OWNER'S MANUAL
MOTORCYCLE
YZF690/YZF690-U (YZF-R7)
Read this manual carefully
before operating this vehicle.
BEB-28199-E0
For your safety - pre-operation checks
1
2
3
4
5
6
7
8
9
10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YZF690-U and is the answer not in the manual?

Questions and answers

Related Manuals for Yamaha YZF690-U

Summary of Contents for Yamaha YZF690-U

  • Page 1: Table Of Contents

    Safety information OWNER’S MANUAL Description Instrument and control functions For your safety – pre-operation checks Operation and important riding points Periodic maintenance and adjustment Motorcycle care and storage Specifications Consumer information MOTORCYCLE Index YZF690/YZF690-U (YZF-R7) BEB-28199-E0...
  • Page 2 EAU81571 Declaration of Conformity: Hereby, YAMAHA MOTOR ELECTRONICS Co., Ltd declares that the radio equipment type, IMMOBILIZER, BEB-00 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://global.yamaha-motor.com/eu_doc/...
  • Page 3 Yamaha a reputation for dependability. Please take the time to read this manual thoroughly, so as to enjoy all advantages of your YZF690 / YZF690-U. The Owner’s Manual does not only instruct you in how to operate, inspect and maintain your motorcycle, but also in how to safeguard yourself and others from trouble and injury.
  • Page 4 Important manual information EAU10134 Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death.
  • Page 5 Important manual information EAU10202 YZF690 / YZF690-U OWNER’S MANUAL ©2022 by Yamaha Motor Co., Ltd. 1st edition, June 2021 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd. is expressly prohibited. Printed in Japan.
  • Page 6 Table of contents Safety information......1-1 For your safety – pre-operation Checking the throttle grip free checks ..........4-1 play..........6-17 Description ........2-1 Valve clearance......6-17 Left view ......... 2-1 Operation and important riding Tires ..........6-17 Right view........2-2 points ..........5-1 Cast wheels ........
  • Page 7 Table of contents Checking the steering ....6-30 Checking the wheel bearings ..6-30 Battery ...........6-31 Replacing the fuses.......6-32 Vehicle lights .........6-33 Replacing a license plate light bulb ..........6-34 Supporting the motorcycle....6-34 Troubleshooting ......6-35 Troubleshooting chart ....6-36 Motorcycle care and storage ..7-1 Matte color caution ......7-1 Care ..........7-1 Storage ..........7-3...

  • Page 8: Safety Information

    Safety information  Never operate a motorcycle with- pears to be very effective in reduc- EAU1028C out proper training or instruction. ing the chance of this type of Take a training course. Beginners accident. Be a Responsible Owner should receive training from a cer- Therefore: As the vehicle’s owner, you are re- tified instructor.
  • Page 9 Safety information  Many accidents involve inexperi- • Always signal before turning or Protective Apparel enced operators. In fact, many op- changing lanes. Make sure that The majority of fatalities from motorcy- erators who have been involved in other motorists can see you. cle accidents are the result of head in- ...
  • Page 10 Safety information  Do not run engine outdoors where Avoid Carbon Monoxide Poisoning When loading within this weight limit, All engine exhaust contains carbon engine exhaust can be drawn into keep the following in mind:  Cargo and accessory weight monoxide, a deadly gas.
  • Page 11 Yamaha accessories, which are avail- performed to your vehicle that change lightweight as possible and able only from a Yamaha dealer, have any of the vehicle’s design or operation should be kept to a minimum. been designed, tested, and approved characteristics can put you and others •...
  • Page 12 Safety information  Remove all loose items from the operator and may limit control ability, therefore, such accesso- motorcycle.  Check that the fuel cock (if ries are not recommended.  Use caution when adding electri- equipped) is in the off position and cal accessories.

  • Page 13: Description

    Description EAU10411 Left view 1. Battery (page 6-31) 9. Engine oil drain bolt (page 6-11) 2. Fuses (page 6-32) 10.Engine oil filter cartridge (page 6-11) 3. Seat lock (page 3-19) 11.Coolant reservoir (page 6-14) 4. Rebound damping force adjuster (page 3-24) 5.

