- Page 1 CHR Series SPEAKER SYSTEM Reference Manual...
-
Page 2: Table Of Contents
• Reference manual (this document) Explains all features of this product. You can download each document from the Yamaha website. Please refer to them as necessary. https://download.yamaha.com/ The precautions and other matters of concern are classified in this manual as follows. -
Page 3: Notice
NOTICE To avoid the possibility of malfunction/damage to the product or damage to other property, follow the notices below. Handling and maintenance • Do not expose the product to excessive dust or vibration, or extreme cold or heat, in order to prevent the possibility of panel disfig- uration, unstable operation, or damage to the internal components. -
Page 4: Main Features
Main Features • This is a high-quality speaker unit, with smooth directional characteristics, and has built-in ports that reduce wind roar in order to achieve a high-resolution sound. • Delivers high sound pressure due to the unit’s high-input tolerance and exceptional reliability from protection circuitry. •... -
Page 5: Controls And Connectors
Controls and Connectors Rear Rear Rear (CHR15) (CHR12) (CHR10) FRONT 7° FRONT 0° 7° 0° Bottom Bottom Bottom Side (CHR15M, CHR12M) q Screw holes for U-bracket M8 (CHR12, CHR10) For installation using separately sold U-brackets. w Screw holes for eye bolts M10 (CHR15, CHR12, CHR10) For installation using commercially available eye bolts (M10). - Page 6 Controls and Connectors speakON connectors These are speakON connectors (NEUTRIK NL4) for connection to a power amplifier or a powered mixer using a speaker cable. Use only NEUTRIK NL4 plugs to connect speakON connectors. CAUTION Use cables specially designed for speakers.
-
Page 7: Connection
Connection Wiring Be sure to wire the plugs as shown below. NEUTRIK speakON plug (NL4) 2– (unconnected) 2+ (unconnected) 1+ : 1– : Parallel connection of speakers speakON connectors are connected inside in parallel. The first CHR receives the signal from an amplifier (such as a power amplifier, a powered mixer, etc.) through one of the speakON connectors, and routes the signal to the second CHR from another speakON connector. -
Page 8: Installation Examples
• Be sure to use eye bolts that comply with standards and safety regula- tions in your area. Yamaha cannot be held responsible for damage or injury caused by insufficient strength of the support structure or improper installation. Suspended Installation Using Eye Bolts (CHR15, CHR12, CHR10) Attach commercially available long eye bolts (30–50 mm in length) to the screw holes located at the top (two locations) and on... - Page 9 Yamaha UB-DXRDHR12 and UB-DXRDHR10 U-bracket respectively. For instructions on installing the U-bracket, refer to the manual for the UB-DXRDHR12 and UB-DXRDHR10. NOTE You can use the U-bracket in combination with optional brackets sold separately. For more information, visit the following Yamaha Pro Audio website. https://www.yamahaproaudio.com/ In addition, the CHR12 and CHR10 feature a rotatable horn (90 degrees).
- Page 10 Installation Examples Rotatable Horn (CHR12, CHR10) Using a No. 2 Phillips head screwdriver, remove all fixing screws on the grille, and then remove the grille from the speaker. Using a No. 2 Phillips head screwdriver, remove all screws installed on the horn and then pull the horn out from the speaker. NOTE While removing the screws with the Phillips head screwdriver, do not apply too much pressure onto the screws.
-
Page 11: Troubleshooting
The protection circuit is operating in the HF Refer to “Protective Circuit” in the NOTICE High frequency range is attenuated. unit. (page 3). If any specific problem should persist, please contact your Yamaha dealer. -
Page 12: Specifications
× 3 (parallel con- SpeakON NL4MP × 2 (parallel connected) nected) nected) * The contents of this manual apply to the latest specifications as of the publishing date. To obtain the latest manual, access the Yamaha website then download the manual file. -
Page 13: Dimensions
Dimensions CHR15 2×M10 Unit: mm CHR12 2xM10 2xM8 Unit: mm... - Page 14 Dimensions CHR10 2×M10 2×M8 Unit: mm...
- Page 15 Dimensions CHR15M Unit: mm CHR12M Unit: mm...
- Page 16 Yamaha Pro Audio global website https://www.yamahaproaudio.com/ Yamaha Downloads https://download.yamaha.com/ © 2024 Yamaha Corporation Published 02/2024 IP-A0...
