PLEASE READ CAREFULLY AND KEEP
THIS MANUAL FOR FUTURE REFERENCE
Instruction Manual
KOCHER-COCINERA-FORNELLO
YOU CAN CONSULT A PROFESSIONAL INSTALLER OR ASK FIRE OFFICIALS OR LOCAL AUTHORITY ABOUT RESTRICTION
AND INSTALLATION INSPECTION IN YOUR AREA.
Certified to
ULC S627, UL 1482
ASTM E3053, ASTM 2515
2020 U.S. Environmental Protection
Agency's cord wood emission standard
490, rue de l'Argon, Quebec (Quebec) Canada G2N 2C9
Phone.: 418-849-8095
Fax: 418-849-0077
www.jaroby.com
PR_I016/2023-02-02-EN
Revision: 13
Printed in Canada
Advertisement
Table of Contents
Related Manuals for J. A. Roby KOCHER
Summary of Contents for J. A. Roby KOCHER
- Page 1 PLEASE READ CAREFULLY AND KEEP THIS MANUAL FOR FUTURE REFERENCE Instruction Manual KOCHER-COCINERA-FORNELLO YOU CAN CONSULT A PROFESSIONAL INSTALLER OR ASK FIRE OFFICIALS OR LOCAL AUTHORITY ABOUT RESTRICTION AND INSTALLATION INSPECTION IN YOUR AREA. Certified to ULC S627, UL 1482 ASTM E3053, ASTM 2515 2020 U.S.
-
Page 2: Table Of Contents
Exterior Air Intake pipe ......... 20 Annexe 2 ............. 29 Installation of Air Intake Pipe ......20 Replacement parts ..........29 Air Inlet Obstruction .......... 20 J. A. Roby Limited Lifetime warranty ....30 Stainless steel tubes replacement ....... 20 PR_I016/2023-02-02-EN Revision: 13... -
Page 3: Introduction
Firebox size 3.01 cubic feet Save these instructions. Please read all the instructions • Recommended log length: 16 inches carefully before installing your new J. A. ROBY Kocher, Cocinera or Fornello cook stove. A proper installation is • Fuel Orientation: front to rear. -
Page 4: Rating Plate
Rating plate PR_I016/2023-02-02-EN Revision: 13... -
Page 5: Appliance Dimensions
Appliance dimensions PR_I016/2023-02-02-EN Revision: 13... -
Page 6: Specifications
Specifications Option Kocher Cocinera Fornello Combustible Wood Wood Wood Recommended 1000 > 3000 ft² 1000 > 3000 ft² 1000 > 3000 ft² Surface area Cooking lids / Cast iron corners Capacity 55 107 BTU/h 55 107 BTU/h 55 107 BTU/h... -
Page 7: Installation
Installation Cook stove with or without water tank WARNING ALWAYS USE J.A. ROBY PARTS on your appliance. Using other differences parts can damage the appliance and cause injury. Floor protection Your stove must be installed on a plate of non-combustible material to protect the floor and avoid fire caused by: •... -
Page 8: Minimum Clearances To Combustible Material
This appliance needs a minimum space because of these reduced clearances. Whether in the living room or the dining room, the Kocher, Cocinera and Fornello cook stove will match perfectly by its originality and heating. For the double wall pipe in Canada and USA, the minimum clearance at the back is 11 1/4 inches (28.6 cm) and the... -
Page 9: Assembly Before Installation
You must therefore assemble these parts before installing the cook stove. Warming oven top Assembly (Kocher and Cocinera) At this moment, you need to know which type of smoke pipe you are installing: a single pipe or a double pipe. -
Page 10: Firebricks Installation
Firebricks installation Side firebrick installation Floor firebricks installation (With ash plug) Put 4 bricks "A" and 1 brick “G” as shown. Put 4 Bricks «A» near to the back wall and 1 brick «P and Q» in front of bricks “A”. Back firebrick installation Put 8 bricks «A»... -
Page 11: Firebrick Installation On The Pipes
Firebrick installation on the pipes Insert the 3 bricks “Y” between the pipes and the rockwool The firebricks must be put on the 3 pipes from the front of combustion chamber. Bricks keep the maximum heat inside the Put two half-round steel disks over the rockwool near the rear combustion chamber and help the air from the tube burn most of deflector (3) already in place. -
Page 12: Firebox Configuration & Part List
Firebox configuration & part list 1) 2 half-disk metal steel plates 2) 1 rock wool insulating blanket 3) 3 Ø 3⁄4 ’’x 15 ’’ pipes with holes on a single side 4) 2 Ø 3⁄4 ’’ x 15 ’’pipes with bigger holes on both side 5) 1 screw and bricks support 6) 1 air pilot 7) 1 ash plug... -
Page 13: General Steps Of Stove Installation
General steps of stove installation Install the chimney following the manufacturer Read the entire installation manual before installing instructions. and using your stove. Put the stove on the floor aligned vertically with the Choose a place to install your cook stove. Read the center of chimney and trace the 4 sides of the stove sections about dimensions of floor protection panel, vertically on the floor. -
Page 14: Chimney Connector Installation
Insert entirely the roll formed end into the stove collar and Chimney connector installation screwing it with a minimum of 3 screws. The chimney connector is a set of single flue pipes and elbow installed between the stove collar and the chimney collar. Components of single wall chimney connector are available at any hardware store and there is no precise standard or regulation. -
Page 15: Installation In A Transportable Building