  • Page 14: Right View

    Description EAU10421 Right view 3,4 3,5 1. Tool kit (page 6-2) 2. Fuel tank cap (page 3-16) 3. Spring preload adjuster (page 3-22) 4. Compression damping force adjuster (page 3-22) 5. Rebound damping force adjuster (page 3-22) 6. Front brake fluid reservoir (page 6-22) 7.

  • Page 15: Controls And Instruments

    Description EAU10431 Controls and instruments 1. Clutch lever (page 3-14) 2. Left handlebar switches (page 3-12) 3. Multi-function meter unit (page 3-6) 4. Main switch/steering lock (page 3-2) 5. Right handlebar switches (page 3-12) 6. Throttle grip (page 6-17) 7. Brake lever (page 3-14)

  • Page 16: Instrument And Control Functions

     Do not place near magnets. Yamaha dealer to have them re-regis-  Do not place near items that tered. 1. Code re-registering key (red bow) 2. Standard keys (black bow) transmit electrical signals.

  • Page 17: Main Switch/Steering Lock

    Instrument and control functions EAU10474 EAU84034 EAU73800 Main switch/steering lock LOCK All electrical circuits are supplied with The steering is locked and all electrical power and the vehicle lights are turned systems are off. The key can be re- on. The engine can be started. The key moved.

  • Page 18: Indicator Lights And Warning Lights

    2. Turn. then remain on until the engine is start- 7. ABS warning light “ ” ed. Otherwise, have a Yamaha dealer Push the key in and turn it to “OFF”. 8. Shift timing indicator light check the vehicle. 9. Immobilizer system indicator light “...
  • Page 19 Instrument and control functions light remains on after adding oil, or excessive/improper use of the mo- EAU91840 Malfunction indicator light stop the engine and have a Yamaha torcycle. To prevent this, observe (MIL) “ ” dealer check the vehicle. these precautions.
  • Page 20 3 keys to a Yamaha lizer system is still enabled.  Use extra caution to avoid pos- dealer to have the standard keys sible wheel lock during emer- re-registered.

  • Page 21: Multi-Function Meter Unit

    Instrument and control functions The multi-function meter unit is also EAU92981 EAU86831 Multi-function meter unit Speedometer equipped with a display brightness and The speedometer shows the vehicle’s shift timing indicator light settings traveling speed. mode. EWA12423 EAU87170 WARNING Tachometer Be sure to stop the vehicle before making any setting changes to the multi-function meter unit.
  • Page 22 If this occurs, have a 5. Use the “SEL” switch to set the Yamaha dealer check the vehicle. minutes. 6. Push the “RES” switch to confirm the setting.
  • Page 23 Instrument and control functions The multi-function display is equipped EAU93021 EAU86890 Quick shifter indicator “QS” (if Odometer with the following: equipped) The odometer shows the total distance  an odometer (ODO) traveled by the vehicle.  two tripmeters (TRIP 1 and TRIP 2) ...
  • Page 24 Instrument and control functions To reset the fuel reserve tripmeter, measurement units, hold the “SEL” EAU89192 Average fuel consumption display change the display to the fuel reserve switch until the measurement units tripmeter, and then hold the “RES” change.  “km/L”: the distance that can be switch until it is reset.
  • Page 25 Instrument and control functions  “AVE_ _._ MPG”: the average dis- If the message “HI” flashes, stop the tance that can be traveled on vehicle, then stop the engine, and let it When the temperature is below –9 °C, 1.0 Imp.gal of fuel. cool.
  • Page 26 Instrument and control functions 4. Push the “SEL” switch to confirm Shift timing indicator light Shift timing indicator light ON r/min the selected setting value and cy- The shift timing indicator light has 3 The shift timing indicator light can be cle to the next setting in the order settings: set between 6000 r/min and 12000...

