Sealey DFS31A Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions and
properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS, AND
CAUTIONS. USE THIS PRODUCT CORRECTLY, AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO
MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY.
1. SAFETY INSTRUCTIONS
ELECTRICAL SAFETY
1.1
WARNING! It is the responsibility of the owner and the operator to read, understand and comply with the following:
p
p
You must check all electrical products, before use, to ensure that they are safe. You must inspect power cables, plugs, sockets and
any other connectors for wear or damage. You must ensure that the risk of electric shock is minimised by the installation of
appropriate safety devices. A Residual Current Circuit Breaker (RCCB) should be incorporated in the main distribution board. We also
recommend that a Residual Current Device (RCD) is used. It is particularly important to use an RCD with portable products that are
plugged into a supply which is not protected by an RCCB. If in any doubt consult a qualified electrician. You may obtain a Residual
Current Device by contacting your Sealey dealer.
You must also read and understand the following instructions concerning electrical safety.
1.1.1 The Electricity at Work Act 1989 requires that all portable electrical appliances, if used on business premises, are tested by a qualified
electrician, using a Portable Appliance Tester (PAT), at least once a year.
1.1.2 The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the safe condition of those appliances
and the safety of the appliance operators. If in any doubt about electrical safety, contact a qualified electrician.
1.1.3 Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply. See 1.1.1 and 1.1.2
and use a Portable Appliance Tester.
1.1.4 Ensure that cables are always protected against short circuit and overload.
1.1.5 Regularly inspect power supply cables and plugs for wear or damage and check all
connections to ensure that none is loose.
1.1.6 Important: Ensure that the voltage marked on the appliance matches the power supply
to be used and that the plug is fitted with the correct fuse - see fuse rating at right.
1.1.7 DO NOT pull or carry the appliance by the power cable.
1.1.8 DO NOT pull the plug from the socket by the cable.
1.1.9 DO NOT use worn or damaged cables, plugs or connectors. Immediately have any faulty
item repaired or replaced by a qualified electrician. When a BS 1363/A UK 3 pin plug is
damaged, cut the cable just above the plug and dispose of the plug safely.
Fit a new plug according to the following instructions (UK only).
a)Connect the GREEN/YELLOW earth wire to the earth terminal ‘E’.
b)Connect the BROWN live wire to the live terminal ‘L’.
c) Connect the BLUE neutral wire to the neutral terminal ‘N’.
d)After wiring, check that there are no bare wires, that all wires have been correctly connected, that the cable outer insulation extends
beyond the cable restraint and that the restraint is tight. Double insulated products, which are always marked with this symbol
fitted with live (brown) and neutral (blue) wires only. To rewire, connect the wires as indicated above - DO NOT connect either wire to
the earth terminal.
1.1.10 Products which require more than 13 amps are supplied without a plug. In this case you must contact a qualified electrician to ensure
that a suitably rated supply is available. We recommend that you discuss the installation of an industrial round pin plug and socket
with your electrician.
1.1.11 If an extension reel is used it should be fully unwound before connection. A reel with an RCD fitted is preferred since any appliance
plugged into it will be protected. The cable core section is important and should be at least 1.5mm², but to be absolutely sure that the
capacity of the reel is suitable for this product and for others which may be used in the other output sockets, we recommend the use
of 2.5mm² section cable.
1.2 GENERAL SAFETY
p WARNING! Ensure that all relevant Health and Safety, Local Authority, Control of Substances Hazardous to Health (COSHH) and General
Workshop Practice Regulations are strictly adhered to when using this equipment.
3 Familiarise yourself with the applications, limitations and hazards peculiar to the
p WARNING! Disconnect
dust free vacuum system
maintenance.
3 Maintain the dust free vacuum system
3 Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
3 Locate dust free vacuum system
adequate lighting.
p WARNING! Ensure correct air pressure is used, maintained, and not exceeded for the sander attachment.
3 The air supply should be adequate for a minimum of 10.6cfm free air delivery to the sanding tool. There should be a minimum of 13cfm
free air delivered to the air inlet of the dust free vacuum system. We recommend the use of a 3HP (or more) compressor.
3 Air supply must be delivered through a 3/8” internal diameter air hose. If you use a 5/16” internal diameter the performance of the tool may
suffer.
3 Keep air hose away from heat, oil and sharp edges. Check air hose for wear before each use, and ensure that all connections are secure.
3 Before each use check attached tool for condition. If worn or damaged replace immediately.
p WARNING! The maximum wattage of any electrical tool operated from the dust free vacuum system must not exceed 1200 watts.
3 Ensure there are no flammable or combustible materials near the work area.
p WARNING! Always wear appropriate approved eye, face, mask, ear defenders, or protective clothing according to task being undertaken.
3 Keep hands and body clear of the sanders working parts when operating the
AUTOMATIC DUST FREE SYSTEM
from mains power and air supply before changing accessories, servicing or performing
in good condition (use an authorised service agent).
in a suitable work area. Keep area clean and tidy and free from unrelated materials. Ensure there is
DFS31A & DFS31B
MODELS:
Blue
Neutral
Wire
dust free vacuum system.
dust free vacuum system.
INSTRUCTIONS FOR:
Yellow & Green
Earth Wire
Brown
Live
Wire
Cable
Restraint
FUSE RATING 10 AMP
DFS31A & DFS31B - 3 - 150405
