SINK SPECIFICATIONS
Glass Vessel Sink
Model VG07904
MODEL VG07904
FEATURES
PACKING LIST
For warranty purposes contact our toll free number:
TOLL FREE: (866) 591 - 7792
E-Mail: techmail@vigoindustries.com
www.vigoindustries.com
DIMENSIONS
MODEL #
SINK
DIAMETER
VG07904
16 1/2"
SINK
HOLE
HEIGHT
DIAMETER
6 "
1 3/4"
16 1/2"
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for VIGO VG07904
Summary of Contents for VIGO VG07904
- Page 1 SINK SPECIFICATIONS Glass Vessel Sink Model VG07904 MODEL VG07904 FEATURES PACKING LIST DIMENSIONS MODEL # SINK SINK HOLE DIAMETER HEIGHT DIAMETER VG07904 16 1/2" 6 " 1 3/4" For warranty purposes contact our toll free number: TOLL FREE: (866) 591 - 7792 16 1/2"...
- Page 2 16 1/2" FRONT VIEW TOP VIEW NOTE: GLASS THICKNESS 1/2" GLASS DIAMETER AND HEIGHT MAY VARY UP TO 1/ 2" MODEL VG07904 THE MEASUREMENTS IN INCHES ARE ROUNDED TO THE NEAREST 1/8"...
- Page 3 Note: The Plumber's putty or Caulk stand comes as a free accessory with a Vigo style pop up. If you decide not to Caulking Gun purchase the Vigo style pop up, the stand can be purchased through the Vigo Tape Measure technical support department.
- Page 4 Subject to the Warranty Service provision below, any product reported to the authorized dealer or to VIGO as being defective within the warranty period will be repaired or replaced (with a product of equal value) at the option of VIGO. This warranty extends to the original owner or end-user and is not transferable to a subsequent owner.
- Page 5 FAUCET SPECIFICATIONS Wall Mount Bathroom Faucet Model VG05001 MODEL VG05001 FEATURES Solid brass construction Single hole construction Ceramic disk cartridge Single lever faucet Wall mount installation Finish resist corrosion and tarnishing PACKING LIST Faucet Assembly Allen Key Spout Cover for spout Mixer Handle Cover for handle...
-
Page 6: Side View
9" SIDE VIEW 5 1/4" 2" 4 3/8" 2 3/8" TOP VIEW 7/8" FRONT VIEW VG05001 THE MEASUREMENTS IN INCHES ARE ROUNDED TO THE NEAREST 1/8"... -
Page 7: Maintenance
HOT AND COLD WATER TO RUN AT LEAST ONE parts are included and visually inspect the unit for any defects. MINUTE EACH. WHILE WATER IS RUNNING, If you have any questions please contact the Vigo Technical Support CHECK FOR LEAKS, ESPECIALLY AT HOOK-UPS Department before proceeding with installation. -
Page 8: Troubleshooting
Using either an allen key or a flat head screw driver, tighten the screw so handle has firm connection to cartridge. PARTS LIST - For any parts needed but not shown, please contact Vigo Technical Support PART # PART FINISH... - Page 9 VIGO or an authorized VIGO dealer, through the lifetime of the original owner or end-user. VIGO warrants the cartridge component of the Product to be free from defects in workmanship and materials under normal use and service for a period of five (5) years from the initial date of purchase by the owner, contractor, or builder, from VIGO or an authorized VIGO dealer.
- Page 10 DRAIN SPECIFICATIONS Bathroom Sink Pop-up Drain VG07000 Model FEATURES Solid brass construction Without an overflow Decorative ring Push down style pop-up Round pop-up cover NOMINAL DIMENSIONS HEIGHT INSTALLED WIDTH INSTALLED DEPTH 1" 2 3/4" 9" 2 3/4" 2 1/2" 1 1/4"...
- Page 11 VIGO warrants the Product to be free from defects in workmanship and materials under normal use and service for a period of one (1) year from the initial date of purchase by the owner or end-user, contractor, or builder, from VIGO or an authorized VIGO dealer.