  • Page 27: Handlebar Switches

    Instrument and control functions Shift timing indicator light bright- Right EAU1234R Handlebar switches ness The shift timing indicator light will Left come on and stay on until the setting is 1 1 1 1 1 1 confirmed. The brightness level of the light will change as the level is adjust- Use the “RES”...
  • Page 28 Instrument and control functions EAU12461 EAU88273 EAU88941 Turn signal switch “ ” Hazard switch “OFF/ ” “SEL/RES” switch To signal a right-hand turn, push this Use this switch to turn on the hazard This switch is used to make setting and switch to “...

  • Page 29: Clutch Lever

    Instrument and control functions EAU12823 EAU12876 EAU93080 Clutch lever Shift pedal Brake lever 1 1 1 1 1 1 1 1 1 1. Clutch lever 1. Shift pedal 1. Brake lever 2. Distance To disengage the drivetrain from the The shift pedal is located on the left 3.

  • Page 30: Brake Pedal

    Instrument and control functions EAU12944 EAU93090 Brake pedal  The ABS performs a self-diagnos- The Yamaha ABS (Anti-lock Brake tic test each time the vehicle first System) features a dual electronic con- 1 1 1 starts off after the key is turned to trol system, which acts on the front and “ON”...

  • Page 31: Fuel Tank Cap

    Instrument and control functions EAU13077 Fuel tank cap The fuel tank cap cannot be closed un- 1 1 1 less the key is in the lock. In addition, the key cannot be removed if the cap is not properly closed and locked. EWA11092 1 1 1 WARNING...

  • Page 32: Fuel

    EWA10882 WARNING EAU86072 Gasoline and gasoline vapors are Your Yamaha engine was designed to extremely flammable. To avoid fires use unleaded gasoline with a research and explosions and to reduce the octane number of 90 or higher. If en- risk of injury when refueling, follow 1.

  • Page 33: Fuel Tank Overflow Hose

    10% (E10). Gas- clean it if necessary. ohol containing methanol is not  Make sure that the fuel tank over- recommended by Yamaha because it flow hose is positioned as shown. can cause damage to the fuel system or vehicle performance problems.

  • Page 34: Catalytic Converter

    Instrument and control functions EAU13435 EAU93101 Catalytic converter Seats See page 6-11 for canister information. The exhaust system contains catalytic converter(s) to reduce harmful exhaust Passenger seat emissions. EWA10863 To remove the passenger seat WARNING 1. Insert the key into the seat lock, The exhaust system is hot after op- and then turn it clockwise.
  • Page 35 Instrument and control functions 1 1 1 1 1 1 2 2 2 1. Projection 1. Cover 1. Bolt 2. Seat holder 2. Quick fastener 4. Lift the seat rearward and up to re- 2. Insert the key into the seat lock, 2.

  • Page 36: Rear View Mirrors

    Instrument and control functions 5. Install the passenger seat. EAU39672 Rear view mirrors 1 1 1 The rear view mirrors of this vehicle Make sure that the seats are properly can be folded forward or backward for secured before riding. parking in narrow spaces.

  • Page 37: Adjusting The Front Fork

    Instrument and control functions EAU76345 Spring preload setting: Adjusting the front fork Minimum (soft): EWA14671 Distance A = 19.0 mm (0.75 in) WARNING Standard: Always adjust the spring preload on Distance A = 14.0 mm (0.55 in) Maximum (hard): both fork legs equally, otherwise Distance A = 4.0 mm (0.16 in) poor handling and loss of stability may result.
  • Page 38 Instrument and control functions tions, however such adjustments are ineffective and may damage 1 1 1 the suspension. Compression damping force The compression damping force is ad- justed on the left fork leg only. Turn the adjusting screw in direction (a) to increase the compression damping force.

  • Page 39: Adjusting The Shock Absorber Assembly

    Instrument and control functions tions, however such adjustments EAU91870 Adjusting the shock absorber are ineffective and may damage assembly the suspension. This shock absorber assembly is equipped with a spring preload adjust- ing ring and a rebound damping force 3 2 1 7 6 5 4 adjusting screw.
  • Page 40 When turning the damping force ad- to increase the rebound damping sembly yourself. Take the shock juster in direction (b), it may turn be- force. absorber assembly to a Yamaha yond stated specifications, Turn the adjusting screw in direction (b) dealer for any service.

