Printing restrictions mean that the displays shown in this booklet may vary from
those actually appearing on the product.
3 - The content of this booklet may not be reproduced in any way without the
manufacturer's permission.
To access the installation menu, press
simultaneously on
-
C
M5-M9
bringing the system into service (Version 5.31)
and
C
- -
- -
OK
1
Advertisement
Table of Contents
Related Manuals for Klereo kompact M5
Summary of Contents for Klereo kompact M5
- Page 1 SWIMMING POOL MONITORING SYSTEM To access the installation menu, press simultaneously on Installation Manual M5-M9 Read carefully and keep for future reference. Please study the manual closely, before bringing the system into service (Version 5.31) 1 - The content of this booklet may be modified without prior notice. 2 - Printing restrictions mean that the displays shown in this booklet may vary from those actually appearing on the product.
-
Page 2: Table Of Contents
3.7. Installing of cans and injections of liquid chemicals .......... 15 3.8. Installing the solenoid valve for Kompact with Bromine tablets ...... 17 3.9. Installing the cell with Klereo Salt Chlorinator ............ 18 Electrical Installation 19 4.1. Connecting the sensors ..................19... - Page 3 4.2. Positioning the pressure sensor ................20 4.3. Connecting the klereo Kompact power supply ........... 20 4.4. Connecting the inputs outputs ................22 4.5. Connecting Filtering ....................25 4.6. Connecting lighting ....................26 4.7. Connecting the Kompact M9 control unit to the multi-sensor box....27 4.8.
- Page 4 6.8. Programming the antifreeze function (if optional) ..........47 6.8.1. Pairing procedure ......................... 47 6.8.2. Activating the antifreeze function ....................48 6.8.3. Setpoint and frost cycle settings ....................48 6.9. Equipment set-up ....................49 6.10. Outputs Assignment .................... 50 6.11. Designation of the Auxiliary outputs ..............
-
Page 5: Klereo Kompact Models Description
Oxygen (which is managed by the basic kit), or liquid Chlorine or Salt Chlorinator or Bromine. There are two ranges of Kompact: the Kompact M5 (5 connections) with the possibility of controlling 5 equipment and the Kompact M9 (9 connections). Kompact allows controlling also auxiliary outputs: lighting, cleaning robot, whirlpool, cc swim, garden lighting, water fountain, and so on. -
Page 6: Disinfectant Options
Optional: Hydraulic kit for Bromine with 2 collars and 4 unions • For Ø50mm (Ref : KL20-KH50) For Ø63mm (Ref: KL20-KH63). 1.2.3. Klereo salt chlorinator It is composed of: • A Salt Chlorinator cell • An electronic control box unit Figure 4. -
Page 7: Kompact Options
1.3.2. The remote Display Remote display is possible on Klereo Kompact + thanks to the Klereo Pad control (Ref.: KL20-AF1 for the Kompact+ M5 range or KL21-AF1 for the Kompact+ M9 range). The PAD is the interface between the user or installer and the Klereo Kompact + system. -
Page 8: Detection Of Empty Tank
An amperometric sensor that measures the free chlorine level in the pool (M9 compatible only) regulates the liquid chlorine injection. 1.3.8. SPA adaptation Klereo Kompact+ can be adapted for spas. In this case, we integrate 0.4l/h metering pumps to be able to treat small volumes of water 1.3.9. Large pool adaptation Dosing pumps with flow rates ranging from 5 l/h to 15 l/h allow the treatment of large basins. -
Page 9: Usage Limitations
In some cases, Klereo may not be able to run the heating system correctly (consult Klereo). When the disinfectant is a salt chlorinator, it is very important to install a –... -
Page 10: Installation Diagram
3.2. Installation Diagram Existing electrical box The connection of the sensors to the Kompact Light control M9 control unit is made on the multi-sensor box. filtration control Filtration Sensors Filter Heating pump Salt Chlorinator Liquide Chlorine Brome pH tank Actif Oxygene Figure 11. -
Page 11: Hydraulic Accessories Positioning
3.3. Hydraulic accessories positioning 3.3.1. The Tube 5 probes The Kit is supplied with a 5 probe transparent tube. The probe holders are supplied with an O-ring and can be screwed without using Teflon. The tube has a diameter of 63mm and is supplied with 2 ×50mm adapters. Figure 12. -
