Genius REMOTE 600 Manual

Hide thumbs Also See for REMOTE 600:
Table of Contents

Advertisement

Quick Links

Table of Contents

Remote 600 Features ............................................ 2
Unpacking the Remote 600................................. 2
About the Remote 600 ......................................... 3
Installing batteries.................................................. 4
About the controls ................................................ 6
Touch screen precautions ........................... 6
Selecting devices and pages ..................... 7
Entering setup ...................................................... 10
Changing the LCD layout .................................. 11
Using preset codes.............................................. 12
Manually setting preset codes .................. 13
Checking the code number ..................... 14
Learning codes.................................................... 15
Deleting codes .................................................... 17
i
1
4
10

Advertisement

Table of Contents
loading

Related Manuals for Genius REMOTE 600

Summary of Contents for Genius REMOTE 600

  • Page 1: Table Of Contents

    Using preset codes..........12 Manually setting preset codes ....13 Checking the code number ..... 14 Learning codes............ 15 Deleting codes ............ 17 Deleting codes one button at a time ..18 Deleting codes one device at a time ..18...
  • Page 2 Creating Macros ..........19 Resetting factory defaults........21 Chapter 4 Using the Remote 600 Button protection ..........22 Record button protection........23 Punch thru ............23 Auto power-off ............ 25 Wake up sensor ........... 25 Backlight ............... 25 Appendix Specifications............26...

  • Page 3: Chapter 1 Introducing The Remote 600

    “learning eye” feature. The advanced macro function enables you to initiate a chain of up to 60 commands with the touch of a single key. Easy to use, the Remote 600 provides you with a complete central control solution.

  • Page 4: Remote 600 Features

    Multi-language e-manual on CD • Pre-programmed Code List • AAA batteries x 4 If any of these items are missing or damaged, contact your dealer immediately. Do not throw the packaging in case you need to ship your Remote 600.

  • Page 5: About The Remote 600

    ENGLISH About the Remote 600 IR transmitter LED indicator Low battery indicator Page indicator Device indicator PC link Setup button LCD touch screen Volume +/- Backlight switch Power switch Channel +/- Return Programmable number buttons Device buttons Learning eye...

  • Page 6: Chapter 2 Quick Start

    ENGLISH Chapter 2 Quick start This chapter provides you with the information to quickly start using the Remote 600. Installing batteries The Remote 600 requires four AAA alkaline batteries (not included). You must insert the batteries before you can operate the Remote 600.
  • Page 7 ENGLISH Battery Indicator A battery icon is displayed in the upper left-hand corner above the Mute button. When the batteries are almost discharged, the battery low icon appears. Battery Tips and Precautions • Pay attention to the batteries when the battery half full icon appears and replace batteries if needed.

  • Page 8: About The Controls

    Remote 600 and your external devices. Use these keys to program codes from your existing remotes, control your devices, and set up macros. You will hear a beep when you press a button. The Remote 600 turns itself off after 90 seconds of inactivity Touch screen precautions •...

  • Page 9: Selecting Devices And Pages

    ENGLISH Selecting devices and pages You can program the hard buttons as well as two pages of soft buttons (on the touch screen) for up to six devices. To change between devices, press the appropriate device button. To switch between pages, press the device button again.

  • Page 10: Loading Preset Codes Using Auto Search

    5. Point the IR transmitter of the Remote 600 at the device then press 6. The Remote 600 will try to turn off the device by transmitting different preset IR codes. When the device switches off, immediately press any hard button or touch the screen.
  • Page 11 ENGLISH NOTES: • You can stop the auto search at any time by pressing any button. • The codes for your device may not be included in the preprogrammed list. If the device does not switch off in six minutes, you may not be able to use preset codes.

  • Page 12: Chapter 3 Setting Up The Remote 600

    ENGLISH Chapter 3 Setting up the Remote 600 Before you can use the Remote 600, you must set it up either by using preset codes or learning codes from your existing IR remote controls. Entering setup To enter setup, press and hold the button for two seconds.

  • Page 13: Changing The Lcd Layout

    ENGLISH Changing the LCD layout You can customize the LCD layout to match the remote control supplied with your devices. 1. Press and hold for two seconds the device button of the device you want to customize. You will see the device icon flashing on the touch screen.

  • Page 14: Using Preset Codes

    ENGLISH Using preset codes This is the fastest way to program the Remote 600 but requires that your device be located in the Pre-programmed Code List that was bundled with the Remote 600. The Remote 600 comes pre-programmed with a list of preset codes.