  • Page 41: Auxiliary Dc Connector

    EAU70641 EAU15306 Auxiliary DC connector Sidestand Yamaha dealer repair it if it does not This vehicle is equipped with an auxil- The sidestand is located on the left function properly. iary DC connector. Consult your side of the frame.

  • Page 42: Ignition Circuit Cut-Off System

    Instrument and control functions EAU44895 Ignition circuit cut-off system This system prevents in-gear engine starts unless the clutch lever is pulled and the sidestand is up. Also, it will stop the running engine should the sidestand be lowered while the trans- mission is in gear.
  • Page 43 The neutral switch may not be working. 6. Move the sidestand up. The motorcycle should not be ridden until 7. Pull the clutch lever. checked by a Yamaha dealer. 8. Shift transmission into gear. 9. Move the sidestand down. Does the engine stall? The sidestand switch may not be working.

  • Page 44: For Your Safety - Pre-Operation Checks

    • If necessary, add recommended coolant to specified level. 6-14 Coolant • Check cooling system for leakage. • Check operation. • If soft or spongy, have Yamaha dealer bleed hydraulic system. • Check brake pads for wear. Front brake • Replace if necessary. 6-22, 6-22 •...
  • Page 45 • Make sure that operation is smooth. • Check throttle grip free play. 6-17, 6-27 Throttle grip • If necessary, have Yamaha dealer adjust throttle grip free play and lubricate ca- ble and grip housing. • Make sure that operation is smooth. Control cables 6-26 •...
  • Page 46 • Tighten if necessary. Instruments, lights, signals • Check operation. — and switches • Correct if necessary. • Check operation of ignition circuit cut-off system. Sidestand switch 3-26 • If system is not working correctly, have Yamaha dealer check vehicle.

  • Page 47: Operation And Important Riding Points

    ECA10311 NOTICE there is a control or function you do not between 0 and 1600 km (1000 mi). For understand, ask your Yamaha dealer. this reason, you should read the fol-  Keep the engine speed out of EWA10272 lowing material carefully.

  • Page 48: Starting The Engine

    This model is equipped with:  the transmission is in the neutral Yamaha dealer check the vehicle.  a lean angle sensor. This sensor position or stops the engine in case of a vehi- ...

  • Page 49: Shifting

    Operation and important riding points 3. Open the throttle gradually, and at EAU16675 ECA10262 Shifting NOTICE the same time, release the clutch  When shifting, press the shift lever slowly. pedal firmly until you feel the 4. After starting out, close the throt- gear shift is complete.

  • Page 50: Tips For Reducing Fuel Consumption

    Operation and important riding points 4. Once motorcycle EAU16811 EAU17214 Tips for reducing fuel con- Parking stopped, the transmission can be sumption When parking, stop the engine, and shifted into the neutral position. then remove the key from the main Fuel consumption depends largely on The neutral indicator light should switch.

  • Page 51: Periodic Maintenance And Adjustment

    To avoid possible burns, let tivities incorrectly may increase brake components cool before your risk of injury or death during touching them. service or while using the vehicle. If you are not familiar with vehicle ser- vice, have a Yamaha dealer perform service.

  • Page 52: Tool Kits

    Tool kits If you do not have the tools or experi- ence required for a particular job, have your Yamaha dealer perform it for you. 1. Tool kit The on–board tool kit is in the location shown. Also, an additional tool kit was handed out separately at the time of vehicle purchase.

  • Page 53: Periodic Maintenance Charts

    EAU71033 Periodic maintenance charts  Items marked with an asterisk should be performed by your Yamaha dealer because these items require special tools, data, and technical skills.  From 50000 km (30000 mi), repeat the maintenance intervals starting from 10000 km (6000 mi).
  • Page 54 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check control system for dam- Evaporative emis- √...

