Ambassador MARINE 132-0207-CP Installation Instructions

I
NSTALLATION
Thank you for choosing Ambassador Marine.
Your new Ambassador Marine faucet, sprayer, shower or
accessory will give you years of trouble-free performance.
Please read these instructions carefully before installing your
new item. If you have any additional questions about the
installation of this product, please feel free to contact one of
our friendly customer service representatives at 800.270.4262.
1
2
3
4
5
I
NSTRUCTIONS
1) Turn off the water supply to your existing faucet (this procedure will vary depending on the
specific plumbing system installed on your boat). Cover the sink drain to prevent any small parts
or debris from falling in. Remove your existing faucet, taking care not to damage your existing
water lines. Clean sink area in preparation for new faucet.
2) Screw mounting bolt into the bottom of the faucet. One end of the bolt is slotted to allow
the use of a screwdriver to secure. Screw both connector hoses into the bottom of faucet (note: it
is NOT necessary to use Teflon (Plumber's) tape on this connection as the o-rings will prevent
leaks). Use a wrench or pliers on the hex nut molded into the brass shaft portion of the hoses.
Do NOT attempt to tighten by turning the hose itself.
3) Place your new faucet through the hole (1
sink. Align the base ring with the bottom of the faucet and make sure the black gasket properly
lines up with the bottom of the base. From under the sink, slide the rubber horseshoe washer
then the metal horseshoe washer onto the mounting bolts. Adjust faucet position on the sink as
desired. Thread the lock nuts onto the mounting bolts and tighten. It may be necessary to
re-adjust the faucet position by slightly loosening the lock nuts, adjusting to the desired location,
then re-tightening the lock nuts.
4) Connect hot and cold water supplies (not provided) to the
Hot supply will connect to the left hose, cold supply will connect to the right hose. Wrap the
NPS-Male brass fittings on the inlet hoses with Teflon (plumber's) tape. Follow the appropriate
steps depending on your water supply lines. If you have pre-assembled water supply hoses with
threaded connectors, simply screw on supply lines. If you have plastic water lines with formed
ends, water lines will seat partially up into the brass fittings. Connect by tightening the coupling
nuts. We do NOT suggest using sweat fittings as they are prone to blow-outs.
5) After installation is complete, remove the aerator. Be careful not to scratch the finish. Turn
the water supply back on and allow both hot and cold water to run for at least one full minute.
While water is running, check all connections for leaks. Replace aerator. Connections may need
re-tightening.
132-0207-CP
133-0207-CP
/ " to 1 / " diameter hole - standard size) in your
1 3
4 8
1 / " NPS-Male inlet hose fittings.
2
(OEM)
(Retail)
Trinidad
Head Faucet
Chrome
1 / "
2
