Internal Use Only http://biz.LGservice.com Portable Air Conditioner SVC MANUAL(Exploded View) GP100CE(TWC101ZBMK0) MODEL : CAUTION Before Servicing the unit, read the safety precautions in Standard SVC manual. Only for authorized service personnel. -
Page 3: Specification
1. Specification Models GP100CE 2.93 Cooling Capacity Btu/h 10,000 Heating Capacity Btu/h Electric Heater Capacity Btu/h Power Input Cooling/Heating 1,050 Running Current Cooling/Heating Starting Current Cooling/Heating c i r r e t e r r 2.79 Btu/h.W 9.50 Ø 1Ø / 115V / 60Hz r o t 97.1... -
Page 4: Piping Diagrams
2. Piping Diagrams Capillary Tube Heat Heat Exchanger Exchanger (Evaporator) (Condenser) Accumulator Compressor Service Manual 3... -
Page 5: Wiring Diagrams
3. Wiring Diagrams COMP CNWF CNRT DISP2 DISP1 4 Portable Air Conditioner... -
Page 6: Exploded View
4. Exploded View 264110 249950 731270 W0CZZA 567480 261704 W0CZZB 352380A 268711B W4810B 354210 554030 352380B 352113 552101 152500 435313 W4810A 35211A 752140 346810 152302A 266001 152302B 359012 352380B 349011 352380B 336610 237200 135312 267120 554160 268711A 130410 145200 W50060B W50060A 267110 147581... - Page 7 P/NO : MFL38891310 JANUARY, 2008...