  • Page 55: General Maintenance And Lubrication Chart

    • Perform dynamic inspection us- Diagnostic system √ √ √ √ √ √ ing Yamaha diagnostic tool. check • Check the error codes. 2 * Air filter element • Replace. Every 40000 km (24000 mi) Air filter case check √...
  • Page 56 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check bearing for looseness or √ √...
  • Page 57 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check operation. √ √ √ √ √...
  • Page 58 Periodic maintenance and adjustment ODOMETER READING ANNUAL ITEM CHECK OR MAINTENANCE JOB 1000 km 10000 km 20000 km 30000 km 40000 km CHECK (600 mi) (6000 mi) (12000 mi) (18000 mi) (24000 mi) • Check operation and free play. • Adjust the throttle cable free play Throttle grip hous- √...

  • Page 59: Removing And Installing Cowlings

    Periodic maintenance and adjustment To install the cowling EAU18782 Removing and installing cowl- 1 1 1 1. Place cowling B in its original po- ings sition, and then install the bolts The cowlings shown need to be re- and nut. moved to perform some of the mainte- 2.

  • Page 60: Checking The Spark Plugs

    1/2 turn past finger tight. However, the Yamaha dealer. Since heat and depos- with a wire thickness gauge and, if spark plug should be tightened to the its will cause any spark plug to slowly necessary, adjusted to specification.

  • Page 61: Canister

    Periodic maintenance and adjustment EAU36113 EAU93141 Canister Engine oil and oil filter car- 1 1 1 tridge The engine oil level should be checked before each ride. In addition, the oil must be changed and the oil filter car- tridge replaced at the intervals speci- fied in the periodic maintenance and lubrication chart.
  • Page 62 Periodic maintenance and adjustment An oil filter wrench is available at a Yamaha dealer. 7. Apply a thin coat of clean engine oil to the O-ring of the new oil filter cartridge. 1. Engine oil filler cap 1. Engine oil drain bolt 2.
  • Page 63 Periodic maintenance and adjustment Recommended engine oil: See page 8-1. Oil quantity: Oil change: 2.30 L (2.43 US qt, 2.02 Imp.qt) With oil filter removal: 2.60 L (2.75 US qt, 2.29 Imp.qt) 1 1 1 Be sure to wipe off spilled oil on any 1.

  • Page 64: Why Yamalube

    We form the periodic maintenance chart. gine off and have a Yamaha dealer teams of specialists in the fields of me- check the vehicle. Recommended coolant:...
  • Page 65 The coolant must be changed at the in- tervals specified in the periodic main- 1 1 1 tenance and lubrication chart. Have a Yamaha dealer change the coolant. WARNING! Never attempt to remove the radiator cap when the engine is 1. Coolant reservoir cap hot.

  • Page 66: Replacing The Air Filter Element And Cleaning The Check Hose

    Yamaha dealer. placed at the intervals specified in the periodic maintenance and lubrication Engine idling speed: chart. Have a Yamaha dealer replace 1250–1450 r/min the air filter element more frequently if you are riding in unusually wet or dusty areas. However, the air filter check...

  • Page 67: Checking The Throttle Grip Free Play

    3.0–5.0 mm (0.12–0.20 in) proper tire pressure may cause se- Periodically check the throttle grip free vere injury or death from loss of play and, if necessary, have a Yamaha control.  The tire air pressure must be dealer adjust it.
  • Page 68 “broken combined weight of the rider, pas- wall is cracked, have a Yamaha dealer in” for it to develop its optimal senger, cargo, and any accessories. replace the tire immediately.
  • Page 69 1. Tire air valve ed below have been approved for this atively poor grip on certain road 2. Tire air valve core model by Yamaha. surfaces until they have been 3. Tire air valve cap with seal “broken in”. Therefore, it is ad-...

  • Page 70: Cast Wheels

    Measure the clutch lever free play as clutch does not operate correctly, have note the following points regarding the shown. a Yamaha dealer check the internal specified wheels.  The clutch mechanism. wheel...