Page 12: T Shape Collar (Optional)
3.3.4. T shape collar (optional) Cut the pipe to a length of 55 mm for Ø 50 mm T shape collars and 65 mm for Ø 63 mm ones. Figure 15. T shape collar 3.3.5. Chamber of analysis (optional) The chamber is screwed onto the wall. Read carefully the installation manual to ensure correct mounting and probe installation. -
Page 13: Installing The Flow Switch
WARNING: Adjust the positioning of the probe holder so the end of the probe does not touch the bottom of pipe, which the direction of joints and washers should be Figure 18. Assembly of probe-holders and water temperature sensor Probe/ Probe/ IMPORTANT sensor... -
Page 14: Connecting The Pipes Of The Metering Pumps
Recommendations: Technical specifications: - Tightening torque : 7.5 N.m Pallet flow switch with magnetic back - It is important to respect the installation position direction mentioned arrow NORYL body representing the direction of water PA6 female connection rotating G ¾ circulation. -
Page 15: Installing Of Cans And Injections Of Liquid Chemicals
Check that the holding collars used to inject the products are sealed. The room must be ventilated. Keep a minimum distance of 1 m between the tanks and the Klereo components, to avoid fumes from the products damaging the system. - Page 16 The holding collars used for injecting products must be placed at the end of the filtering circuit before the backflow. Maximum distances between Klereo control box unit and the tanks or the injection points are 2m maximum. The minimum distance between two injection points is 40cm . A drawing up cane with empty tank level detector is optional.
-
Page 17: Installing The Solenoid Valve For Kompact With Bromine Tablets
3.8. Installing the solenoid valve for Kompact with Bromine tablets The Kompact for Bromine regulates disinfection by opening a solenoid valve letting the water going through a brominator filled with bromine or a chlorinator filled with Chlorine tablets. There are 2 possibilities to install the Bromine regulation kit. Respect the direction identified by the arrow on the Figure 27. -
Page 18: Installing The Cell With Klereo Salt Chlorinator
Brominator manual). Install manual valves at the by-pass level for easy maintenance. 3.9. Installing the cell with Klereo Salt Chlorinator Allow a maximum distance of 1.5m between the cell and the control box unit (it is actually the length of the cable between the 2 units). Connecting the cell is done in Ø... -
Page 19: Electrical Installation
Water temperature sensor Figure 32. Connecting the sensors to the kompact M5 and M9 control box unit For water temperature sensor connect the bleu wire to B, yellow wire to J, green wire to V and red wire to R... -
Page 20: Positioning The Pressure Sensor
4.2. Positioning the pressure sensor Klereo is suitable for conventional installations using sand or cartridge filters. The pressure sensor measures positive pressures and is mounted near or in place of the existing pressure gauge. The pressure sensor can be screwed directly onto the filter (use Teflon tape for sealing). - Page 21 Connection Phase-Neutral- Groung Earth connection Use a screwdriver to remove the pre-cut cover of the cable glands. Figure 36. Connection of the power supply of the Kompact M9 Chlorine, Bromine and Active Oxygen unit Connect the 2 cell cables L = Line N = Neutral = Ground Gas detection G...
-
Page 22: Connecting The Inputs Outputs
They should not come out. Figure 38. Cabling the wires on the Klereo Kompact control box unit The control box unit must be installed into the technical room in order to be in a position to connect the other pool equipment. - Page 23 Ph = Line, N = Neutral, Couv = pool cover , Floc = Flocculent Kompact M5 is equipped with 5 outputs and the Kompact m9 with 9 outputs: 1. The filtering output V1 and V2 must be connected to the swimming pool control box unit (refet to §...
- Page 24 5. The Inputs I and J (and G and H in the case of the Kompact M9) is supplied with 220V signal. It allows the lighting or filtration to be controlled externally to Klereo (see § input configuration).
