Summary of Contents for METALU S-400
-
Page 2: Table Of Contents
Manual and certificates – METALU S-400 pool lift Contents Manufacturer information ........................3 Functional characteristics........................3 Main product standards........................5 CE declaration of conformity........................ 6 Identification plate..........................7 Warranty certificate..........................7 Commissioning certificate........................8 Components in the standard package. -
Page 3: Manufacturer Information
2. Functional characteristics. The METALU S-400 pool lift is designed to help people with reduced mobility access swimming pools independently. It is a pool lift that does not need to be anchored to the ground, avoiding the need for drilling near the pool. - Page 4 Removable seat to prevent improper use. • Accessories (available to order): o Seat belt. o Protective cover. The technical characteristics of the METALU S-400 model are listed below. Technical characteristics S-400 Material AISI 316 stainless steel Maximum load capacity 120 or 150...
-
Page 5: Main Product Standards
Manual and certificates – METALU S-400 pool lift 3. Main product standards. The manufacturing and finish of the lift have the following characteristics: o The entire structure and accessories are made of 316 stainless steel. o The finish of the metal avoids sharp edges that could cause injuries. -
Page 6: Ce Declaration Of Conformity
Manual and certificates – METALU S-400 pool lift 4. CE declaration of conformity. CE DECLARATION OF CONFORMITY The undersigned, representing the company: Company name: Manufacturas Metálicas Luisianeras. S.L Tax ID: B - 41,834,508 Address: Polígono industrial Los Motillos, C/ Madrid n.º 11 naves A, C, D, G, H, 41430. -
Page 7: Identification Plate
Manual and certificates – METALU S-400 pool lift 5. Identification plate. The product shall bear a legible and indelible identification plate displaying the following information: • Name and address of the manufacturer. • CE conformity marking. • Year of manufacture. -
Page 8: Commissioning Certificate
Manual and certificates – METALU S-400 pool lift 7. Commissioning certificate. Manufacturer information: Company name: Manufacturas Metálicas Luisianeras, S.L. Tax ID: B – 41834508. Address: Polígono Industrial Los Motillos, C/ Madrid n.º 11 naves A, C, D, G, H, 41430. -
Page 9: Components In The Standard Package
Manual and certificates – METALU S-400 pool lift 8. Components in the standard package. The standard package for the METALU S-400 model includes the following components: Linear actuator Foldable arm Seat Base platform Footrest Battery Actuation controller Control system... -
Page 10: Components In The Delivery
Manual and certificates – METALU S-400 pool lift 9. Components in the delivery. Components in the delivery Assembled weight Dimensions Type of order Content [kg] (width x length) [mm] 1. Lift body 2. Seat European pallet: 3. Documentation: 300 kg •... - Page 11 Manual and certificates – METALU S-400 pool lift In addition, delivery includes a ramp to facilitate getting the lift out of the box in which it is packaged. Before moving the lift along the ramp, we recommend removing the seat and the packaging documentation box.
-
Page 12: Dimensions Of The Lift
Manual and certificates – METALU S-400 pool lift 10. Dimensions of the lift The image below shows the dimensions of the METALU S-400 lift from the profile of a standard pool with units in millimetres [mm]. S-400 lift side view dimensions. - Page 13 Manual and certificates – METALU S-400 pool lift The image below shows the dimensions of the METALU S-400 lift in plan view for a standard pool with units in millimetres [mm]. S-400 lift plan view dimensions. The lift is designed to be easily transported and stored. To this end, the base dimensions are 730 mm, so...
- Page 14 Manual and certificates – METALU S-400 pool lift In three-dimensional space, the critical positions of the lift are shown in the image below. Dimensions in three-dimensional space of the S-400 lift.
-
Page 15: Use Of The Lift
Manual and certificates – METALU S-400 pool lift 11. Use of the lift. Follow these steps to use the pool lift: 1. Unblock the emergency stop of the control system (24V electrical mechanism). Emergency stop 2. Sit on the seat and place feet on footrests. -
Page 16: Proper Use Of The Product And Maintenance
• Preliminary considerations. o To use the METALU S-400 pool lift correctly, follow the instructions in this manual and be mindful of the precautions and warnings, as well as the maintenance instructions. It is the lift owner’s responsibility to follow the instructions in this manual. - Page 17 If the lift is outside, we recommend covering it to extend the life of its components. One accessory offered by METALU is a protective cover, which we recommend using. o If there are weeks during which the lift isn’t used, we recommend operating it with a medium load (approximately 75 kg), raising and lowering it several times.
- Page 18 Looking after the environment is everyone’s responsibility. METALU equipment should only be used by designated people at centres and by the users of the equipment. Those responsible at centres should know the equipment and have read the instructions. If any questions remain after reading the instructions, contact the manufacturer at the addresses provided below.
- Page 19 MANUFACTURAS METÁLICAS LUISIANERAS, S.L. Batery Pool Lift model METALU S-400 Manual and certificates Adress: Polígono Industrial Los Motillos, C/ Madrid n.º 11 naves A, C, D, G, H, 41430. La Luisiana (Sevilla) Spain CIF: B – 41834508 Phone: +34 955 907 784 Web: www.poollift.com.es...
