S A F E H AV E N K I T
One Triangle Base and Shade Top, nine screws,
three Safe Haven trunks, fifty-four 46" limbs
1. Insert trunks into post base and secure with provided
self-tapping screws. TIP: Note the correct orientation of the V shape.
There are NO pre-drilled holes for the self-tapping screws.
2. Insert one limb into the second V from the top of each trunk (see diagram).
3. Lay shade top over top of trunks and secure by inserting limbs in top row of V's
on top of each trunk (see diagram).
4. Insert limbs in the remaining V's on each trunk.
5. Place gravel, concrete block(s), or bag of concrete in base to weigh
product down (not included).
shade top
limb
2
3-post base
( 6 0 lb s . )
self-
tapping
screw
trunk
Do not place in swimming or boating areas. Check your local game laws.
3
Shade top should be
secured between rst
and second row of limbs
per trunk. Place shade
top over trunks BEFORE
inserting top row of
limbs.
