Manual and certificates – METALU PANTALAN hydraulic pool lift Contents Manufacturer information ........................3 Functional characteristics........................3 Main product standards........................5 CE declaration of conformity........................ 6 Identification plate..........................7 Warranty certificate..........................7 Commissioning certificate........................8 Installation certificate. -
Page 3: Manufacturer Information
2. Functional characteristics. The METALU PANTALAN model is a pool lift that allows people with reduced mobility to enter swimming pools independently. The design is fully custom and aimed at swimming pools that lose large amounts of water: docks, natural pools, ports, etc. - Page 4 ➢ Manometer to measure the pressure received by the hydraulic system. ➢ The lift leaves the factory fully assembled and ready for installation. ➢ Adaptability (available to order): Inverse turn or left turn. The technical characteristics of the METALU PANTALAN model are listed below. Technical characteristics AISI 316 stainless steel...
-
Page 5: Main Product Standards
Manual and certificates – METALU PANTALAN hydraulic pool lift 3. Main product standards. ➢ The manufacturing and finish of the lift have the following characteristics: o The entire structure and accessories are made of 316 stainless steel. o The finish of the metal avoids sharp edges that could cause injuries. -
Page 6: Ce Declaration Of Conformity
Manual and certificates – METALU PANTALAN hydraulic pool lift 4. CE declaration of conformity. CE DECLARATION OF CONFORMITY The undersigned, representing the company: Company name: Manufacturas Metálicas Luisianeras, S.L. Tax ID: B – 41834508. Address: Polígono Industrial Los Motillos, C/ Madrid n.º 11 naves A, C, D, G, H, 41430. -
Page 7: Identification Plate
Manual and certificates – METALU PANTALAN hydraulic pool lift 5. Identification plate. The product shall bear a legible and indelible identification plate displaying the following information: • Name and address of the manufacturer. • CE conformity marking. • Year of manufacture. -
Page 8: Commissioning Certificate
Manual and certificates – METALU PANTALAN hydraulic pool lift 7. Commissioning certificate. Manufacturer information: Company name: Manufacturas Metálicas Luisianeras, S.L. Tax ID: B – 41834508. Address: Polígono Industrial Los Motillos, C/ Madrid n.º 11 naves A, C, D, G, H, 41430. -
Page 9: Installation Certificate
Manual and certificates – METALU PANTALAN hydraulic pool lift 8. Installation certificate. Installer company: Declaration: The lift has been installed in compliance with the manufacturer’s instructions. Product: “METALU PANTALAN” pool lift. Hydraulic assistant. Serial no.: Installation date: Place of assembly:... -
Page 10: Components In The Standard Package
Manual and certificates – METALU PANTALAN hydraulic pool lift 9. Components in the standard package. The standard package of the METALU PANTALAN model is made of the components in the following image. Shower Top control lever Top anchor Lower control lever... -
Page 11: Components In The Delivery
Manual and certificates – METALU PANTALAN hydraulic pool lift 10. Components in the delivery. The components of the METALU-PANTALAN lift are: 1. Lift body: o Cylinder and axis. o Valve system. o Shower. 2. Seat: o Seat. o Foldable armrest. -
Page 12: Dimensions Of The Lift
Manual and certificates – METALU PANTALAN hydraulic pool lift 11. Dimensions of the lift The dimensions of the lift in position in a standard pool are the following. Since it’s a model with a custom design, most of the dimensions depend on how it's customised. - Page 13 Manual and certificates – METALU PANTALAN hydraulic pool lift Plan view lift dimensions. The lift turning range is 170 degrees...
- Page 14 Manual and certificates – METALU PANTALAN hydraulic pool lift Units in millimetres [mm]. The following image shows the dimensions of the seat, foldable armrest, foldable footrest, and seat belt. * The foldable footrest has 3 positions. The dimension is 180 mm for the middle position. The other two positions are at a distance of 5 cm;...
- Page 15 Manual and certificates – METALU PANTALAN hydraulic pool lift...
-
Page 16: Proper Use Of The Product And Maintenance
Manual and certificates – METALU PANTALAN hydraulic pool lift 12. Proper use of the product and maintenance. Using and maintaining the product correctly will substantially increase its lifetime. Therefore, we recommend following these guidelines: • Proper use of the lift: o Use the lift responsibly. - Page 17 Manual and certificates – METALU PANTALAN hydraulic pool lift • Maintenance: o Clean the structure of the lift with lots pressurised fresh water to ensure there are no foreign particles on the surface, and then dry with a cotton cloth.
- Page 18 Manual and certificates – METALU PANTALAN hydraulic pool lift The pool lift moves using a hydraulic mechanism. When the user turns handle, the lift will start to go up or down, allowing them to enter or leave the pool. The following image shows the standard right turning direction of the lift. There is another version of the left that turns left.
- Page 19 Manual and certificates – METALU PANTALAN hydraulic pool lift The element that activates the lift is an actuating handle. The lifting or lowering speed can be adjusted depending on how much the handle is turned. The PANTALAN model has two actuation zones to guarantee user autonomy.
- Page 20 Looking after the environment is everyone’s responsibility. METALU equipment should only be used by designated people at centres and by the users of the equipment. Those responsible at centres should know the equipment and have read the instructions. If any questions remain after reading the instructions, contact the manufacturer at the addresses provided below.
- Page 21 MANUFACTURAS METÁLICAS LUISIANERAS, S.L. METALU PANTALAN Manual and certificates Dirección: Polígono Industrial Los Motillos, C/ Madrid n.º 11 naves A, C, D, G, H, 41430. Localidad: La Luisiana (Sevilla) – Spain CIF: B – 41834508 Teléfono principal: +34 955 907 784 Página web: www.ascensoracuatico.com...
