3.3 OSD Setting

Basic and simple instruction on the control keys.
VGA+DVI:
VGA+HDMI:
VGA+HDMI+Earphone out:
1).Press the bottom key to activate the OSD window.
2). You can now select any one of the functions by quickly repeat-pressing the bottom key . The blue box will
navigate towards the right as you press the key. You can release once the blue box highlights the option you want to
choose. Note that the selection is one way loop always moving one direction and then returning at beginning of the
menu. The blue box will remain on the selected function for about 3 seconds and the function icon will flash three
times to confirm the choice visible on the 1st layer of the OSD and activate it.
VGA+DVI:
VGA+HDMI:
VGA+HDMI+Earphone out:
