- Page 1 SMARTOUCH DIGITAL ePACK USER MANUAL APPLIED COMPUTER CONTROLS 701 W. Foothill Blvd., Azusa, CA 91702 (626) 969-9655 Fax (626) 334-4809 www.acc-spas.com...
- Page 2 Micro-processor technology is becoming a familiar name in the spa industry. Here, at Applied Computer Controls, we produced our first intelligent microprocessor based spa control system, in 1981-82. The SC-100 and SC-200; the forerunners of intelligent electronic spa controls. Today, SmarTouch Digital includes more than 30 years experience. SmarTouch Digital, is a third generation microprocessor-based control system.
-
Page 3: Table Of Contents
TA B L E O F C O N T E N T S INTRODUCTION ....... . 4 INTRODUCTION . -
Page 4: Introduction
INTRODUCTION Thank you for buying a spa equipped with a SmarTouch Digital control system. Many years of experience went into the design of this family of controls. You can be assured your spa control system is the most advanced, it is highly reliable and will serve you for many years to come. -
Page 5: Temperature Setting
IN A H U R RY - R E A D T H I S SmarTouch Digital comes to you with a universal set of default settings. If you choose to keep these settings, then you only need to remember 2 things: how to set the spa temperature and to press the SET key whenever you are done using the spa. -
Page 6: Setting Time-Of-Day
S E T T IN G T I M E -O F -D AY Setting Time-Of-Day Press and hold for 2 sec. the DOWN (Time) arrow key. Controller will display 12:00 noon. Use to set the correct time-of-day. *After every selection “Hours , Minutes” press SET key. -
Page 7: Spa-Side Control Panel 2010
SPA-SIDE CONTROL PANEL 2010 FUNCTIONS Press once to activate the low jets. Press again for high jets. A third depression turns the jets OFF, if the heater is off. Press, for air bubbles or a second pump if marked AUX. Light switch ON/OFF, or an optional three functions’... -
Page 8: Spa-Side Control Panel 1000
SPA-SIDE CONTROL PANEL 1000 FUNCTIONS Press once to activate the low jets. Press again for high jets. A third depression turns the jets OFF, if the heater is off. Press, for air bubbles or a second pump if marked AUX. Light switch ON/OFF, or an optional three functions’... -
Page 9: Self-Diagnostic Codes
S E L F - D A IG N O S T IC C O D E S CODE EXPLANATION COLD Water temperature below 40 F. Water temperature above 108 F. SESH Temperature sensor shorted. SEOP Temperature sensor open or disconnected HLer Overheat condition or overheat sensor is disconnected PSOL Pressure-switch open with low speed jets ON. -
Page 10: Start-Up Procedure
S TA RT- U P P R O C E D U R E Once the spa is delivered and the electrical installation accomplished, the next step is to fill it and heat the water. IMPORTANT It is recommended to perform the following procedure when you drain and refill the spa, to protect the heater element. -
Page 11: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS WARNING 1. To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times. 2. A wire connector is provided on this unit to connect a minimum 8 AWG (8.4MM2) solid copper conductor, between this unit and any metal equipment, metal enclosures of electrical equipment, metal water pipe, or conduit within 5 feet (1.5m) of... -
Page 12: Programming (Optional)
P R O G R A M M I N G SmartTouch Digital comes with factory settings. Programming the SmartTouch controller is optional. The following options are necessary only if you have certain requirements or you need to custom program the filtration and heating cycles. Parameter Programming is a means by which the spa owner / user can change the various timing elements and calibrate... - Page 13 SETTING FILTRATION PERIODS & SILENT MODE FP1, FP2, FP3, FP4 & SIL BEFORE YOU START THIS PROCEDURE PLEASE MAKE SURE YOU SET THE CORRECT TIME-OF-DAY. Note the a.m. LED light -Press SET & DOWN arrow keys together at the same time. -Code “FP1”...
- Page 14 PA R A M E T E R M E N U L I S T Press momentarily the “SET” & “DOWN ARROW” keys at the same time to access the following options. Max Detail 12:00 Start time of filtration period 1 12:00 Start time of filtration period 2 12:00...
- Page 15 Max Detail CLDN Cool Down cycle in seconds. Whenever the heater is turned off the pump keeps running the extra seconds to even the temperature of the heater element and the surrounding water to prevent scale build up and premature heater failure. Economy Cycle Length.
- Page 16 Detail CALB This is not a time element. It is one of the distinctive features of the Smartouch Control System. The number is internal and in indicative of what the processor sees as temperature. It is used to calibrate the temperature reading. Increase this value by 1 to decrease the displayed temperature by ⁄...
-
Page 17: System Options
SYSTEM OPTIONS (Press Up & Down arrow keys together at the same time) Code “CAnC” is displayed User Settable ON/OFF switches 0 = low or circulation pump on demand, 1 = continuous running 0 = user timer reset, 1 = cumulative 0 = alternate TOD, elapsed time &... -
Page 18: Wifi Options
W I F I O P T IO N FCC Regulatory Approval U.S.A. Contains FCC ID: W7OMRF24WG0MAMB This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 19: Electrical Instructions Installation
ELECTRICAL INSTALLATION INSTRUCTIONS All electrical wiring must be performed by a qualified, licensed electrician in order to meet NEC, (National Electrical Code) state and local codes. • This unit is a “Permanently Connected Equipment Assembly with Pump(s), Heater, Blower and Control.” •... - Page 20 ELECTRICAL INSTALLATION INSTRUCTIONS Page 19...
- Page 21 BRANCH CIRCUIT BREAKER REQUIREMENTS 4 Wire System 240 Volts 30/50 Amp 2 Pole Breaker USE COPPER CONDUCTOR ONLY. #6 AWG WIRE 120 Volts 3 Wire System 20 Amp 1 Pole Breaker CAUTION: A new breaker must be used for a new spa installation. Do not use an existing or used breaker.
-
Page 22: Wiring Diagram
W I R IN G D I A G R A M Page 21... -
Page 23: Exploded View
Page 22... -
Page 24: Troubleshooting Guide
TECH TALK..TROUBLESHOOTING GUIDE For SmarTouch Digital ERROR CODES COLD Water temperature below 40 F. Water temperature above 108 F. SESH Temperature sensor shorted. SEOP Temperature sensor open or disconnected HLer Overheat condition or overheat sensor disconnected PSOL No water pressure with low speed jets ON. PSOH No water pressure with high speed jets ON PSOC No water pressure with circulating pump ON Error code PSOL? PSOH? PSOC? - Page 25 Check power at Heater ELEMENT. If no power one or more heater relay(s) is NOT -- closing. Replace PCBoard. OVERHEAT ERROR CODES ( OH or HLEr) but spa water temperature is not. Allow enough time for the sensors to cool down. Then clear the error code by pressing the SET button. 1-Turn temperature down to lowest setting &...
- Page 26 N O T E S...
- Page 27 N O T E S...
- Page 28 2.5” X 5.5" 3.25” X 7.25" SmarTouch Digital © 1999 Applied Computer Controls. SmarTouch & SmarTouch Digital are trademarks of Applied Computer Controls. This manual may not be copied or reproduced without permission, in part or in total. Rev. ePack 417...
