- Page 1 AUTOOL SDT203 Smoke Leak Detector User Manual www.autooltech.com...
- Page 2 企业标准 / Corporate standard: Q/OR 006-2023...
- Page 3 COPYRIGHT INFORMATION Copyright ● All rights reserved by AUTOOL TECH. CO., LTD. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of AUTOOL.
- Page 4 CAUTIONS Warning Before using the instrument, please read this manual careful- ly for proper operation. If you are not a technician, please do not change, disassemble or repair the product; otherwise all the losses shall be borne by the user. This product is powered by electricity and should not be used as a toy for children.
-
Page 5: Table Of Contents
TABLE OF CONTENTS Product Introduction ..................2 Overview ......................2 Working theory....................2 Features ......................2 Technical parameter..................3 Product Structure ....................4 Structure diagram.................... 4 Operations Instruction ..................5 Preparation before use..................5 Smoke test ...................... 5 Generic operation.................... 6 Airbag adapter instructions ................ -
Page 6: Product Introduction
Low oxygen combustion theory ● The AUTOOL smoke leak detector employs a forced combus- tion smoke generation method in a low oxygen environment. It is energized by a conductive column to the heating wire, which rapidly heats up to more than 300°C so that the mineral oil reaches the ignition point and enters the state of combustion. -
Page 7: Technical Parameter
Technical Power Supply DC 12 V parameter Test Oil Filling Volume 10-20 ml Rated Output Pressure ＜15psi Rated Output Flow ＜6 L/min Rated Power 65 W 190*130*85mm Product Size Package Size 234*246*179mm Product Weight 2.5kg Gross Weight 2.7 kg... -
Page 8: Product Structure
PRODUCT STRUCTURE Structure diagram Hook port Pressure gauge Oil refill port Flow meter Oil level gauge Start / Stop button Working cycle LED Power LED Velcro strap Smoke outlet Power socket... -
Page 9: Operations Instruction
OPERATIONS INSTRUCTION Preparation ● Mount the Hook to the hook port (A), used for carrying the unit before use around or hanging somewhere under the hood. ● Open the oil refill port (D), fill the smoke oil into the reservoir and note the oil level gauge (E), make sure the oil level will not exceed 2cm above the bottom of the gauge. -
Page 10: Generic Operation
Generic Turn off the ignition of the vehicle. Leak test of vehicle systems ● operation requires the engine to be off. ● Dismantle the air filter and the throttle connections. ● Clean the inner wall of the intake opening to avoid sharp objects and put the universal intake adapter into the opening. -
Page 11: Airbag Adapter Instructions
Airbag Airbag adapters are suitable for non-circular connections. While adapter for round and oval ports, please use the inlet tapered adapter for instructions normal cases. ● Before using the airbag adapter, be sure to clean the inner wall of the intake manifold (or other test interfaces) to prevent sharp protrusions from piercing the airbag adapter. -
Page 12: Description Of Accessories
DESCRIPTION OF ACCESSORIES Accessories Name Quantity Remark Power cord 1 pc Connected to car battery Smoke outlet hose 1 pc Connecting adapter Installed on the detected Cone adapter 1 pc pipeline Universal airbag 1 pc Used to seal the air inlet adapter Used for hanging Hook... -
Page 13: Maintenance Service
MAINTENANCE SERVICE Our products are made of long-lasting and durable materials, and we insist on perfect production process. Each product leaves the factory after 35 procedures and 12 times of testing and inspec- tion work, which ensures that each product has excellent quality and performance. -
Page 14: Warranty
Disclaimer All information, illustrations, and specifications contained in this manual, AUTOOL resumes the right of modify this manual and the machine itself with no prior notice. The physical appearance and color may differ from what is shown in the manual, please refer to the actual product. -
Page 15: Return & Exchange Service
RETURN & EXCHANGE SERVICE ● If you are an AUTOOL user and are not satisfied with the Return & AUTOOL products purchased from the online authorized Exchange shopping platform and offline authorized dealers, you can return the products within seven days from the date of receipt;...
