- Page 1 Owner's Manual (OLED Monitor) Please read this manual carefully before operating your set and retain it for future reference. 45GS95QE 45GS95QX www.lg.com Copyright 2024 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
TABLE OF CONTENTS ASSEMBLING AND PREPARING ............4 USER SETTINGS ................. 15 - Installing ..........................5 - Activating the Main Menu ....................15 Moving and Lifting the Monitor ..................5 Main Menu Features ......................15 Installing on a Table ......................6 Menu Settings ........................16 Using the Kensington Lock ....................6 [Game Adjust] ........................16 Installing on the Wall ......................7 [Picture Adjust] ........................17... - Page 3 TROUBLESHOOTING ................25 LICENSE .................... 26 OPEN SOURCE SOFTWARE NOTICE INFORMATION ......26...
-
Page 4: Assembling And Preparing
• To purchase optional accessories, visit an electronics store or an online shopping site, or contact the retailer • Always use genuine LG components to ensure safety and product performance. from which you purchased the product. • The product warranty will not cover damage or injury caused by the use of unauthorised components. -
Page 5: Installing
Installing CAUTION • Avoid touching the monitor screen as much as possible. Moving and Lifting the Monitor - This may result in damage to the screen or some of the pixels used to create images. • If you use the monitor panel without the stand base, its power button may cause the monitor to become When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or unstable and fall, resulting in damage to the monitor or human injury. -
Page 6: Installing On A Table
Installing on a Table Using the Kensington Lock • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm away from For more information on installation and usage, refer to the Kensington lock owner’ s manual or visit the website the wall to ensure sufficient ventilation. -
Page 7: Installing On The Wall
Installing on the Wall Installing the Wall Mount Plate To install the monitor to a wall, attach a wall mounting bracket (optional) to the back of the monitor. This monitor meets the specifications for the wall mount plate or other compatible devices. Make sure that the wall mounting bracket is securely fixed to the monitor and to the wall. - Page 8 Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could • The wall mounting bracket is optional. You can obtain optional accessories from your local dealer. lead to injury. Use an authorised LG wall mount and contact the local dealer or qualified personnel. • •...
-
Page 9: Product And Button Description
Product and Button Description : Wall Mount Plate : Back of the Monitor : Standard screw : Max. 8 mm : Joystick Button... -
Page 10: How To Use The Joystick Button
How to Use the Joystick Button Adjusting the Stand Height You can easily control the functions of the monitor by pressing the joystick button or moving it left/right/up/ Place the monitor mounted on the stand base in an upright position. down with your finger. -
Page 11: Adjusting The Angle
Supported Drivers and Software Adjusting the Angle Place the monitor mounted on the stand base in an upright position. You can download and install the latest version from the LGE website (www.lg.com). Adjust the angle of the screen. - Monitor Driver / The angle of the screen can be adjusted forward or backward from -1°... -
Page 12: Using The Monitor
CAUTION HDMI Connection • If you use generic cables not certified by LG, the screen may not display or there may be image noises. Transmits digital video and audio signals from your PC to the monitor. • Do not press the screen for a prolonged time. This may cause image distortion. -
Page 13: Displayport Connection
Connecting AV Devices DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. HDMI Connection NOTE HDMI transmits digital video and audio signals from your AV device to the monitor. • There may be no video or audio output depending on the DP (DisplayPort) version of the PC. •... -
Page 14: Connecting Peripherals
Connecting Peripherals Headset Connection Connect peripherals to the monitor via the headset port. USB Device connection NOTE The USB port on the product functions as a USB hub. • Peripheral devices are sold separately. To use USB 3.0, connect the A-B type USB 3.0 cable of the product to the PC. •... -
Page 15: User Settings
USER SETTINGS Main Menu Features NOTE • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. Activating the Main Menu Press the joystick button on the back of the monitor. Move the joystick up/down and left/right to set the options. Joystick Button Main Menu Description... -
Page 16: Menu Settings
Menu Settings [Game Adjust] [Settings] > [Game Adjust] To view the OSD menu, press the joystick button at the back of the monitor and then enter the [Settings]. • [Game Mode]: you can choose picture mode for game display settings. Move the joystick up/down and left/right to set the options. -
Page 17: [Picture Adjust]
[Picture Adjust] • [Adaptive-Sync]/[VRR]: This function shows a clear screen without screen tearing or stuttering in the game environment. [Settings] > [Picture Adjust] However, screen flickering may occur in some game environments. • [Brightness]: Adjusts the brightness of the screen. - Supported Interface: DisplayPort(Adaptive-Sync), USB-C(Adaptive-Sync), HDMI(VRR). -
Page 18: [Sound]
[Input] • [Six Color]: Meets the user requirements for colors by adjusting the hue and saturation of the six colors (red, green, blue, cyan, magenta, and yellow) and then saving the settings. [Settings] > [Input] - Hue: Adjusts the tone of the screen colors. •... -
Page 19: [General]
[General] • [SMART ENERGY SAVING]: Conserve energy by using luminance compensation algorithm. - [High]: Saves energy using the high-efficiency [SMART ENERGY SAVING] feature. [Settings] > [General] - [Low]: Saves energy using the low-efficiency [SMART ENERGY SAVING] feature. • [Language]: Sets the menu screen to the desired language. - [Off]: Disables the feature. -
Page 20: Important Information For Preventing Image Retention
Important Information for Preventing Image Retention Safety precautions for prolonged use Due to the unique properties of OLED panels, the brightness may be reduced with prolonged use. Reduced Unlike regular LED/LCD monitors, pixels in the OLED monitors emit light on their own, achieving a perfect black brightness is permanent. -
Page 21: Product Specification
PRODUCT SPECIFICATION AC/DC Adapter • Model: AD10660LF Manufacturer: PI Electronics (H.K.) Ltd. Specifications are subject to change without notice. - Input: 100-240 V~ 50/60 Hz 3.3 A The symbol means alternating current, and the symbol means direct current. - Output: 20.0 V 13.5 A Color Depth: Power Sources •... -
Page 22: Support Mode
Support Mode HDMI Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.940 800 x 600 37.879 60.317 1024 x 768 48.363 60.004 1280 x 720 45.000 60.000 1280 x 1024 79.976 75.025 1920 x 1080 67.500 60.000 720 x 480... - Page 23 Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.940 800 x 600 37.879 60.317 1024 x 768 48.363 60.004 1280 x 720 45.000 60.000 1280 x 1024 79.976 75.025 1920 x 1080 67.500 60.000 720 x 480 29.830 59.779...
-
Page 24: Hdmi Timing (Video)
HDMI Timing (Video) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) 480P 31.5 720P 1080P 67.5 1080P 2160P 2160P... - Page 25 Do you see an "Unrecognised monitor, monitor found" message? • Have you installed the display driver? - Be sure to install the display driver from our web site: http://www.lg.com. - Make sure to check if the graphics card supports function.
- Page 26 HDMI Licensing LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing Administrator, Inc. such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.
- Page 27 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. Model Serial No.
