R O O T WA D
One 20" Root Wad trunk, nine 46" limbs
1. Position trunk upright where slits appear as "V" shapes.
2. Insert one limb into outer V-shape and angle tip down slightly
as you insert into V-shape directly across trunk.
3. Ensure limb is fit securely through V-shapes on both sides of trunk.
MossBack products allow you to create multiple limb configurations.
Leave at least 4" of limb through on one side of trunk. See ideas below.
4. Continue inserting limbs in trunk repeating first three steps.
Product needs weighting. We recommend our block adapter (sold separately)
to easily attach a concrete block to our single products.
trunk
shade top
( 9 lb s . )
limb
2
3-post base
Regular
Do not place in swimming or boating areas. Check your local game laws.
self-
tapping
screw
trunk
All limbs to one side
(creates a stakebed)
limb
3
Regular
quick link
quick link
Widespread for
maximum coverage
hex nut
Shade top sh
secured betw
and second r
per trunk. Pla
top over trun
inserting top
limbs.
All limbs to
(creates a s
cable
Advertisement
Summary of Contents for MOSSBACK FISH HABITAT ROOT WAD
- Page 1 R O O T WA D ( 9 lb s . ) One 20" Root Wad trunk, nine 46" limbs limb 1. Position trunk upright where slits appear as “V” shapes. Shade top sh self- 2. Insert one limb into outer V-shape and angle tip down slightly...
- Page 2 R O O T WA D K I T ( 3 2 lb s . ) One Triangle Base and Shade Top, nine screws, three 20" Root Wad trunks, twenty-seven 46" limbs 1. Insert ONE LIMB into the BOTTOM V shape slot on each trunk (see diagram).
- Page 3 One base plate affixed to an 11 inch connector sleeve, one top plate, two screws (for use with Root Wad*, Safe Haven, Safe Haven XL, Trophy Tree, Trophy Tree XL, Predator Prey Combo Tree, and John Godwin Signature Crappie Tower) 1.
