ORDER
NO. $D8001-1663
ervice Manual
Direct Drive Automatic Turntable System
Specifications
General
Power supply:
Power consumption:
Dimensions:
(Wx H x D)
Weight:
Turntable section
Type:
Drive method:
Motor:
Drive control method:
Turntable platter:
Turntable speeds:
Speed deviation:
Wow
and flutter:
Rumble:
Tonearm section
Type:
Technics
Specifications subject to change without notice.
Weight and dimensions shown are approximate.
~ 110-120/220-240V , 50Hz or 60Hz
DC 12 V (DC input jack)
20 W (AC)
6 W (DC)
31.5 x 8.8 x 31.5cm
(12-1/2" x 3-1/2" x 12-1/2")
6.5 kg (14.3 Ib.)
Quartz direct drive
Automatic turntable
Auto start/Auto lead-in
Auto return
Auto stop
Repeat play
Auto speed select
Auto size select
2-speed search functions
Record presence detection
Direct drive
Brushless DC motor
Quartz-phase-locked control
Aluminum die-cast
Diameter 30 cm (12 inches)
33-1/3 rpm and 45 rpm
Auto speed select
(Manual selection possible)
Within +0.002%
0.012% WRMS*
0.025% WRMS
(JIS C5521)
+0.035% peak (IEC 98A Weighted)
*Measured by obtaining signal from built-in frequency
generator of motor assembly.
—56 dB (IEC 98A Unweighted)
—78 dB (IEC 98A Weighted)
Dynamic balanced type
Linear tracking tonearm
4-pivot gimbal suspension
~ SL-10
(XG), (XGF), (XGB),
(XAL), (E), (XA), (XGE)
Areas
Effective length:
Tracking error angle:
Effective mass:
Resonance frequency:
Tonearm drive motor:
Cartridge section
Type:
Cantilever:
Damper
Frequency
response:
Output voltage:
Channel separation:
Channel balance:
DC resistance:
Impedance:
Compliance (dynamic):
Vertical tracking angle:
Stylus pressure range:
Stylus tip:
Effective mass:
Weight:
Replacement cartridge:
MC pre-preamp section
Rumble:
Frequency response:
Output level:
Overall distortion:
*(XG) is available in European.
*(XGF) is available in France.
*(XGB) is available in Belgium.
*(XAL) is available in Australia.
*(E) is available in Scandinavia.
*{XA) is available in Asia, Latin America, Middle East
and Africa.
*(XGE) is available in United Kingdom.
105 mm
(3-31/32'')
Within +0.1°
9 g (including cartridge)
12 Hz
Coreless DC motor
Moving coil stereo cartridge
Coreless twin-ring coil type
Pure boron pipe
TTDD (Technics Temperature
Defense Damper)
10 Hz to 60 kHz
10 Hz to 10 kHz +0.5 dB
0.2 mV at 1 kHz,
5 cm/s. zero to peak lateral velocity
(0.56 mV at 1 kHz, 10 cm/s. zero to
peak 45° velocity [DIN 45 500] )
More than 25.dB at 1 kHz
More than 20 dB at 10 kHz
Within 1 dB at 1 kHz
302
300 Pure resistance
12 x 10° cm/dyne at 100 Hz
20°
1.25 +0.25 g (12.5 +2.5 mN)
0.2 x 0.7 mil (5 x 8um)
Elliptical stylus
Block diamond tip
0.23 mg
6.0 g (cartridge only)
EPS-310MC
—70 dB (IHF A)
20 Hz to 20 kHz +0.5 dB
2.5 mV
0.02% {connected to Technics
SU-70AII)
Matsushita Electric Trading Co., Ltd.
P.O. Box 288, Central Osaka Japan
