Basalte 0610-21 Installation Manual

GIGABIT PoE ADAPTER USB-C
Installation Manual
Description
The Gigabit PoE adapter USB-C connects an iPad to ethernet and uses power over ethernet (PoE) to charge the
device. This enables an iPad to receive both data and power over a single Ethernet cable.
The Gigabit PoE adapter is instantly recognized by the iPad and can be configured using the settings app on the
device when running iOS15 (or later)
2
How to install with Eve frame
a
a Eve frame (06XX-XX) (not included)
b 0093-12 Angled USB-C to USB-C cable - short (power and data)
c Gigabit PoE adapter USB-C
d RJ45 cable from PoE switch (not included)
1
b
Before operating the unit, please read this
manual thoroughly and keep it for future
reference.
Model No. 0610-21
Caution: any changes or modifications
not expressly approved in this manual
could void your authority to operate this
equipment.
1 RJ45 PoE cable in
2 USB-C out
3
3 0093-12 Angled USB-C to USB-C cable
- short (power and data)
c
d
