Owner's Manual &
Safety Instructions
23l
Model
HCB79B
1-9/16" SDS-Max Type Rotary Hammer
WARNING: To prevent serious injury, User must read and
understand Owner's Manual. SAVE THIS MANUAL.
When unpacking, make sure that the product is intact and undamaged.
If any parts are missing or broken, please call 1‑888‑866‑5797
as soon as possible. Reference 56844.
