PRODUCED IN ACCORDANCE WITH EN1004-3
1. COnDitiOnS / DiSCLAiMer
2. WArrAnty
3. USe & FUnKtiOn
4. GenerAL rULeS & inStrUCtiOnS FOr USe
5. PACKS & MODULeS
6. BASe MODULe
6.1 Mounting of castors
6.2 Erection
7. BASe MODULe With rAiLinG
7.1 Mounting of railing
8. 3,61 M tOWer With OUtriGGerS
8.1 Mounting of base module
8.2 Mounting of extension
8.3 Mounting outriggers
8.4 Mounting of platform
8.5 Mouting of railing
9. 5,57 M tOWer With OUtriGGerS
9.1 Mounting of the first extension
9.2 Mounting of the first platform
9.3 Mounting of the second extension
9.4 Mounting of second platform
9.5 Mounting of railing
10. DiSASSeMBLy
11. WArninGS
HOBBY
PACK 1
PACK 1
www.jumbo.as
SCAFFOLD
PACK 2
PACK 1
PACK 2
PACK 3
PACK 1
PACK 2
PACK 3
MAX. LOAD
200 KG
PACK 5
PACK 4
PACK 5

Advertisement

loading
Need help?

Need help?

Do you have a question about the HOBBY and is the answer not in the manual?

Questions and answers

Related Manuals for Jumbo HOBBY

Summary of Contents for Jumbo HOBBY

  • Page 1 SCAFFOLD HOBBY PRODUCED IN ACCORDANCE WITH EN1004-3 MAX. LOAD 1. COnDitiOnS / DiSCLAiMer 200 KG 2. WArrAnty 3. USe & FUnKtiOn 4. GenerAL rULeS & inStrUCtiOnS FOr USe 5. PACKS & MODULeS 6. BASe MODULe PACK 1 6.1 Mounting of castors 6.2 Erection...

  • Page 2: Warranty

    This type of scaffold is designed to be loaded with max. 200 kg. JUMBO HOBBY Scaffold is intended for use where there is a need for safe and easy access to a task at a given height. The scaffold is weatherproof, but it is recommended to store the scaffolding indoors when not in use. In general, aluminum scaffold- ing should avoid contact with untreated iron constructions and with iron particles, as they can work their way into aluminum.
  • Page 3 The frames must be secured with self-locking clips. The curved part of the clips should pint outwards and downwards, it automatically locks. JUMBO HOBBY Scaffolds should always be assembled on a solid and sustainable base. When moving the scaffold push only in the longitudinal direction. During movement the inclination must never exceed 2°, and move only at walking speed.
  • Page 4 5. PACKS AnD MODULeS PACK 1 - Base module Contains: 1 x folding frame 6 rungs, 72,5x165 cm 1 x platform w/hatch 60x180 cm 4 x nylon castors w/brake, Ø12,5 cm PACK 2 - Railing kit Contains: 2 x Railway frames 2 rungs, 72,5x100 cm 2 x Double guardraili 180 cm PACK 3 - Extension kit Contains:...
  • Page 5 PACK 1 PACK 1 PACK 2 PACK 1 PACK 2 PACK 3 PACK 5 PACK 1 PACK 2 PACK 3 PACK 4 PACK 5...

  • Page 6: Base Module

    assembly instructions PACK 1 6. BASE MODULE Mount the castors before mounting the scaffold! 6.1 Mounting the castors 6.1.1 6.1.2 Behind the castor there is a Insert white plastic fitting bolt. Use the enclosed Allen key to into the vertical tube hold back the bolt and turn the white on the scaffolding plastic piece until you can feel the...
  • Page 7 ASSEMBLY INSTRUCTIONS PACK 1 PACK 2 7. BASE MODULE WITH RAILING Follow the instructions from point 6. BASE MODUL, until 6.2.2 and then continue with the following. If the platform is located on the top rung, it may be advantageous to move it a few rungs down and mount from there.
  • Page 8 assembly instructions PACK 1 PACK 2 PACK 3 PACK 5 8. 3,61 M tOWer W/OUtriGGerS Follow instructions from point 6. BASE MODUL, until point 6.2.2 and continue with the following. 8.1 Mounting the base section 8.1.1 Ensure that the platform is lo- cated on the highest rung &...
  • Page 9 8.3 Mounting the outriggers 8.3.1 To mount outriggers follow the diagram 8.3.1a - 8.3.1b. Place the couplers on the outriggers prop around the vertical tube on the frame right above the 4th. rung. Fastend the couplers. Place the top couplers on the outrigger around the frame´s vertical tube and fasten loosely.
  • Page 10 assembly instructions 9. 5,57 M tOWer W/OUtriGGerS Follow instructions from point 6. BASE MODUL, until point 8.1.1 and continue with the following. NOTE: Always lock all 4 castors before entering the scaf- fold! The castors are locked by pressing the brake down. 9.1 Mounting the first extension 9.1.1 Mount the two 7 9.1.2 Then mount diago-...
  • Page 11 9.3.2 Now mount the 9.3.3 Mount the diago- next double guardrail. nals. Remember that the One on each side - diagonals must be placed mounted inside on the on each side in a cross! vertical tube. The bottom Ensure that the claws claws on each guardrail are locked correctly.
  • Page 12 JUMBO HOBBY Scaffolding may only be used with other equipment approved by JUMBO Stillads A / S. In case of design changes it will be at your own risk. Protect the storm locks, claws and castors against bumps and dirt.
