Table Of Contents - Delta Controls HTX Installation, Operation & Maintenance Manual

T A B L E O F C O N T E N T S H E A D E R
I N S T A L L A T I O N
1. Components of the HTX Claus Thermal Reactor Thermocouple System
2. Pre-Installation
2.1 Transportation
2.2 Storage
2.3 Handling
2.4 Pre-Installation Preparation
2.5 Site Installation Survey
2.6 Thermocouple and Accessories Inspection
2.7 Nozzle Inspection
2.8 Resolving Dimensional Problems
3. Installing the Thermocouple
3.1 Vertical Installation
3.2 Non-Vertical Installation
3.3 Wiring
3.4 Flush Gas Connection
3.5 Flush/Primary Thermowell Integrity Test
O P E R A T I O N & M A I N T E N A N C E
4. Using Multiple Thermocouples within the HTX
5. Pre-Commissioning/Commissioning Procedure (Startup)
6. Shutdown
7. Operation
8. Maintenance
9. Troubleshooting
S P E C I F I C A T I O N S
10. Specifications