  • Page 15: Manually Setting Preset Codes

    ENGLISH Manually setting preset codes 1. Find your device in the supplied list of preset codes. 2. Press and hold to enter setup. 3. Press 4. Find the digit code number from the pre-programmed code list. 5. Use the number buttons to enter the four digit code.

  • Page 16: Checking The Code Number

    4 for the second, third and forth digits of the code number. You can use this code number to program the Remote 600 if your settings are changed or accidentally erased. See Manually setting preset codes on page 13.

  • Page 17: Learning Codes

    ENGLISH Learning codes If your device is not in the list of preset codes, you can use your existing IR remote control to “teach” the Remote 600. You can program all buttons except for and the DEVICE keys. NOTE: Not all codes can be learned. If the Remote 600 cannot learn a code, three beeps are emitted.
  • Page 18 Remote 600 emits a beep and the LED on the Remote 600 lights until you release the button on the device’s remote. 9. Repeat steps 5 – 8 for all the buttons you want to program. 10. When you have finished, press...

  • Page 19: Deleting Codes

    Programming a button overwrites any previous function. • When the Remote 600 has successfully learned a function it beeps once and the LED lights up until you release the remote control’s button. Deleting codes You can delete codes if you no longer want to use the function or if you want to reprogram a button.

  • Page 20: Deleting Codes One Button At A Time

    ENGLISH Deleting codes one button at a time 1. Select the appropriate device by pressing the device button. 2. Press and hold to enter s etup. Press 4. Press the button you want to delete. Repeat step 4 for all the buttons you want to delete.

  • Page 21: Creating Macros

    2. Press and hold to enter setup. 3. Press 4. Press the button to which you want to assign the macro. A double beep sounds to indicate macro mode. 5. Press the buttons in the sequence of your commands for a Macro.
  • Page 22 7. Press to confirm or to discard the macro. The button’s original function will be preserved. 8. To set another macro, repeat steps 3 ~ 7. 9. After you have finished setting macros, press to leave this mode. NOTES: •...

  • Page 23: Resetting Factory Defaults

    ENGLISH Resetting factory defaults Resetting factory defaults deletes all functions and restores them to the original factory setup. You will lose all macros and user-defined buttons. Resetting defaults cannot be undone. 1. Press and hold to enter setup. 2. Press and hold for four seconds.

  • Page 24: Chapter 4 Using The Remote 600

    Buttons which are correctly programmed using the preset codes or learning feature emit a single beep when pressed and the LED lights up briefly. If the button that do not have a function in it, the LED does not light. NOTE:...

  • Page 25: Record Button Protection

    Punch thru The punch thru function enables you to access the VOL +/– controls of the TV or RECV device without having to switch to that device. For example, while you are watching a DVD you can adjust the volume of your TV using punch thru.
  • Page 26 Volume+ or Volume - together. • The punch thru function can only be set with the DVD, VCR, SAT, and AUX devices, and enables you to control the volume of these sources through the TV or RECV device.

  • Page 27: Auto Power-Off

    90 seconds. Wake up sensor The Remote 600 also has an internal motion detector. You can turn it on again by moving the Remote 600 or press any key on it. Backlight The Remote 600 has a blue backlight to make using it in the dark room easily.

  • Page 28: Appendix

    Appendix Specifications Model Remote 600 Capacity 6 devices in one Dimensions (W x H x D) 58 mm x 198 mm x 28 mm Weight (W/O batteries) 160 g Buttons 44 programmable buttons + 6 device buttons + Backlight button...

  • Page 29: Troubleshooting

    Installing batteries on page 4. *Check the correct device is The Remote 600 does selected on the Remote 600. not operate a device. *Make sure you are using the Remote 600 within the effective transmission distance. (8 ~ 10 m) *The batteries may be discharged.
  • Page 30 Remote 600’s learning a function. learning eye and you are holding the remote’s button until the function is learned. *Check the remote’s IR transmitter is 5 ~ 10 cm from the Remote 600’s learning eye.
  • Page 31 *The LED does not light up up when you press a when the button doesn’t have button. a function in it. Please input an IR codes init. *Check the button that you pressed has been programmed the code in it.
  • Page 32 ENGLISH Problem Solution *Sometimes the code’s frequency is out of the learning range. The Remote 600 cannot learn all codes. You may not be able to program the Remote 600 for some devices or functions. Macro does not work. *Check the correct device is selected on the Remote 600.
  • Page 33 ENGLISH Problem Solution The touch screen turns *The Remote 600 has a power- off. saving feature and switches off automatically after 90 seconds of inactivity. To switch it back on again, please move the Remote 600. * The batteries may be discharged.
