Indicator
Alarm
Back View of FD1616GS：
Item
Grounding Terminal
Power Module
2.2
The input voltage must be stable, no EMI noise and distortion.
When use DC power supply, the input voltage is -48VDC, the allowed range is -36 ~ -72
VDC.
When use AC power supply, the input voltage is 110/220VAC, the allowed range is 90 ~
264VAC.
Note: Follow all security specification and the rule about the electricity in the
locality or the building. All power supply must be legal.
2.3
Shenzhen C-Data Technology Co., Ltd.
www.cdatatec.com
( n=1/2/3/4)
XGEn
(n=1/2)
ALARM
宽带接入
FD1616GS Rear View
One, it's in the left of the front panel and is used to grounding for machine
frame
Support Pluggable type two power module. You can chose AC or DC power
supply, optional

Power Requirement

Equipment Ground

data at the uplink port(n)
Green , Always The uplink port(n) is connected
ON
OFF The uplink port(n) isn't
connected
Flash There is the communication
data at the 10GE uplink port(n)
Green , Always The 10GE uplink port(n) is
ON connected
OFF The 10GE uplink port(n) isn't
connected
Always ON One fan doesn't work
Slow Flash Two fan doesn't work
Fast Flash More than three fan doesn't
work
OFF All the fan work
