Hercules HC108B Owner's Manual & Safety Instructions

20v variable speed grease gun
Hide thumbs
Table of Contents

Advertisement

Quick Links

Owner's Manual &
Safety Instructions
REV 21j
Model
HC108B
20V Variable Speed Grease Gun
WARNING: To prevent serious injury, User must read and
understand Owner's Manual. SAVE THIS MANUAL.
When unpacking, make sure that the product is intact and undamaged.
If any parts are missing or broken, please call 1-888-866-5797
as soon as possible. Reference 58607.