-
Page 25: Connecting Filtering
5A. Make sure that the electrical circuit is equipped with necessary protections meeting local standards. IMPORTANT Set the filtering switch in Auto mode. Never connect the filter pump directly to Klereo Kompact control box unit V1-V2 inputs. Figure 41. Example of connection to an existing swimming pool control box unit. -
Page 26: Connecting Lighting
Figure 42. Example of lighting connection to an existing swimming pool control box unit Additional possible connections for the Aux B double relay output of Kompact M5 The following diagram shows both types of wiring according to the auxiliary equipment amperage. -
Page 27: Connecting The Kompact M9 Control Unit To The Multi-Sensor Box
4.7. Connecting the Kompact M9 control unit to the multi-sensor box Water temperature Pressure sensor Ph probe Flow sensor Flow sensor Amperometric free chlorine sensor (4-20mA) Drill the Kompact M9 control unit to pass the cable. Figure 44. Connecting the multi-sensor box Connect the wires as follow: - Connection of the multisensor box to the control unit COFFRET... -
Page 28: Connection Of The Salt Chlorinator
Connection of the Klereo 3 salt chlorinator 4.8.2. Use of anotherchlorinator With another Salt Chlorinator, different from Klereo , you can connect its power supply to Klereo Kompact control box unit R-RN terminals. The electrical consumption must be less than 2,5A. -
Page 29: Connecting The Heating System
When using a heating device, it must be controlled by output P and Q. It is a relay contact (normally open 10A max). In the case of the Kompact M5, this output is default set up to control auxiliary equipment Aux A. To activate the heating menu, change the output assignment (refer to §: outputs assignment)). -
Page 30: Contacts Inputs
not manage filtering. Please contact after sales service department for further information on this working mode. • Lighting modes are: o Either « two-way switch » mode when you wish to keep an existing switch (to be connected to I-J input). o or «... -
Page 31: Klereo Connect
Figure 51. connecting the display holder 5. KLEREO CONNECT The Klereo Connect option (Ref: KL60-C2) allows remote monitoring of the pool. A simple interface allows you to visualize the parameters and control the pool equipment. 6. START UP 6.1. Klereo display 6.1.1. - Page 32 2. pH and water temperature values 3. filtration area 4. Programmed mode and filtration status 5. Access to the Klereo menu 6. Switching filtration ON or OFF manually (maintenance mode) An alternative home screen is available. To use it, simply go to the menu:...
-
Page 33: Kompact M9 Interface
6.1.2. Kompact M9 Interface Lighting and filtration control indicators To access the installation menu, press Status light simultaneously on of filtration display Navigation key Figure 54. Kompact M9 home screen The filtration indicator light is : Steady green when the filtering is permanently ON (manual ON) Flashing green when the filtering is on for a cycle (regulated / time slots or external command) Flashing red when filtering is not possible because of a security or a fault. -
Page 34: Main Menu
Direct access to « system status » statement Browse key When the right arrow is pressed, a summary of the system status is displayed on the Klereo screen. This provides a summary of the filtration, heating and treatment settings (pH and disinfectant). 6.2. Main menu:... -
Page 35: Interface
Resume frost (optional)* Mi-day filtering* *Menus accessible from the service interface For the best Klereo regulation performance, it is very important to enter the right characteristics: pool water volume and the filter pump flow rate. 6.4.1. Filtration modes Figure 55. -
Page 36: Filtering Parameters
The filtration mode can be: • set in regulated mode, i.e. the filtration time is automatically calculated by Klereo according to the temperature, pool volume and pump flow rate. In addition, an "advanced" sub-menu allows you to configure two functions (see next paragraph: §filtration settings) -
Page 37: Antifreeze Function Management
For accessing a sub-menu or confirming an action Cancel or return to previous menu 6.5. Regulations test Now that all the Klereo Kompact components are installed, the various regulations must be checked. Test heating (if installed), the pH dosing pump and the disinfectant (dosing pump, solenoid valve or Salt Chlorinator). -
Page 38: Water Treatment
WARNING : When activating the dosing pumps, check that the liquid is circulating in the right direction and up to the pool's filtration circuit. 6.6. Water treatment 6.6.1. Balanced PH Klereo Water treatment Balanced Ph. This menu indicates the balanced pH by measuring and entering the TAC (alkalinity) and TH (hardness) values. -
Page 39: Ph Correcting Agent Set-Up
If the measured pH value is higher than the set pH setpoint, in the case of a correction with pH minus, Klereo will control the pH corrector injection in order to reach the set point. In the case of a treatment with pH plus, if the measured pH value is lower than the pH set point, klereo will command the addition of pH corrector. -
Page 40: Disinfectant
Klereo2 or 3 Salt Chl. Other Salt Chl. Active Oxygen Bromine None You can access this menu to select the disinfectant that will be used to treat the pool: chlorine, bromine... For a non-Klereo salt chlorinator, select "other Salt Chlor". - Page 41 In the case of active oxygen treatment, you will have the following options: Klereo Water traitement Disinfectant Regulated stop Boost treatment Fixed volume In the case of a treatment with a klereo salt chlorinator, you will have the following options: Klereo Water traitement Disinfectant Regulated ORP.salt Filt Sync. Stop...
