Pioneer VSX-906RDS Service Manual

® PIONEER'
Service
Manual
ae
RRV1813
AUDIO/VIDEO STEREO RECEIVER
@ Refer to the service manual RRV1780 for VSX-D736S/HLXuJl.
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Type Power Requirement The voltage can be converted by the following method.
VSX-906RDS
HYXdI O C220 - 230V AC240V, *
HYXJIGR ie) AC220 - 230V AC240V, *
% : Alter the wiring of the Power-supply block at the primary winding of power-transformer referring to the "Line Voltage
Selection" described in Service Manual.
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153, Japan
PIONEER ELECTRONICS SERVICE, iNC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 501 Orchard Road, #10-00 Lane Crawford Place, Singapore 0923
© PIONEER ELECTRONIC CORPORATION 1997 T-ZZK MAY 1997 Printed in Belgium