  • Page 71: Checking The Brake Lever Free Play

    Yamaha dealer. 1. No brake lever free play There should be no free play at the brake lever end. If there is free play, have a Yamaha dealer inspect the brake system. EWA14212 WARNING A soft or spongy feeling in the brake lever can indicate the presence of air in the hydraulic system.

  • Page 72: Checking The Front And Rear Brake Pads

    EAU22393 EAU40262 Checking the front and rear Checking the brake fluid level Yamaha dealer replace the brake pads brake pads Before riding, check that the brake fluid as a set. is above the minimum level mark.
  • Page 73 Periodic maintenance and adjustment  Use only the specified brake flu- Rear brake fluid level goes down suddenly, have a id; otherwise, the rubber seals Yamaha dealer check the cause before may deteriorate, causing leak- further riding. 1 1 1 age.

  • Page 74: Changing The Brake Fluid

    EAU22734 EAU22762 Changing the brake fluid Drive chain slack Have a Yamaha dealer change the The drive chain slack should be brake fluid every 2 years. In addition, checked before each ride and adjusted have the seals of the master cylinders if necessary.
  • Page 75 3. Tighten the axle nut, and then EAU59921 To adjust the drive chain slack tighten the locknuts to the speci- Consult a Yamaha dealer before ad- fied torques. 1 1 1 justing the drive chain slack. 1. Loosen the locknut at each end of...

  • Page 76: Cleaning And Lubricating The Drive Chain

    If a cable is wet areas. Service the drive chain as damaged or does not move smoothly, follows. have a Yamaha dealer check or re- place it. WARNING! Damage to the ECA10584 NOTICE outer housing of cables may result...

  • Page 77: Checking And Lubricating The Throttle Grip And Cable

    In pedals should be checked before each addition, the cable should be lubricat- ride, and the pedal pivots should be lu- ed by a Yamaha dealer at the intervals bricated if necessary. specified in the periodic maintenance Brake pedal chart.

  • Page 78: Checking And Lubricating The Brake And Clutch Levers

    EWA10732 Clutch lever WARNING If the sidestand does not move up and down smoothly, have a Yamaha dealer check or repair it. Otherwise, the sidestand could contact the ground and distract the operator, re- sulting in a possible loss of control.

  • Page 79: Lubricating The Rear Suspension

    The swingarm pivots must be lubricat- face and hold it in an upright posi- sion must be lubricated by a Yamaha ed by a Yamaha dealer at the intervals tion. WARNING! To avoid injury, dealer at the intervals specified in the...

  • Page 80: Checking The Steering

    [EWA10752] the periodic maintenance and lubrica- 2. Hold the lower ends of the front have a Yamaha dealer check or re- tion chart. If there is play in the wheel fork legs and try to move them for- pair it.

  • Page 81: Battery

     Electrolyte is poisonous and 3. Fully charge the battery before in- stallation. NOTICE: When install- Have a Yamaha dealer charge the bat- dangerous since it contains sul- tery as soon as possible if it seems to ing the battery, be sure to turn furic acid, which causes severe have discharged.

  • Page 82: Replacing The Fuses

    Periodic maintenance and adjustment nect the positive lead before EAU59876 Replacing the fuses connecting the negative lead. The main fuse and the fuse boxes, [ECA16842] which contain the fuses for the individ- 4. After installation, make sure that ual circuits, are located under the rider the battery leads are properly con- seat.

  • Page 83: Vehicle Lights

    If an LED light does not come on, Fuel injection system fuse: check the fuses and then have a 10.0 A Yamaha dealer check the vehicle. If the Backup fuse: license plate light does not come on, 7.5 A check and replace the bulb. (See page Accessory fuse: 10.0 A...

  • Page 84: Replacing A License Plate Light Bulb

    Periodic maintenance and adjustment EAU49722 EAU67131 Replacing a license plate light Supporting the motorcycle bulb 1. Remove the license plate light unit bolts. 1. License plate light bulb 4. Insert a new bulb into the socket. 1. Maintenance stand (example) 5.