- Page 42 ORP probe and the programmed ORP target value while taking into consideration the pool characteristics. If the value measured by the ORP probe is below the target value, Klereo will inject disinfectant and will stop injection when the target value is reached.
- Page 43 Figure 64. Modifying the regulated mode When the regulated active oxygen mode is selected, it is possible to choose the day of injection of the disinfectant. To do this, use the menu: Klereo Water Advanced Injection mode Daily...
- Page 44 Klereo Water Advanced Injection mode Start filtering traitement Processing Distributed filtering End Filtering The "Distributed filtering " mode is the default mode. In this case the amount of active oxygen is distributed over 1/3 of the filtering time. This mode allows a gentle treatment but can create an addictive effect of water and the appearance of microalgae.
- Page 45 Klereo Water treatment Salt Chlorinator parameters This menu is only shown when a Klereo slat Chlorinator has been installed, allowing access to features specific to the use of this Salt Chlorinator. a) Hybrid set up Klereo offers a Hybrid salt chlorinator (patented system) that combines salt chlorination...
-
Page 46: Reset Daily Treatment
Salt Chlorinator equipment. d) ORP security There is an adjustable ORP security when using a Salt Chlorinator treatment (whatever the model, Klereo or another brand) in order to stop Chlorine production when reaching a maximum value. Default value is 800mV. -
Page 47: Reset Of Consumption
10 min (pH) and 30 to 90 min (ORP). 6.7.2. Water temperature calibration Sometimes, the water temperature given by the Klereo sensor may differ from the one given by a thermometer inside the pool or another pool equipment. It is possible to calibrate the Klereo sensor to display the same temperature values. -
Page 48: Activating The Antifreeze Function
6.8.2. Activating the antifreeze function Thanks to your air temperature sensor, you can configure the Frost protection function, which is very useful in case of active wintering. To activate the Frost Protection function, go to the following menu: Klereo Parameters Set up Equipments Check the "Frost function"... -
Page 49: Equipment Set-Up
Frost function: by marking this option, you activate it and get access to its set-up (refer to 6.10). Klereo filtering: this function is selected when delivered. Indeed, it is Klereo default piloting filtering. However an external device can also control filtering: in that case... -
Page 50: Outputs Assignment
If Klereo filtering is disabled, water treatment will only be ON either when the Klereo control box detects a water flow or when there is 220V detected on input I-J (Klereo control box unit power supply input). In that case: Connect the filter pump 220V on the input I-J and set-up the 220V input in «... -
Page 51: Designation Of The Auxiliary Outputs
Configuration of the Kompact M9 filtering pump WARNING If you use variable speed pump, wiring of the electrical box must be changed (ask klereo the appropriate wiring diagram). Make sure that the control of the variable speed pump is connected correctly. If the pump is equipped with an ON/OFF or On/Off relay control input, do not forget to check the Pump ON/OFF box in the Pump menu. -
Page 52: Heating
6.13. Heating Important: in the case of a Kompact M5, it is necessary to assign the P-Q output for heating as above mentioned. To set up P-Q output to heating, go to menu: Klereo... -
Page 53: Type Of Heating
Use the display to go to the menu : Klereo Heating Heating target Figure 74. Heating temperature target value setting screen Set the heating equipment target value to the maximum so that it will always be above Klereo heating target value. -
Page 54: Prevent Heating
The heating hysteresis menu allows you to adjust the temperature delta between the pool water temperature and the setpoint set on Klereo from which your heating system will start up again to maintain the pool water temperature as well as possible. -
Page 55: Water Meter
