Clas Ohlson LYN3271H Quick Start Manual

Rechargeable Worklight
Art.no 36-9319 Model LYN3271H
Please read the entire instruction manual before using the product
and then save it for future reference. We reserve the right for
any errors in text or images and any necessary changes made
to technical data. In the event of technical problems or other
queries, please contact our Customer Services.
Safety
• Only use the provided charging cable
• Charge the battery before using it for the first time
• Never look directly into the light source as it is very bright.
Risk of eye damage.
Buttons and functions
5 4 3
1. [ ] Button
2. Battery indicator
3. USB-A port for charging mobile phones, etc
4. USB-C input for charging the work lamp
5. Charging cable, USB-A to USB-C
Charging
1. Connect the provided charging cable to the USB-C port (4)
and USB charger (sold separately). The battery indicator (2)
shows when the battery is being charged and when it is fully
charged (four LEDs are lit).
2. Unplug the charging cable from the light when the battery is
fully charged .
• When it is time to charge, the LED flashes 5 times. The light
then has about 10 minutes of remaining operating time
(the indicator flashes).
• Do not leave the light on charge for more than 24 hours at a time.
Operating instructions
Press [ ] repeatedly to switch on and adjust the brightness of
the lamp. Choose between high, medium or low. The last mode
switches off the work light.
2 1
When the work light is switched on, the indicator (2) shows the battery
charge status.
Memory function
1. If no button is pressed within 5 seconds, the current brightness
is saved. The next button press switches the lamp off.
2. The next time the work lamp is switched on, it starts in the last
selected light mode.
Power bank
Use the work light as a power bank by using the USB-A socket (3)
to charge devices such as mobile phones etc.
Care and maintenance
Clean the lamp using a lightly moistened cloth. Use only mild
cleaning agents, never solvents or corrosive chemicals.
Battery
The battery is not replaceable.
When it stops working the product must be discarded.
Responsible disposal
This symbol indicates that this product should not
be disposed of with general household waste.
This applies throughout the entire EU. In order to
prevent any harm to the environment or health
hazards caused by incorrect waste disposal, the
product must be handed in for recycling so that the
material can be disposed of in a responsible manner.
When recycling your product, take it to your local
collection facility or contact the place of purchase.
They will ensure that the product is disposed of in an
environmentally sound manner.
Specifications
Charge 5 V DC, 1 A
Battery 3.7 V, 4400 mAh
Power 10 W
5 V DC, max 1 A
USB output
Beam angle 115º
Light source 800 lm (non-replaceable)
Colour temperature 4000 K
Charging time appr. 4−5 hours
Run time at full charge appr. 3 hours (100%)
IP rating IP54
Size 239 × 167 × 118 mm
English