  • Page 85: Troubleshooting

    The following troubleshooting charts represent quick and easy procedures for checking these vital systems your- self. However, should your motorcycle require any repair, take it to a Yamaha dealer, whose skilled technicians have the necessary tools, experience, and know-how to service the motorcycle properly.

  • Page 86: Troubleshooting Chart

    Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 87 Start the engine. If the engine overheats again, have a The coolant level Yamaha dealer check and repair the cooling system. is OK. If coolant is not available, tap water can be temporarily used instead, provided that it is changed to the recommended cool- ant as soon as possible.

  • Page 88: Motorcycle Care And Storage

    Be performance and extend the useful life  high-pressure washers sure to consult a Yamaha dealer for of many components. Washing, clean- steam-jet cleaners. Excessive advice on what products to use be- ing, and polishing will also give you a...
  • Page 89 Motorcycle care and storage chemicals such as, solvents, Washing plastic may scratch the wind- gasoline, rust removers, brake 1. Rinse off any degreaser and spray shield, so be sure to test all fluid, or antifreeze, etc. down the vehicle with a garden cleaning products before gen- hose.

  • Page 90: Storage

    Motorcycle care and storage  Do not use abrasive polishing will become slippery, which EAU83472 Storage could cause loss of control. compounds as they will wear Always store the vehicle in a cool, dry Thoroughly clean the surfaces away the paint. place.
  • Page 91 Motorcycle care and storage 1. Make all necessary repairs and b. Pour a teaspoonful of engine wheels a little once a month in or- perform any outstanding mainte- oil into the spark plug bore. der to prevent the tires from be- nance.

  • Page 92: Specifications

    Specifications Dimensions: Fuel injection: Starting system: Electric starter Overall length: Throttle body: Engine oil: 2070 mm (81.5 in) ID mark: Overall width: Recommended brand: 1WS1 705 mm (27.8 in) Drivetrain: Overall height: Gear ratio: 1160 mm (45.7 in) 1st: Seat height: 2.846 (37/13) 835 mm (32.9 in) 2nd:...
  • Page 93 Specifications Loading: Auxiliary light: Maximum load: License plate light: 162 kg (357 lb) 5.0 W (Total weight of rider, passenger, cargo and accessories) Front brake: Type: Hydraulic dual disc brake Rear brake: Type: Hydraulic single disc brake Front suspension: Type: Telescopic fork Rear suspension: Type:...

  • Page 94: Consumer Information

    These identification numbers are needed when registering the vehicle with the authorities in your area and when ordering spare parts from a Yamaha dealer. 1 1 1 VEHICLE IDENTIFICATION NUMBER: 1. Vehicle identification number 1. Engine serial number...

  • Page 95: Diagnostic Connector

    1 1 1 mation will be needed when ordering cal analysis and development purpos- spare parts from a Yamaha dealer. Although the sensors and recorded data will vary by model, the main data points are: ...
  • Page 96 Consumer information Yamaha will not disclose this data to a third party except in the following cas- es. In addition, Yamaha may provide vehicle data to a contractor in order to outsource services related to the han- dling of vehicle data. Even in this case,...

  • Page 97: Index

    Index Dimmer switch ........3-12 Display brightness and shift timing ABS............3-15 License plate light bulb, replacing..6-34 indicator light settings mode ..... 3-10 ABS warning light ........3-5 Display units, switching ......3-6 Air filter element and check hose, Main switch/steering lock.......
  • Page 98 Index Sidestand, checking and lubricating ..6-28 Spark plugs, checking ......6-10 Specifications .........8-1 Speedometer ..........3-6 Starting the engine........5-2 Start switch...........3-13 Steering, checking ........6-30 Storage ...........7-3 Supporting the motorcycle ....6-34 Swingarm pivots, lubricating ....6-29 Tachometer..........3-6 Throttle grip and cable, checking and lubricating...........6-27 Throttle grip free play, checking ...6-17 Tires ............6-17 Tool kits ..........6-2...
  • Page 100 Original instructions PRINTED IN JAPAN 2021.07-0.4×1 CR (E)