6.15. Water Meter When installing a water meter, you must activate flow sensor 1 in the menu Klereo Parameters setup Sensor presence To be alerted in case of overconsumption, tick the box "overconsumption/Surconsom.". In this case an alert is triggered if a continuous water flow rate between 30 and 50 l/h is detected (default setting). -
Page 56: Input And Flow Switches Set-Up
Default selected when delivered. These two treatment priorities are inactive when Klereo is in “Eco mode”. Boost treat. priority: this option starts immediately the disinfectant boost treatment during 24h and therefore forces filtering. -
Page 57: Flow Switch Set-Up
• Not used 6.17.3. Inputs and flow switches status To check 220V (IJ terminal) input and flow switches status as well as empty tank level detectors (for pH and disinfectant) and pool cover when used. Klereo Parameters Tests / Installation Inputs status... -
Page 58: Selecting The Control Modes
Figure 78. Recurrence programming screens 6.19. Selecting the control modes Klereo Control modes Select with this menu: • Comfort mode will always favor water quality. Indeed, when filtering time is coming to an end, filtering will continue if one of the 3 parameters (pH, disinfectant and heating) has not reached its target value. -
Page 59: Maintenance
Before the pH probe is installed, let it submerged in a glass of tap water for at least 30 minutes. The pH probe must be calibrated every 6 months. For calibration go to the following menu: Klereo Maintenance PH calibration On the display unit, enter the pH calibration menu and run the procedures following... -
Page 60: Orp Probe Checking
30 minutes. The ORP probe must be checked when installed and each time the season starts. For calibration go to the following menu: Klereo Maintenance ORP Checking On the display unit, enter the ORP check menu and run the procedures following the... -
Page 61: Peristaltic Pumps
7.3. Peristaltic Pumps The santoprene tube inside the pump is the part to be protected during wintering. Draw clear water through to rinse the pipe and avoid premature deterioration. Activate the metering pump using the adequate menu on the display (refer to § regulations test in the Kompact installation manual), so that the roller is positioned as shown on the picture below. - Page 62 To set up in regulated Prevent filtering mode Skimming planning Set up the slots Regulated OFF Regulated ON Skimming Heating Pump speed settings Disinfect Lavage Closed cover Displaced cover Frost-free Night If heating present Night watch Fill in the value Frost target value Frost cycles (optional)
- Page 63 Klereo2 OR 3 Salt Chl. Other Salt Chlor. Active Oxygen Bromine None pH correcting agent pH minus pH plus None pH concentration* Treat. concentration* pH pump flow rate* *Submenus accessible in service Treat. pump flow mode rate* Boost treat. timelag* Injection mode Start filtering Distribution...
- Page 64 Total water meter Correct pH Disinfect RESET Flocculant Consumptions Filtration Heating Lighting Auxiliary 4 Force Filtering. Time slots Manual Adjustable frequency Timer Pulse Frequency Force Filtering Time slots Manual Adjustable frequency Filt. sync. for auxiliaries Timer Pulse Stop Aux (in case of other auxiliary) pH calibration ORP checking...
- Page 65 Chlorine (optional) Air temp (optional) Pressure Flocculant tank Flowmeter 1 Flowmeter 2 Equipments Indoor Pool Pool cover Pool cover polarity Frost function (optional) Klereo filtering Lighting Heating Auxiliary (if option) Outputs Relay P-Q assignment Heating settings assignem Aux A ents...
- Page 66 Flocculant deactivated) Aux A Aux A designation Allows selecting if auxiliary set up function associated with Aux A Advanced *ask Klereo support for functions definition Heating Type of heating Heating /Heatin g pump None Heating hysteresis Type of heating 0.1°C...
- Page 67 Multisensor Multi-Gen2 Tests / Installation Salt Chlor. test (if installed) Regulations test Input status Flow switches status Pool info Quick installation Reset Reset Display Reset control box Reset parameters Factory Settings Display Software version Control box update Display update USB operations...
