Montage- und Bedienanleitung
安装及操作指南
Návod k instalaci a k použití
Instrucciones de montaje y de manejo
Instructions de montage et mode d' emploi
Installation and operating instructions
ΟΔΗΓΙΕΣ ΕΓΚΑΤΑΣΤΑΣΗΣ ΚΑΙ ΣΥΝΤΗΡΗΣΗΣ
Szerelési és használati utasítás
Istruzioni di montaggio e per l'uso
Montagehandleiding en Gebruiksaanwijzing
Instrukcja montażu i obsługi
Instrucţiuni de montaj şi utilizare
Руководство по монтажу и эксплуатации
Návod na montáž a obsluhu
Weitere Sprachen finden Sie hier.
您可 在
找 其他
Další jazyky najdete zde.
Puedes encontrar otros idiomas aquí.
Vous pouvez trouver d'autres langues ici.
You can find other languages here.
Μπορείτε να βρείτε άλλες γλώσσες εδώ.
Itt találhat más nyelveket is.
Puoi trovare altre lingue qui.
Andere talen vindt u hier.
Inne języki znajdziesz tutaj.
Pute i găsi alte limbi aici.
Здесь вы можете найти другие языки.
Ďalšie jazyky nájdete tu.
Kludi GmbH & Co. KG
Postfach 25 60
D-58685 Menden
Am Vogelsang 31-33
D-58706 Menden
。
Telefon:
(D) +49 (0) 23 73 / 904-0
Telefax:
(D) +49 (0) 23 73 / 904-4 65
E-Mail:
info@kludi.de
Internet:
www.kludi.com
t
H o
l d
C o
Advertisement
Table of Contents
Related Manuals for Kludi PushTronic
Summary of Contents for Kludi PushTronic
- Page 1 Andere talen vindt u hier. Inne języki znajdziesz tutaj. Pute i găsi alte limbi aici. Здесь вы можете найти другие языки. Ďalšie jazyky nájdete tu. Kludi GmbH & Co. KG Telefon: (D) +49 (0) 23 73 / 904-0 Postfach 25 60 Telefax:...
- Page 2 5 °C / 41 °F min. 1 bar / 14,5 psi 3 min. 158 °F Kludi GmbH & Co. KG Postfach 25 60 Telefon: Telefax: (D) +49 (0) 23 73 / 904-0 (D) +49 (0) 23 73 / 904-4 65 D-58685 Menden...
- Page 3 Bath fill mode 20 - Maintenance - Anti-legionella flushing 21 - Maintenance - Cleaning 22 - Device settings 23 - Satistics Settings 24 - Annex Problems KLUDI has the right to change these and the following conditions at any time. www.kludi.com...
-
Page 4: Safety Instructions
Safety Safety instructions Due to the combination of control unit (PushTronic) and APP hazards are not always clear or immediately recognisable. Therefore proceed with caution and in accordance with the operating instructions. Children and physically, mentally or sensory impaired persons must be instructed or supervised. - Page 5 PushTronic Initial start-up Start-up Must be carried out before the first application (please speak to your installer). All intended consumers must be connected for this. Caution! During this process, hot water flows through all consumers to flush and set up the pipes! There is a risk of scalding! Caution! Pay attention to the alignment of the consumers, especially the hand shower, as otherwise water damage may occur.
- Page 6 PushTronic Operation <35 °C 8 L/min. 8 L/min. <95 °F 35 °C 35 °C 95 °F 95 °F 38 °C / 100 °F 44 °C / 111 °F >35 °C >95 °F 44 °C 111 °F www.kludi.com...
-
Page 7: Pause Mode
PushTronic Operation Pause Mode During the shower process, you can switch to pause mode by pressing the Cold associated rotary knob. To continue showering, tap the corresponding knob again. If a shower process (warm-up, child safe shower, bath filling, etc.) is started via the S- FLOW APP, the mixer switches to pause mode after preparation and you can start the shower process via pressing the left rotary knob. -
Page 8: Summer Mode
PushTronic Summer mode Summer mode (not for EU countries!) Summer mode requires that the hot and cold water supplies have a similar or the same flow temperature. Only then should the summer mode be activated. The water temperature cannot be adjusted in this mode. The water temperature is the temperature that flows out of the pipes. - Page 9 S-FLOW APP coupling APP coupling Instructions for pairing the KLUDI device with a smartphone Download the S-FLOW APP from Google Play or the APP Store. Connect your smartphone to your Wi-Fi network. Open the S-FLOW APP and click on "Sign up"...
