| 2 - JH-7110 DevKit Configuration Basics
Table 2-1 Boot Mode (continued)
Boot Mode
SD Card boot
QSPI Flash boot
UART boot
Note:
StarFive does not recommend that you boot from SD Card directly. It is recommend that
JH-7110 DevKit use the following boot mode:
• QSPI Flash + SD Card
• QSPI Flash + eMMC
The following figure shows the dip switch locations for all the supported boot modes (⑥) in
View (on page 7).

Figure 2-1 Boot Mode Dip Switch Location

www.starfivetech.com
Boot Selection
Value
RGPIO_1
0×1 0 (L)
0×2 0 (L)
0×3 1 (H)
© 2018-2024 StarFive Technology
All rights reserved
RGPIO_0
1 (H)
0 (L)
1 (H)
Top
12
