Clas Ohlson TBC30SXPDK1-ES1 Quick Start Manual

30 W LED Tripod Work Light
Art.no 36-8662 Model TBC30SXPDK1-ES1
Please read the entire instruction manual before use and then
save it for future reference. We reserve the right for any errors in
text or images and any necessary changes made to technical
data. In the event of technical problems or other queries, please
contact our Customer Services.
Safety
The light source is not dimmable.
• This product is extremely bright. Do not look directly into
the light, doing so could cause eye damage.
• Never let children play with the product.
• The product must only be connected to an electrical socket
with a 230 V power supply.
• The product must not be used in rooms where explosive
gases or liquids are used or stored.
• Treat the product with care and do not subject it to shocks
or impacts.
• Never immerse the product in water or other liquid.
• The product must not be covered.
• Never try to open the housing, repair or modify the product
in any way.
• Never use the product if your hands are moist or wet.
• Never use the product if it, its mains lead or plug is
damaged in any way.
Product description
1. Adjustment screws
(one on each side)
2. Fastening screw
3. Height adjustment lock
4
4. Leg lock knob
5
5. Cable holder
Instructions for use
1. Open out the legs of the tripod and lock them in place by
tightening the lock knob (4).
2. Adjust the tripod to the desired height and tighten
the adjustment locks (3).
3. Mount the work light onto the tripod and secure it using
the fastening screw (2).
4. Connect the mains lead to a 230 V power point.
5. Undo the adjustment screws (1) and set the desired angle.
6. Unplug the work light after use.
Care and maintenance
Unplug it from the electrical outlet. Clean the exterior of the light
by wiping it with a damp cloth. Use only mild cleaning agents,
never solvents or corrosive chemicals.
Responsible disposal
1
This symbol indicates that this product should not
be disposed of with general household waste. This
applies throughout the entire EU. In order to prevent
any harm to the environment or health hazards
caused by incorrect waste disposal, the product
2 must be handed in for recycling so that the material
can be disposed of in a responsible manner. When
recycling the product, take it to your local collection facility or
contact the place of purchase. They will ensure that the product
is disposed of in an environmentally sound manner.
Specifications
220–240 V AC, 50/60 Hz
Rated voltage
3
Power 30 W
Colour Black
Light source 2400 lm
Colour temperature 4000 K
Colour rendition > 80 Ra
Beam angle 120°
IP rating IP65
Operating temperature −20 to 40 °C
Mains cable 2.8 m, H05RN-F 3G1.0 mm²
Work light size
(W × H × D) 217 × 207 × 54 mm
Max tripod height 180 cm
Note: The light source of this luminaire is notreplaceable;
when the light source reachesits end of life the whole luminaire
shall bereplaced.
English
