- Page 1 AUTOOL SDT60 Smoke Leak Detector User Manual www.autooltech.com...
- Page 2 AUTOOL TECHNOLOGY CO.,LTD www.autooltech.com aftersale@autooltech.com +86-755-2330 4822 / +86-400 032 0988 Hangcheng Jinchi Industrial Park, Bao’an, Shenzhen, China Corporate Standard: Q/OR 006-2023...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Copyright Information..................2 Copyright......................2 Trademark ....................... 2 Cautions ......................3 Warning ......................3 Product Introduction ..................4 Overview ......................4 Working theory....................4 Features ......................4 Technical parameter..................5 Product Structure ....................5 Structure diagram.................... 5 Operations Instruction .................. -
Page 4: Copyright Information
COPYRIGHT INFORMATION Copyright ● All rights reserved by AUTOOL TECH. CO., LTD. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of AUTOOL. -
Page 5: Cautions
CAUTIONS Warning Before using the instrument, please read this manual careful- ly for proper operation. If you are not a technician, please do not change, disassemble or repair the product; otherwise all the losses shall be borne by the user. This product is powered by electricity and should not be used as a toy for children. -
Page 6: Product Introduction
PRODUCT INTRODUCTION Overview The AUTOOL SDT60 smoke leak detector is specifically designed for detecting leaks in automotive pipelines. It features a visual pressure gauge, enhancing the convenience and speed of leak detection. This tool aids maintenance technicians in quickly resolving leakage issues, saving repair time. -
Page 7: Technical Parameter
Technical Power Supply DC 12 V parameter Test Oil Filling Volume 10-20 ml Rated Output Pressure ＜10psi Rated Output Flow ＜5 L/min Rated Power 50 W Product Weight 1.6 kg 2.7 kg Gross Weight PRODUCT STRUCTURE Structure diagram Filling port Pressure gauge Smoke indicator Smoke control switch... -
Page 8: Operations Instruction
If the test oil is overfilled, turn the device upside down to drain some oil. ● Start using the SDT60 after the first two steps. ● Detail Fit the smoke hose to the smoke outlet (G) and the power cord operation to the power socket (F). -
Page 9: Operation Guidelines For Automobile Pipeline Inspection
● Operation Turn off the engine ignition switch. guidelines for NOTE automobile pipeline All leak detection of automobile piping systems must be inspection performed with the engine turned off. ● Remove the intake air filter, while some models need to remove the throttle valve. -
Page 10: Instruction Of Smoke Leak Detector Pressure Gauge
Instruction of The smoke leak detector pressure gauge has two main ● smoke leak functions, one is for machine self-test, and the other is for detector pre-assessment of the pipeline system. If the pointer of the pressure pressure gauge keeps still, which represents there is a gauge relatively serious leak in the pipeline;... -
Page 11: Description Of Accessories
1 pc for checking filling amount Used for hanging Hook 1 pc products Universal red 1 set Used for sealing the hose rubber plug Product related operation AUTOOL SDT60 Smoke Leak Detector User manual 1 pc User Manual instructions www.autooltech.com... -
Page 12: Maintenance Service
MAINTENANCE SERVICE Our products are made of long-lasting and durable materials, and we insist on perfect production process. Each product leaves the factory after 35 procedures and 12 times of testing and inspec- tion work, which ensures that each product has excellent quality and performance. -
Page 13: Warranty
Disclaimer All information, illustrations, and specifications contained in this manual, AUTOOL resumes the right of modify this manual and the machine itself with no prior notice. The physical appearance and color may differ from what is shown in the manual, please refer to the actual product. -
Page 14: Return & Exchange Service
RETURN & EXCHANGE SERVICE ● If you are an AUTOOL user and are not satisfied with the Return & AUTOOL products purchased from the online authorized Exchange shopping platform and offline authorized dealers, you can return the products within seven days from the date of receipt;...
