- Page 1 User Manual LCH-627-75B & LCH-627-90B...
-
Page 2: From The Manufacturer
From the Manufacturer Please read this user manual carefully before attempting to operate the appliance and keep it in a safe place for future reference. This appliance and its packaging are produced by processes that minimize waste and respect the environment. Please help us to continue this effort to protect the environment by using the appliance efficiently and dispose of the packaging in a responsible manner. -
Page 3: Cleaning, Maintenance & Service
Cleaning, Maintenance & Service It is very important to clean and maintain the grease filters regularly (at least once monthly) to improve its efficiency in eliminating heat and contaminated air in the kitchen. Heavy oil deposits is a fire hazard. Hood surface should be cleaned with soft cloth and non-corrosive detergent. - Page 4 3. Dimension Diagrams LCH-627-75B LCH-627-90B...
-
Page 5: Cleaning And Maintenance
10 minutes. The fan will automatically operate at high speed for 1 minute after the 10 minutes cleaning function. B.Touch control(LCH-627-75B/LCH-627-90B) LED screen ithin 10-15cm distance from the switch, wave once from left to right to turn on power (LED Wave A, W screen shows ”1”). - Page 6 (only in re-circulating model): Charcoal cannot be reused. They must be replaced with the appropriate types once a year or depending on the frequency of appliance usage. For this appliance to function effectively, regular maintenance is a must. Clogged filters restrict airflow and may cause the motor to overheat.
- Page 7 5. Installation Use suitable bolts to mount the appliance on a secure surface. The minimum distance between the supporting surface for the cooking vessels on the hob and the lowest part of the range hood. When the range hood is located above a gas appliance, this distance shall be at least 65 cm.
- Page 8 Way two: ⚫ Drill 4 holes of 6mm diameter at the bottom of the hanging cupboard ⚫ Put the one way valve on the cooker hood, then install the cooker hood on the bottom of the cupboard, tighten the hood with enclosed 4 screws. ⚫...
- Page 9 Air ventilation setting ⚫ Outdoor exhausting: Turn the adjuster to outdoor position(pic.7A), install the outlet, turn on the cooker hood, then the air will be vented from the outside outlet. ⚫ Recycling: the recycling mode with carbon filter ,Turn the adjuster to indoor position (pic.7B), install the outlet cover, turn on the cooker hood, then the air can be vented from the inside outlet.
- Page 10 Installation (Vent inside) If you do not have an outlet to the outside, exhaust pipe is not required and the installation is similar to the one show in section “Installation (Vent outside)”. Activated carbon filter can be used to trap odors. In order to install the activated carbon filter, the grease filter should be detached first.
-
Page 11: For The Installer
FOR THE INSTALLER 6. Safety Information 1. Electrical connection must be in accordance with the local standards and laws. 2. To ensure that the electrical supply in compliance with the appliance setting, otherwise, do not connect. 3. To ensure the power supply cord is free from any heat source or sharp objects. 4. - Page 12 Problems Possible Cause Action Check that the main switch is turned Not function No power supply Check that the plug is connected Aluminum grease filters clogged Clean the filters and replace when dry Poor airflow Charcoal grease filters clogged Replace charcoal filters with new sets Motor running but no Butterfly valve jammed Contact technician...