- Page 10 Start and end the showering process by pressing the left rotary knob 4 times. Press "Done" to continue. If the device is not listed, repeat the above procedure. Alternatively, either disconnect the power supply or reconnect the WiFi module. www.kludi.com...
-
Page 11: General Information
Call up device selection, Terminate connection. Alarm active, Select alarm setting. Select user Close window/menu Back to the previous window/menu Next Continue to the next window/menu Save setting Save Main window B shows menu-related information, possible selections, input masks and control elements. www.kludi.com... - Page 12 Device settings - Maximum water temperature - Maximum water flow rate - Pause time - Automatic switch-off Statistics, data and consumption APP settings - Password - Terms and conditions - Privacy policy of the APP - APP version - Logout www.kludi.com...
-
Page 13: Device Selection
"Save" in the top right-hand corner. Here it is also possible to disconnect the device by clicking on "Disconnect device" at the bottom. Attention! If the device is not connected to the APP, no settings can be made on the product. www.kludi.com... - Page 14 The selection window appears. Select a user profile. The user profile is selected. To rename the user profile, click on the three small dots. Now change the name of the user and press “Save" in the top right-hand corner. www.kludi.com...
- Page 15 Now programme the parameters for the warm-up and press "Save" in the top right- hand corner. The change has been saved. The process can be cancelled via "CANCEL” in the S-FLOW APP or by pressing the left rotary knob on the mixer. www.kludi.com...
- Page 16 - Move alarm, - Start/stop warm-up or - Deactivate alarm. Press "+" to programme, change or delete an alarm. The programming window appears. Now programme the alarm and press "Save" in the top right-hand corner. The change has been saved. www.kludi.com...
- Page 17 Caution! Check that the shower is clear (no persons or objects). This setting prevents the parameters preset here (temperature, flow rate, outlet) from being changed via the control unit (e.g. PushTronic). Press to start the warm-up process directly. As soon as the warm-up process has been completed, the display switches to pause mode.
- Page 18 Repeat the programming for all subsequent steps and press "Save" in the top right- hand corner. The change has been saved. The process can be cancelled via "CANCEL" in the S-FLOW APP or by pressing the left rotary knob on the mixer. www.kludi.com...
- Page 19 Now programme the parameters for the Bath fill mode and press "Save" in the top right-hand corner. The change has been saved. The process can be cancelled via "CANCEL” in the S-FLOW APP or by pressing the left rotary knob on the mixer. www.kludi.com...
-
Page 20: Maintenance
Caution! Check that the shower is clear (no persons or objects). The process can be cancelled via "CANCEL” in the S-FLOW APP or by pressing the left rotary knob on the mixer. www.kludi.com... - Page 21 Caution! Check that the shower is clear (no persons or objects). The process can be cancelled via "CANCEL” in the S- FLOW APP or by pressing the left rotary knob on the mixer. www.kludi.com...
-
Page 22: Device Settings
In the "Device settings", "Maximum temperature", "Maximum flow", "Pause time" and "Auto shower OFF timer" can be set for the three users. This display also contains the serial number of the system. This serial number is important if external maintenance is required and must be specified if necessary. www.kludi.com... - Page 23 The password can be changed in the "Settings" menu. Here you will also find the terms and conditions and the privacy policy of the APP as well as the current APP version. In this menu you will also find "Logout" to log out of your user account. www.kludi.com...
- Page 24 Description Recommended action Problem Check the power supply to the mixing unit. PushTronic The PushTronic has lost the connection to Check the connection of the power cable and without function the display cable to the mixing unit and the mixing unit check whether the cables are damaged.