Installation in a transportable building DO NOT INSTALL THIS APPLIANCE IN A TRANSPORTABLE BUILDING Use of smoke detectors and carbon monoxide monitors To provide reasonable fire prevention, the following should be given serious consideration: At least one smoke detector on each floor of your home should be installed to ensure your safety. -
Page 16: General Steps Of Chimney Installation
Use only approved chimneys of the same size as the output of • The chimney must also be at least 2 feet over the the appliance, which means 6 inches in the case of Kocher, Cocinera and Fornello. The chimneys must be... -
Page 17: Vertical Installation Inside Masonry Chimney
Vertical Installation inside Masonry Outside Vertical Installation Chimney The cook stove must be installed in accordance with the applicable local laws or the CAN/CSA-B365, NFPA 211 The cook stove must be installed in accordance with the (USA). Follow the chimney manufacturer’s instructions to applicable local laws or the standards such as ULC-S635, ULC- install the chimney. -
Page 18: Vertical Installation On Cathedral Roof
Vertical Installation on Cathedral Roof Offset Vertical Installation The cook stove must be installed in accordance with the The cookstove must be installed in accordance with the applicable local laws or the CAN/CSA-B365, NFPA 211 (USA). applicable local laws or the CAN/CSA-B365, NFPA 211 (USA). Follow the chimney manufacturer’s instructions to install the Follow the chimney manufacturer’s instructions to install the chimney. -
Page 19: Vertical Installation
Vertical Installation The cook stove must be installed in accordance with the applicable local laws or the CAN/CSA-B365, NFPA 211 (USA). Follow the chimney manufacturer’s instructions to install the chimney. PR_I016/2023-02-02-EN Revision: 13... -
Page 20: Combustion Air Intake
Stainless steel tubes Combustion air intake replacement In conventional designed homes, natural ventilation is enough Although the tubes are in stainless steel, with extreme to operate the wood stove efficiently. temperature and conditions, the tubes are eventually corroded Some houses are more airtight than others. If you do not have and perforated by normal deterioration. -
Page 21: Operating Instructions
NEVER LEAVE THE STOVE UNATTENDED WHEN THE DOOR IS SIGHTLY OPEN. ALWAYS CLOSE THE DOOR Operating Instructions AFTER LIGHTNING. CAUTION: NEVER USE GAZOLINE, GAZOLINE TYPE Control of primary and secondary air LANTERN FUEL, KEROSEN, CHARCOAL LIGHTER FLUID, OR SIMILAR LIQUIDS TO START OR “FRESHEN UP” THE admission FIRE IN THIS STOVE. -
Page 22: First Fire
Insert the end of the handle into the opening of the First fire cooking hole cover. For the first hours of operation, you must heat your appliance Tilt the handle to the outside and lift up the opposite gradually. In order to allow an appropriate baking of the paint side of the cooking hole cover. -
Page 23: Opening And Closing Of Warming Oven
Usage of oven for cooking Opening and closing of warming oven The cook stove can cook food in the oven part. The heat is The spring handles of warming oven are decorative purpose transferred from the wall between the stove and the oven. To only. -
Page 24: Wood Storage
Wood storage Ash Disposal Keep wood 36 inch (91cm) away from the cook stove. Some embers are mixed with ash and can remain lit. If embers NEVER STORE WOOD UNDER THE COOK STOVE. have enough oxygen, it can stay lit some hours and even some Maintenance few days. -
Page 25: Door Maintenance
Door maintenance Disassembly and reassembly of door Do not unscrew the lower hinge when disassemble the door. The door is the mobile element that needs a special attention. Its tightness is primordial. If you see the white soot sticking on Keep the door locked. -
Page 26: Replacing Glass Fiber Rope
Replacing glass fiber rope What to do in case of Chimney Fire When the braided glass fibre rope is all flattened out, it becomes impossible to close the door hermetically. This means that the Contact your local authority to know what to do in case of glass fibre rope is no longer usable or that the rope is damaged. -
Page 27: Annex 1
Annex 1 Door assembly Wood Stove Door *The same assembly for an arc wood stove PR_I016/2023-02-02-EN Revision: 13... -
Page 28: Oven Door
Oven Door PR_I016/2023-02-02-EN Revision: 13... -
Page 29: Annexe 2
Annexe 2 Replacement parts • Bricks • Stove ceramic glass • Tempered glass oven door • Spring Handle • Stove door • Oven door • Fans • Flat glass fiber rope (around glass) • Round glass fiber rope • Ash plug •... -
Page 30: J. A. Roby Limited Lifetime Warranty
WOOD BURNING STOVES & FIREPLACES J. A. ROBY’s warranty only applies to original buyer and is non-transferable. This warranty covers brand new products only, which have not been altered, modified nor repaired since shipment from factory. The products covered by this warranty must be manufactured after review date indicated at the bottom of page.
